2001 PONTIAC GRAND PRIX keyless

2-26
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transaxle. And remember to lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.

Close all windows.

Lock the glove box.

Lock all the doors except the driver's.

If your vehicle has a remote keyless entry system,
take the transmitter with you.

2-27
Content Theft-Deterrent
(If Equipped)
The vehicle may have a theft-deterrent alarm system.
A red light located on top of the instrument panel
(toward the center of the vehicle, near the windshield)
will flash slowly when the system is armed.While armed, the doors will not unlock with the power
door lock switch. The alarm will sound if someone
tampers with the trunk lock, enters the vehicle (without
using the remote keyless entry transmitter or key to
unlock the doors), or turns the ignition on. The horn
will sound and the headlamps will flash for up to
two minutes. The system will also cut off the fuel
supply, preventing the vehicle from being driven.
Arming with the Power Lock Switch
Your alarm system can be programmed to arm when you
use either power lock switch to lock the doors while any
door is open and the key is removed from the ignition.
If you would like to arm the system with the power lock
switch, see ªMultifunction Alarm Locks and Lighting
Choicesº in the Index. The red light flashes quickly to
let you know when the system is ready to arm with the
power door lock switches. When you press the rear of
the power lock switch, the red light will stop flashing
and stay on to let you know the system is arming.
After all doors are closed and locked, the red light will
begin flashing at a very slow rate to let you know the
system is armed.

2-28 Arming with the Remote Keyless
Entry Transmitter
The alarm system will arm when you use the remote
keyless entry transmitter to lock the doors after the key
is removed from the ignition. The red light will turn on
to let you know the system is arming. After all doors are
closed and locked, the red light will begin flashing at a
very slow rate to let you know the system is armed.
Arming Confirmation
If the remote unlock confirmation is on (see ªLocks
and Lighting Choicesº in the Index), the headlamps
will flash briefly to let you know when the alarm system
has armed.
Disarming with the Remote Keyless
Entry Transmitter
The alarm system will disarm when you use the
remote keyless entry transmitter to unlock the doors.
The red light will stop flashing to let you know the
system is disarmed.
Disarming with the Key
The alarm system will disarm when you use the key to
unlock the doors. The red light will stop flashing when
the system is disarmed. If you would like the key to
disarm the alarm system, see ªLocks and Lighting
Choicesº in the Index.
PASS-Key
III
Your vehicle is equipped
with the PASS
-Key III
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key III is a passive
theft
-deterrent system. This
means you don't have to do
anything different to arm or
disarm the system. It works
when you insert or remove
the key from the ignition.
Your PASS
-Key III system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.

2-54
Interior Lamps
Instrument Panel Intensity Control
You can brighten or dim
the instrument panel lights
by turning the interior
lamps thumbwheel.
Turn the thumbwheel to the right to increase the
brightness of the instrument panel lights and to the
left to decrease the brightness. Turn the thumbwheel
completely to the left to turn them off.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave the vehicle at night. You can also turn
these lamps on by turning the interior lamps
thumbwheel completely to the right.
Illuminated Entry
The illuminated entry feature will light the interior of
the vehicle so that you can see the inside of the vehicle
before you enter at night. The interior lamps will come
on for 40 seconds when you unlock the doors using the
remote keyless entry transmitter (if equipped) and the
ignition is in LOCK or OFF. After 40 seconds have
elapsed, the interior lamps will slowly fade out. The
lamps will fade out before 40 seconds have elapsed if
you do the following:

Lock all doors using the remote keyless entry
transmitter (if equipped).

Lock the doors using the power door lock switch.
When any door is opened, illuminated entry is canceled.
The interior lamps will stay on while any door is opened
and slowly fade out when all doors are closed. The
interior lamps may stay on for up to 25 seconds after all
doors have been closed if they have not been locked.
See ªDelayed Illuminationº later in this section.

2-55 Delayed Illumination
The delayed illumination feature will continue to light
the interior of the vehicle for 25 seconds after all the
doors have been closed so that you can find the ignition
and buckle the seat belt at night. Delayed illumination
will not occur while the ignition is in RUN or
ACCESSORY. After 25 seconds have elapsed, the
interior lamps will slowly fade out. The lamps will
fade out before the 25 seconds have elapsed if you do
the following:

Turn the ignition to RUN or ACCESSORY.

Lock all doors using the remote keyless entry
transmitter (if equipped).

Lock the doors using the power door lock switch.
To turn delayed illumination feature off or on, see
ªLocks and Lighting Choicesº in the Index.
Delayed Exit Lighting
For exiting the vehicle at night, the vehicle is equipped
with the delayed exit lighting feature. The interior lamps
will illuminate for up to 25 seconds when you remove
the key from the ignition. After 25 seconds have
elapsed, the interior lamps will slowly fade out.
The lamps will fade out before the 25 seconds have
elapsed if you:

Insert the key and turn the ignition to RUN
or ACCESSORY.

Lock all doors using the remote keyless entry
transmitter (if equipped).

Lock the doors using the power door lock switch.
When any door is opened, delayed exit lighting is
canceled. The interior lamps will stay on while any door
is opened and will slowly fade out when all the doors
are closed. The interior lamps may stay on for up to
25 seconds after all the doors have been closed if they
have not been locked. See ªDelayed Illuminationº
earlier in this section.
To turn the delayed exit lighting feature off or on,
see ªLocks and Lighting Choicesº in the Index.

6-68
Fuse Description
1 Cooling Fan 2
2 Spare
3 Headlamps
4 Battery Main 2
5 Ignition Main 1
6 Cooling Fan 1 Fuse Description
7 Battery Main 1
8 Ignition Main 2
18 Fuel Injections
19 Spare
20 Spare
21 Mass Air Flow (MAF),
Heated Sensors, Canister Purge,
Boost Solenoid
22 Spare
23 Spare
24 Spare
25 Ignition Module
26 Spare
27 Trunk Release, Back
-Up Lamps
28 AC Clutch, ABS Ignition
29 Remote Keyless Entry,
Theft
-Deterrent, Shock Sensor,
Trip Computer, HVAC Module,
Security LED
