2001 PONTIAC GRAND AM clock

3-17
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a cassette
tape or compact disc is playing. If the cassette tape or
compact disc player is playing, play will stop for the
announcement and resume when the announcement
is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
ALTERNATE FREQUENCY: This RDS feature
allows the radio to switch frequencies to the best quality
station with the same programming. AF is off by
default from the factory. Press and hold AM FM for
two seconds to turn alternate frequency on or off.
AF ON or AF OFF will appear on the display and the
radio will beep once. The radio will not switch to other
stations when AF is off.Adjusting the Speakers
BAL FADE: This button adjusts balance and fade.
To adjust balance, press this button until BAL appears
on the display. SELECT will appear on the display to
show that the speakers can be adjusted. Turn the
SELECT knob clockwise for the right speakers and
counterclockwise for the left speakers. The middle
position balances the sound between the speakers. To
adjust fade, press this button until FAD appears on the
display. Turn the SELECT knob clockwise to adjust the
sound to the front speakers and counterclockwise for the
rear speakers. The middle position balances the sound
between the speakers. Press and hold this button for
two seconds to return both fade and balance to the
middle position.
Playing a Compact Disc
With the ignition on, insert a disc partway into the slot,
label side up. The player will pull it in and the disc
should begin playing. If you want to insert a CD when
the ignition is off, first press the eject symbol or the
RCL knob.

3-20
Playing the Radio
PWR VOL: Press this knob to turn the system on and
off. To increase volume, turn the knob clockwise. Turn
it counterclockwise to decrease volume.
SCV: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV,
your audio system adjusts automatically to make up
for road and wind noise as you drive. Set the volume
at the desired level. Press this button to select MIN,
MED or MAX. Each choice allows for more volume
compensation at faster vehicle speeds. Then, as you
drive, SCV automatically increases the volume, as
necessary, to overcome noise at any particular speed.
The volume level should always sound the same to you
as you drive. If you don't want to use SCV, select OFF.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK: Press the up or down arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking. The radio will seek to stations with
a strong signal only.SCAN: Press and hold one of the SEEK arrows for
two seconds until the SCAN icon appears on the display
and you hear a beep. Use SCAN to listen to stations for
a few seconds. The radio will go to a station, stop for a
few seconds, then go on to the next station. Press one of
the SEEK arrows again to stop scanning. The sound will
mute while scanning. The radio will scan to stations
with a strong signal only.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press EQ to select the equalization.
5. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered button, the station you set will return and
the equalization that you selected will also be
automatically selected for that button.
6. Repeat the steps for each pushbutton.

3-21
PRESET SCAN: Press and hold one of the SEEK
arrows for more than four seconds until the PSCAN icon
and the preset number appear on the display. You will
hear a double beep. Use PRESET SCAN to listen to
each of your preset stations for a few seconds. The radio
will go to the first preset station stored on your
pushbuttons, stop for a few seconds, then go on to the
next preset station. Press one of the SEEK arrows again
to stop scanning presets.
PRESET SCAN will skip over presets where no station
is being received at that time to prevent hearing static.
Setting the Tone
TONE: Press and release this button until the desired
tone control (BASS, MID or TREB) is found. The
SELECT LED indicator will light to show that the tone
control can be adjusted. When using BASS or MID, turn
the SELECT knob clockwise to increase bass. Turn it
counterclockwise to decrease bass. When using TREB,
turn the SELECT knob clockwise to increase treble.
Turn it counterclockwise to decrease treble. If a station
is weak or noisy, you may want to decrease the treble.
To set all of the tone controls to the middle position,
press and hold TONE until FLAT appears on the display.EQ: This feature allows you to choose preset bass, mid
and treble equalization settings designed for different
individual listening tastes. Press EQ to select the desired
preset equalization setting. Each time you press EQ,
another setting will appear on the display.
You can preset up to six equalization settings by
performing the following steps:
1. Turn the radio on.
2. Use the TONE button and the SELECT knob to
select the desired equalization.
3. Press and hold EQ for two seconds. SELECT EQ #
will appear on the display. The EQ icon will flash.
4. Press EQ or turn the SELECT knob to select the
desired EQ number. Each time you press EQ or turn
the SELECT knob, another EQ setting will appear on
the display.
5. Press and hold the EQ button or push the SELECT
knob to store the equalization preset. You will hear a
beep and EQ SAVED will appear on the display.
6. Repeat the steps for each EQ setting.
EQ 5 has been programmed for use with talk radio, but
it can be preset to a different tone.

3-24
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite Program Types (PTYs).
These buttons have factory PTY presets. You can set up
to 12 PTYs (six FM1 and six FM2) by performing the
following steps:
1. Press AM FM to select FM1 or FM2.
2. Press PROG TYPE, if it is not already on.
3. Turn the SELECT knob to select a PROG
-TYPE.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, with the SELECT LED and P
-TYPE icon
indicator on the PTY you set will return.
5. Repeat the steps for each pushbutton.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a cassette
tape or compact disc is playing. If the cassette tape or
compact disc player is playing, play will stop for the
announcement and resume when the announcement
is finished.This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
ALTERNATE FREQUENCY: This RDS feature
allows the radio to switch frequencies to the best quality
station with the same programming. AF is off by
default from the factory. Press and hold AM FM for
two seconds to turn alternate frequency on or off.
AF ON or AF OFF will appear on the display and the
radio will beep once. The radio will not switch to other
stations when AF is off.
Adjusting the Speakers
BAL FADE: This button adjusts balance and fade. To
adjust balance, press this button until BAL appears on the
display. SELECT will appear on the display to show that
the speakers can be adjusted. Turn the SELECT knob
clockwise for the right speakers and counterclockwise for
the left speakers. The middle position balances the sound
between the speakers. To adjust fade, press this button
until FAD appears on the display. Turn the SELECT knob
clockwise to adjust the sound to the front speakers and
counterclockwise for the rear speakers. The middle
position balances the sound between the speakers. Press
and hold this button for two seconds to return both fade
and balance to the middle position.

3-25
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on, but the radio is off, the
tape can be inserted and will begin playing. If you hear
nothing but a garbled sound, the tape may not be in
squarely. Press the eject symbol to remove the tape and
start over.
While the tape is playing, use the VOL, FAD, BAL,
TREB, MID, BASS, EQ, SEEK and SCAN controls just
as you do for the radio. The display will show TAPE and
an arrow showing which side of the tape is playing. The
tape player automatically begins playing the other side
when it reaches the end of the tape.
Your tape bias is set automatically when a metal or
chrome tape is inserted. If you want to insert a tape
when the ignition is off, first press the cassette eject
symbol or the RCL knob.
If an error appears on the radio display, the tape won't
play because of an error.
TIGHT TAPE is displayed when the tape is tight and
the player can't turn the tape hubs. Remove the tape.Hold the tape with the open end down and try to turn the
right hub counterclockwise with a pencil. Turn the tape
over and repeat. If the hubs do not turn easily, your
tape may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.
BROKEN TAPE is displayed when the tape is broken.
Try a new tape.
WRAPPED TAPE is displayed when the tape is
wrapped around the tape head. Attempt to get the
cassette out. Try a new tape.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.


(1): Press this button to advance quickly to another
part of the tape. Press the button again to return to
playing speed. The radio will play the last selected
station while the tape advances. You may select stations
during FWD operation by using TUNE.
While in FWD mode the display will show FREQ and
FWD and two right arrows. If the radio is playing a
RDS station the display will show the station name and
two right arrows.

4-12 Steering in Emergencies
There are times when steering can be more effective
than braking. For example, you come over a hill and
find a truck stopped in your lane, or a car suddenly pulls
out from nowhere, or a child darts out from between
parked cars and stops right in front of you. You can
avoid these problems by braking
-- if you can stop
in time. But sometimes you can't; there isn't room.
That's the time for evasive action
-- steering around
the problem.
Your vehicle can perform very well in emergencies like
these. First apply your brakes. See ªBraking in
Emergenciesº earlier in this section. It is better to
remove as much speed as you can from a possible
collision. Then steer around the problem, to the left or
right depending on the space available.
An emergency like this requires close attention and a
quick decision. If you are holding the steering wheel at
the recommended 9 and 3 o'clock positions, you can
turn it a full 180 degrees very quickly without removing
either hand. But you have to act fast, steer quickly, and
just as quickly straighten the wheel once you have
avoided the object.
The fact that such emergency situations are always
possible is a good reason to practice defensive driving at
all times and wear safety belts properly.

5-14
NOTICE:
In cold weather, water can freeze and crack the
engine, radiator, heater core and other parts.
So use the recommended coolant.
CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol
and it will burn if the engine parts are hot
enough. Don't spill coolant on a hot engine.
1. You can remove the coolant surge tank pressure cap
when the cooling system, including the coolant surge
tank pressure cap and upper radiator hose, is no
longer hot. Turn the pressure cap slowly
counterclockwise (left) about two or two and
one
-half turns. If you hear a hiss, wait for that to
stop. This will allow any pressure still left to be
vented out the discharge hose.

5-19 Removing the Spare Tire and Tools
The equipment you'll
need is in the trunk.
1. Pull the carpeting from the floor of the trunk.
2. Turn the center retainer nut on the compact spare
tire cover counterclockwise to remove it. Lift and
remove the cover. See ªCompact Spare Tireº later
in this section for more information about the
compact spare.
3. Turn the wing nut
counterclockwise and
remove it. Then lift off
the spacer and remove
the compact spare tire.
4. Remove the jack and wheel wrench from the trunk.
Your vehicle's jack and wheel wrench are stored in
a foam tray. Remove the band around the jack.
