2001 PONTIAC BONNEVILLE stop start

2-76
When the ignition is on, the brake system warning light
will also come on when you set your parking brake. The
light will stay on if your parking brake doesn't release
fully. If you try to drive off with the parking brake set, a
chime will also come on until you release the parking
brake. If the light stays on after your parking brake is
fully released, it means you have a brake problem.
If you have the optional Driver Information Center (DIC),
a PARK BRAKE SET message will be displayed while
the park brake is set.
Anti-Lock Brake System Warning Light
United States CanadaWith the anti
-lock brake system, the light(s) will come
on when your engine is started and may stay on for
five seconds. That's normal.
If the light stays on, turn the ignition to OFF. Or, if the
light comes on when you're driving, stop as soon as
possible and turn the ignition off. Then start the engine
again to reset the system. If the light still stays on, or
comes on again while you're driving, your vehicle needs
service. If the regular brake system warning light isn't
on, you still have brakes, but you don't have anti
-lock
brakes. If the regular brake system warning light is also
on, you don't have anti
-lock brakes and there's a
problem with your regular brakes. See ªBrake System
Warning Lightº earlier in this section.
The anti
-lock brake system warning light should come
on briefly when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.

2-81
This light should come on, as a check to show you it is
working, when the ignition is on and the engine is not
running. If the light doesn't come on, have it repaired.
This light will also come on during a malfunction in one
of two ways:

Light Flashing
-- A misfire condition has been
detected. A misfire increases vehicle emissions and
may damage the emission control system on your
vehicle. Dealer or qualified service center diagnosis
and service may be required.

Light On Steady
-- An emission control system
malfunction has been detected on your vehicle.
Dealer or qualified service center diagnosis and
service may be required.
If the Light Is Flashing
The following may prevent more serious damage to
your vehicle:

Reducing vehicle speed.

Avoiding hard accelerations.

Avoiding steep uphill grades.

If you are towing a trailer, reduce the amount of
cargo being hauled as soon as it is possible.If the light stops flashing and remains on steady, see
ªIf the Light Is On Steadyº following.
If the light continues to flash, when it is safe to do so,
stop the vehicle. Find a safe place to park your vehicle.
Turn the key off, wait at least 10 seconds and restart the
engine. If the light remains on steady, see ªIf the Light
Is On Steadyº following. If the light is still flashing,
follow the previous steps, and drive the vehicle to your
dealer or qualified service center for service.
If the Light Is On Steady
You may be able to correct the emission system
malfunction by considering the following:
Did you recently put fuel into your vehicle?
If so, reinstall the fuel cap, making sure to fully install
the cap. See ªFilling Your Tankº in the Index. The
diagnostic system can determine if the fuel cap has been
left off or improperly installed. A loose or missing fuel
cap will allow fuel to evaporate into the atmosphere. A
few driving trips with the cap properly installed should
turn the light off.

2-92
GM Oil Life System
: Press the SELECT button
until OIL LIFE appears in the display. The OIL LIFE
NORMAL display will show an estimate of the oil's
remaining useful life. When the oil life index is less than
10%, an ENGINE OIL CHANGE SOON message will
be displayed and the oil life display will show OIL LIFE
CHANGE. When you have the oil changed according to
the maintenance schedule, you will have to reset the Oil
Life System. To reset the Oil Life System, see ªOil Life
Systemº in the Index. Also, see ªEngine Oil, When to
Changeº and ªMaintenance Scheduleº in the Index.
Tire Pressure Status: Press the SELECT button until
TIRE PRESSURE appears in the display. TIRE
PRESSURE NORMAL is displayed when the Check
Tire Pressure System believes your vehicle's tire
pressures are normal. If a potential problem is detected,
the display will show CHECK TIRE PRESSURE and
the tire pressure status will show TIRE PRESSURE
LOW. If you see the CHECK TIRE PRESSURE
message, you should stop as soon as you can and check
all your tires for damage. (If a tire is flat, see ªIf a Tire
Goes Flatº in the Index.) Also check the tire pressure in
all four tires as soon as you can. See ªInflation
-- Tire
Pressureº and ªCheck Tire Pressure Systemº in
the Index.
DIC Warnings and Messages
Other messages or warnings may appear in the DIC display.
For Canadian drivers, in addition to the DIC message your
DIC will display EXP with a number after it which reflects
the following messages:
EXP (Export ID) Warning Message
3 SERVICE VEHICLE SOON. . . . . . . . . . . . . . . . .
9 CHECK GAGES VOLT. . . . . . . . . . . . . . . . . . . . .
11 CHECK GAGES LOW FUEL. . . . . . . . . . . . . . .
16 ENGINE HOT A/C DISABLED. . . . . . . . . . . . .
20 TURN SIGNAL ON?. . . . . . . . . . . . . . . . . . . . . .
24 TRUNK AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
25 WASHER FLUID LOW. . . . . . . . . . . . . . . . . . . .
27 BATTERY SAVER ACTIVE. . . . . . . . . . . . . . . .
33 STARTING DISABLED
- THEFT * . . . . . . . . . .
34 SERVICE THEFT SYSTEM. . . . . . . . . . . . . . . .
35 CHECK GAGES OIL PRESSURE *. . . . . . . . . .
36 OIL LEVEL LOW. . . . . . . . . . . . . . . . . . . . . . . .
37 BRAKE FLUID LOW *. . . . . . . . . . . . . . . . . . . .
40 ALARM OCCURRED. . . . . . . . . . . . . . . . . . . . .
44 CHECK GAGES TEMPERATURE *. . . . . . . . .
54 SERVICE STABILITY SYSTEM. . . . . . . . . . . .
55 STABILITY SYSTEM ACTIVE. . . . . . . . . . . . .
61 CHECK GAS CAP. . . . . . . . . . . . . . . . . . . . . . . .

2-93
EXP (Export ID) Warning Message
81 ENGINE OIL CHANGE SOON. . . . . . . . . . . . .
83 SERVICE AIR BAG. . . . . . . . . . . . . . . . . . . . . . .
102 CHECK CHARGE SYSTEM. . . . . . . . . . . . . . .
140 DRIVER DOOR AJAR. . . . . . . . . . . . . . . . . . .
141 FRONT PASSENGER DOOR AJAR. . . . . . . .
142 LEFT REAR DOOR AJAR. . . . . . . . . . . . . . . .
143 RIGHT REAR DOOR AJAR. . . . . . . . . . . . . . .
144 CHECK TIRE PRESSURE. . . . . . . . . . . . . . . .
147 PARK BRAKE SET *. . . . . . . . . . . . . . . . . . . .
The EXP codes are used to make translation from
English to other languages easier.
Pressing any of the DIC control buttons will remove the
above messages or warnings from the DIC display,
unless noted by an asterisk (*).
SERVICE STABILITY SYSTEM
- 54: If you ever
see the SERVICE STABILITY SYSTEM message, it
means there may be a problem with your stability
enhancement system. If you see this message, try to
reset the system (stop; turn off the engine; then start the
engine again). If the SERVICE STABILITY SYSTEM
message still comes on, it means there is a problem. You
should see your dealer for service. Reduce your speed
and drive accordingly.STABILITY SYSTEM ACTIVE
- 55: You may see
the STABILITY SYSTEM ACTIVE message on the
Driver Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates
when the computer senses that your vehicle is just
starting to spin, as it might if you hit a patch of ice or
other slippery spot on the road. When the system is on,
you may hear a noise or feel a vibration in the brake
pedal. This is normal.
When the STABILITY SYSTEM ACTIVE message is
on, you should continue to steer in the direction you
want to go. The system is designed to help you in bad
weather or other difficult driving situations by making
the most of whatever road conditions will permit. If the
STABILITY SYSTEM ACTIVE message comes on,
you'll know that something has caused your vehicle to
start to spin, so you should consider slowing down.
Tire Pressure Status
- 144: If you see the CHECK
TIRE PRESSURE message, you should stop as soon as
you can and check all your tires for damage. (If a tire is
flat, see ªIf a Tire Goes Flatº in the Index.) Also check
the tire pressure in all four tires as soon as you can. See
ªInflation
- Tire Pressureº and ªCheck Tire Pressure
Systemº in the Index.

3-6
Automatic Operation
When the system is set for AUTO, your climate control
system will control the air delivery mode, fan speed, A/C
and RECIRC operations. Air will come from the floor,
panel or windshield outlets. The fan speed will vary as the
system maintains the selected temperature setting.
When AUTO is selected, the A/C operation and air inlet
will be automatically controlled. The air conditioning
compressor will run at outside temperatures over
approximately 40
F (4
C). The air inlet will normally
be set to outside air. If it's hot outside, the air inlet will
automatically switch to recirculated inside air to help
quickly cool down your vehicle.
To find your comfort zone, start with 75
F (24
C)
temperature setting and allow about 20 minutes for the
system to regulate. Turn the TEMP knob up or down to
adjust the temperature setting if necessary. If you choose
the temperature setting of 60
F (15
C), the system will
remain at the maximum cooling setting and fan speed. If
you choose the temperature setting of 90
F (33
C), the
system will remain at the maximum heat setting and fan
speed. Choosing either maximum setting will not cause
the system to heat or cool any faster.Be careful not to cover the sensor located on the top of
the instrument panel near the windshield. This sensor
regulates temperature based on sun load.
The EXT (exterior) temperature sensor is located in
the front of the vehicle behind the grille. The displayed
temperature is most accurate after the vehicle has been
moving for a few minutes. If the vehicle is stopped and
then restarted within 2 1/2 hours, the sensor will be hot
from the engine heat. In this case, the temperature first
displayed will continue to be the previous temperature.
The display will update after the vehicle has been
moving for a few minutes and the sensor has a chance
to cool down to the actual temperature.
To avoid blowing cold air in cold weather, the system
will delay turning on the fan until warm air is available.
The length of delay depends on engine coolant
temperature. Pushing the fan button will override
this delay and change the fan to a selected speed.

3-26


(1): Press and hold this button to advance quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
RDM (3): Press this button to hear the tracks in random,
rather than sequential, order. RDM and the track number
will appear on the display.
 (4): Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
EQ: Press EQ to select the desired preset equalization
setting while playing a compact disc. The equalization
will be automatically set whenever you play a
compact disc.
SEEK: Press the down arrow while playing a CD to
go to the start of the current track if more than eight
seconds have played. Press the up arrow to go to the
next track. If you hold the button or press it more than
once, the player will continue moving backward or
forward through the disc.SCAN: Press and hold one of the SEEK arrows for
more than two seconds until SCAN appears on the
display and you hear a beep. Use SCAN to listen to each
selection for a few seconds. The disc will go to the next
selection, stop for a few seconds, then go on to the next
selection. Press this button again to stop scanning. The
sound will mute while scanning. SCAN and the track
number will appear on the display.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes. While elapsed time is showing,
CD TIME will appear on the display.
AM FM: Press this button to play the radio when a disc
is in the player.

3-34
SCAN: Press and hold one of the SEEK arrows for
more than two seconds until SCAN appears on the
display and you hear a beep. Use SCAN to listen to each
selection for a few seconds. The tape will go to the next
selection, stop for a few seconds, then go on to the next
selection. Press this button again to stop scanning. The
sound will mute and SCAN will appear on the display
while scanning. The tape will scan in forward only.
AM FM: Press this button to play the radio when a tape is
in the player. The tape will stop but remain in the player.
CD TAPE: With a compact disc in the player and the
radio playing, press this button to play a compact disc.
Press AM FM to return to the radio when a compact disc
is playing. Press CD TAPE to switch between the tape and
compact disc if both are loaded. The inactive tape or
CD will remain safely inside the radio for future listening.
The display will show tape and CD icons. If you have the
optional CD changer and the CD changer is loaded, the
CD
-TAPE button will activate the changer and an icon
will be lit in the display.
: Press this button to remove the tape. The radio will
play. Eject may be activated with either the ignition or
radio off. Cassettes may be loaded with the radio and
ignition off if this button is pressed first.CLEAN PLAYER: If this message appears on the
display, the cassette tape player needs to be cleaned.
It will still play tapes, but you should clean it as soon as
possible to prevent damage to the tapes and player. See
ªCare of Your Cassette Tape Playerº in the Index. After
you clean the player, press and hold the eject button for
five seconds to reset the CLEAN PLAYER indicator.
The radio will display CLEANED to show the indicator
was reset.
Playing a Compact Disc
With the ignition on, insert a disc partway into the slot,
label side up. The player will pull it in and the disc should
begin playing. If you want to insert a CD when the
ignition is off, first press the eject button or the RCL knob.
Inserting a CD with the radio off and the ignition on will
start auto play.
When the disc is inserted, the CD symbol will be
displayed. If you select an EQ setting for your CD, it
will be activated each time you play a CD.
As each new track starts to play, the track number will
appear on the display.

3-35
If CHECK CD appears on the radio display and the disc
comes out, it could be that:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.


(1): Press and hold this button to advance quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
RDM (3): Press this button to hear the tracks in random,
rather than sequential, order. RDM and the track number
will appear on the display.
 (4): Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.EQ: Press EQ to select the desired preset equalization
setting while playing a compact disc. The equalization
will be automatically set whenever you play a
compact disc.
SEEK: Press the down arrow while playing a CD to
go to the start of the current track if more than eight
seconds have played. Press the up arrow to go to the
next track. If you hold the button or press it more than
once, the player will continue moving backward or
forward through the disc.
SCAN: Press and hold one of the SEEK arrows for
more than two seconds until SCAN appears on the
display and you hear a beep. Use SCAN to listen to each
selection for a few seconds. The disc will go to the next
selection, stop for a few seconds, then go on to the next
selection. Press this button again to stop scanning. The
sound will mute while scanning. SCAN and the track
number will appear on the display.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes. While elapsed time is showing,
CD TIME will appear on the display.
