9YOUR AT A GLANCE
STEERING WHEEL HEIGHT ADJUSTMENT Lower the lever to release the steering wheel. Adjust to the required height and raise the lever to lock the stee-ring wheel. OPENING THE BONNET Inside the vehicle:
pull the
handle. Outside the vehicle: lift the catch
and lift the bonnet. Secure the strut to hold the bonnet open.
8271

YOUR 206 CC IN DETAIL65
CHILD SEATS Child safety was one of PEUGEOT's main concerns when designing your vehicle; however the safety of your children also depends on you.
For maximum safety, please observe the following precautions:
- All children under the age of 10 are required to travel in approved restraining devices*, suited to their weight, in the seats
fit-
ted with seat belts.
- front passenger seat*: children under the age of 10 must not be transported in the "forwards facing" position, unless the rear seats are already occupied by other children. In this case adjust the front passenger seat to the mid-position. The "rear fac -
ing" position is permitted when the air bag is disarmed.
After carrying out numerous tests, PEUGEOT recommends the following systems: Up to 18 months (to 29 lbs or 13 kg) "Ršmer Babysure": is installed with its back to the engine and secured with a three-point seat belt, on either the front or rea r
seat. In the front the passenger seat must be adjusted to the "mid-position".
From 9 months to 3 or 4 years (20 to 40 lbs or 9 to 18 kg) "Ršmer Prince": is fitted to the rear seat with a three-point seat belt.For the safety of your children, the seat and the restraining cushion must never be separated.
From 3 to 6 years (33 to 55 lbs or 15 to 25 kg) "Ršmer Vario": is fitted to the rear seat with a three-point seat belt.
1
2
3

YOUR 206 CC IN DETAIL71
Bonnet strut Secure the strut to hold the bonnet open. Before closing the bonnet, replace the strut in its housing.
To close Lower the bonnet and release it at the end of its travel. Check that the bonnetis locked.
Opening the bonnet Inside the vehicle:
pull the handle on
the left- hand side, under the fascia. Outside the vehicle: lift the catch and
raise the bonnet. Filling the fuel tank The tank must be filled with fuel with the engine switched off
.
Insert the key then turn it to the left. Remove the cap.
A label indicates which type of fuel to use. If you fill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehiclemalfunctions. The capacity of the tank is approxi- mately 10.3 gallons (47 litres).

YOUR 206 CC IN DETAIL
84
Glove compartment The glove compartment is fitted with a lock.
To open the glove compartment, lift the handle. The light comes on when the lid is opened. 1.
Vehicle document folder storage
2. Cup holder
3. Pen holder
4. Spectacles storage
5. Map storage
6. Coin storage Bottle holder
A bottle holder is fitted between the two rear seat backs.
To open it, pull the top of the cover. Lashing rings Use the 4 lashing rings on the luggage compartment floor secure your lug-gage.

PRACTICAL ASPECTS OF YOUR VEHICLE95
Punctures Because this version does not pos- sess a spare wheel, you have twoaerosols for temporary tyre repairsstored in an insulated storage box
1
secured by a strap to the right-handside of the boot. Using a repair aerosol (See also the instructions on the aerosols).
If possible remove the foreign body which caused the puncture.
 Position the wheel so that the valve
is at the 2 o'clock or 10 o'clock posi-tion.
 Shake the aerosol vigorously befo-
re use. (In very cold weather, warmthe aerosol for a few minutes in yourhands).
 In one hand hold the valve.
 With the other, firmly push the end
of the aerosol tube onto the valve,keeping the aerosol centralised.
 Maintain the pressure firmly for one
minute, then immediately drive at
moderate speed to the nearest
garage. Aersosols enable a tempo-rary repair to be carried out(maximum speed 50 mph(80 km/hour)).
After use, it is necessary to replacethe tyre. Because the aerosols are pres- surised, they must not be exposedto a temperature higher than 50¡C. Keep them away from heat in their insulated storage box.

PRACTICAL ASPECTS OF YOUR VEHICLE99
Ð Pull the tab
Aupwards and remove the protective cover.
Ð Disconnect the connector.
Ð Press the end of the securing clip to remove it. Change the faulty bulb.
Ð On fitting, ensure that the direction notches are in the cor- rect position and that the clip is secured correctly.
Ð Reconnect the connector.
Ð Replace the protective cover. Remarks
Ð Only touch the bulbs with a dry cloth.
Ð To replace the bulbs on the right side, remove the wash- wipe reservoir filler pipe first.
Ð Condensation may form inside the headlamps. It will dis- appear when the lights are used.
Changing a bulb Dipped/main headlamps H7 55WSide lights W5W
Turn the pin connector B a quarter turn and remove it.
Change the bulb.

PRACTICAL ASPECTS OF YOUR VEHICLE101
Rear lights Release the top of the boot side trim. Unscrew the wing bolt inside the boot
using the wheelbrace if necessary. Disconnect the connector
A.
Release the light unit.Release spanner B from the bulb hol-
der.Unscrew nut Cusing spanner B and
removet the bulb holder.Change the faulty bulb.When refitting, stow spanner B on
support D and refit the light .
1. Amber direction indicators
PY21W.
2. Reversing lights P21W.
3. Brake lights/side lights P21/5W.Front fog lamps H1 55W Press underneath the access flap to release it. Open the flap.
Turn the cover to remove it.Disconnect the bulb.Press both ends of the securing clip to release the bulb.
The ÒamberÓ bulbs must be replaced by bulbs of identi-
cal specification and colour.
