2001 Oldsmobile Silhouette Setting clock

3-12
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). This will
allow the heater and defroster to work much better,
reducing the chance of fogging the inside of
your windows.

When you enter a vehicle in cold weather, turn the
fan knob to ª5º, the highest setting, for a few
moments before driving off. This helps clear the
intake ducts of snow and moisture, and reduces
the chance of fogging the inside of your windows.

Keep the area around the base of the center
instrument panel console and the air path under the
front seats clear of objects. This helps air to circulate
throughout your vehicle.

In cold weather, operating the system in the
OUTSIDE AIR mode will improve the time it
takes to warm the vehicle.Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.
Setting the Clock
Press and hold the HR or MN buttons, located below the
tune knob, for two seconds. Then press and hold HR until
the correct hour appears. AM or PM will appear on the
display. Press and hold MN until the correct minute appears.
The clock may be set with the ignition on or off. The clock
symbol will appear on the display in time
-set mode.
Press and hold the H button until the correct hour
appears. AM will appear on the display for morning
hours.Press and hold the M button until the correct
minute appears. The clock may be set with the ignition
on or off.
To set the clock to the time of an FM station broadcasting
Radio Data System (RDS) information, press and hold
HR and MN or the H and M buttons at the same time
for two seconds until UPDATED and the clock symbol
appear on the display. If the time is not available from the
station, NO UPDAT will appear on the display instead.

3-13 AM-FM Stereo with Compact Disc Player
with Radio Data System (RDS) and
Automatic Tone Control
Playing the Radio
PWR: Press this button to turn the system on and off.
VOL: Turn this knob clockwise to increase volume.
Turn it counterclockwise to decrease volume.
DISP: Press this button to display the clock with the
ignition off.AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV,
your audio system adjusts automatically to make up for
road and wind noise as you drive. Set the volume at the
desired level. Press AUTO VOL to adjust the SCV.
AVOL will appear on the display. Each time you press
AUTO VOL, another volume setting (LOW, MEDIUM
or HIGH) will appear on the display. NONE will appear
on the display if the radio cannot find out the vehicle
speed. Then, as you drive, SCV automatically increases
the volume, as necessary, to overcome noise at any
particular speed. The volume level should always sound
the same to you as you drive. If you don't want to use
SCV, select OFF. Each volume setting allows for more
volume compensation at faster vehicle speeds.
Finding a Station
AM FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there.

3-14
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to select the equalization that
best suits the type of station selected.
5. Press and hold one of the six numbered buttons.
The radio will produce one beep. Whenever you
press that numbered button, the station you set
will return and the auto tone equalization that you
selected will also be automatically selected for
that button.
6. Repeat the steps for each pushbutton.
P SCAN: Press and hold one of the arrows for more
than two seconds. The radio will produce one beep.
Use P SCAN to listen to each of your favorite stations
stored on your pushbuttons for a few seconds.The radio will scan through each of the stations stored
on your pushbuttons, except those stations with
weak reception. The auto tone setting stored for that
pushbutton will be automatically chosen. Press P SCAN
or one of the pushbuttons again to stop scanning.
SCAN will be displayed whenever the tuner is in the
P SCAN mode. The channel number (P1 through P6)
will appear with the frequency. In FM mode, this
function will scan through the current band such as
FM1 or FM2.
Setting the Tone
BASS: Press and release the P
-TYPE LIST/AUDIO
knob until BASS appears on the display. Then turn the
knob clockwise to increase bass and counterclockwise
to decrease bass. The display will show the bass level.
When you use this control, the radio's auto tone setting
will switch to manual and the auto tone display will go
blank. To set the tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST/AUDIO
knob when no tone or speaker control is active.
The radio will produce one beep and display ALL
with the level display in the middle position.

3-15
TREB: Press and release the P-TYPE LIST/AUDIO
knob until TREB appears on the display. Turn the knob
clockwise to increase treble and counterclockwise to
decrease treble. The display will show the treble level.
When you use this control, the radio's auto tone setting
will switch to manual and the auto tone display will go
blank. If a station is weak or noisy, you may want to
decrease the treble.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for rock,
news, pop, jazz, classic and country stations. TONE and
the preset equalization setting will appear on the display
when you press AUTO TONE. Each time you press it,
another setting will appear on the display. The manual
setting allows tone control to return to the bass and
treble controls. Use the pushbuttons and the AUTO
TONE button to program auto tone for station presets.Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the
right speakers and counterclockwise to move the sound
to the left speakers. The middle position balances the
sound between the speakers. The display will show
the speaker balance. To set the control to the middle
position, select the control and press and hold the
P
-TYPE LIST/AUDIO knob. The radio will produce
one beep and set the display level to the middle position.
FADE: Press and release the P
-TYPE LIST/AUDIO
knob until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers
and counterclockwise to move the sound to the rear
speakers. The middle position balances the sound
between the speakers. The display will show the
speaker balance.

3-20 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
System (RDS) and Automatic Tone Control
(If Equipped)
Playing the Radio
PWR: Press this button to turn the system on and off.
VOL: Turn this knob clockwise to increase volume.
Turn it counterclockwise to decrease volume.
DISP: Press this button to display the clock with the
ignition off. Press this button to display an RDS station
frequency or program type when the radio is on.AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV,
your audio system adjusts automatically to make up for
road and wind noise as you drive. Set the volume at the
desired level. Press AUTO VOL to adjust the SCV.
AVOL will appear on the display. Each time you press
AUTO VOL, another volume setting (LOW, MEDIUM
or HIGH) will appear on the display. NONE will appear
on the display if the radio cannot find out the vehicle
speed. Then, as you drive, SCV automatically increases
the volume, as necessary, to overcome noise at any
particular speed. The volume level should always sound
the same to you as you drive. If you don't want to use
SCV, select OFF. Each volume setting allows for more
volume compensation at faster vehicle speeds.
Finding a Station
AM FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there. The radio will seek to stations
with a strong signal only.

3-21
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to select the equalization that
best suits the type of station selected.
5. Press and hold one of the six numbered buttons.
The radio will beep once to confirm. Whenever you
press that numbered button, the station you set will
return and the AUTO TONE equalization that you
selected will also be automatically selected for
that button.
6. Repeat the steps for each pushbutton.
P SCAN: Press and hold one of the arrows for more
than two seconds. The radio will beep once to confirm.
Use P SCAN to listen to each of your favorite stations
stored on your pushbuttons for a few seconds. The radio will scan through each of the stations stored
on your pushbuttons, except those stations with
weak reception. The auto tone setting stored for that
pushbutton will be automatically chosen. Press P SCAN
or one of the pushbuttons again to stop scanning.
SCAN will be displayed whenever the tuner is in the
preset scan mode. The channel number (P1 through P6)
will appear with the frequency. In FM mode, this
function will scan through the current band such as
FM1 or FM2.
Setting the Tone
BASS: Press and release the P
-TYPE LIST/AUDIO
knob until BASS appears on the display. Then turn the
knob clockwise to increase bass and counterclockwise
to decrease bass. The display will show the bass level.
When you use this control, the radio's auto tone setting
will switch to manual. To set bass to the middle position,
select the control and press and hold the P
-TYPE
LIST/AUDIO knob. The radio will produce one beep
and set the display level to the middle position. To set all
tone and speaker controls to the middle position, press
and hold the P
-TYPE LIST/AUDIO knob when no
tone or speaker control is active. The radio will produce
one beep and display ALL with the level display in the
middle position.

3-22
TREBLE: Press and release the P-TYPE LIST/AUDIO
knob until TREB appears on the display. Turn the knob
clockwise to increase treble and counterclockwise to
decrease treble. The display will show the treble level.
When you use this control, the radio's auto tone setting
will switch to manual. If a station is weak or noisy, you
may want to decrease the treble. To set treble to the
middle position, select the control and press and hold the
P
-TYPE LIST/AUDIO knob. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST/AUDIO
knob when no tone or speaker control is active.
The radio will produce one beep and display ALL with
the level display in the middle position.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for rock,
news, pop, jazz, classical and country music stations.
TONE and the preset equalization setting will appear on
the display when you press AUTO TONE. Each time
you press it, another setting will appear on the display.
The manual setting allows tone control to return to the
bass and treble controls. Use the pushbuttons and the
AUTO TONE button to program the auto tone for
station presets.Adjusting the Speakers
BALANCE: Press and release the P
-TYPE
LIST/AUDIO knob until BAL appears on the display.
Turn the knob clockwise to move the sound to the right
speakers and counterclockwise to move the sound to the
left speakers. The middle position balances the sound
between the speakers. The display will show the speaker
balance. To set the balance to the middle position,
select the control and press and hold the P
-TYPE
LIST/AUDIO knob. The radio will produce one beep
and set the display level to the middle position. To set all
tone and speaker controls to the middle position, press
and hold the P
-TYPE LIST/AUDIO knob when no
tone or speaker control is active. The radio will produce
one beep and display ALL with the level display in the
middle position.
FADE: Press and release the P
-TYPE LIST/AUDIO
knob until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers
and counterclockwise to move the sound to the rear
speakers. The middle position balances the sound
between the speakers. The display will show the
speaker balance.
