²Sudden or hard accelerations may reduce fuel economy.
²Slow down gradually.
²Driving at reasonable speeds (traveling at 88 km/h [55 mph] uses 15%
less fuel than traveling at 105 km/h [65 mph]).
²Revving the engine before turning it off may reduce fuel economy.
²Using the air conditioner or defroster may reduce fuel economy.
²You may want to turn off the speed control in hilly terrain if
unnecessary shifting between third and fourth gear occurs.
Unnecessary shifting of this type could result in reduced fuel
economy.
²Warming up a vehicle on cold mornings is not required and may
reduce fuel economy.
²Resting your foot on the brake pedal while driving may reduce fuel
economy.
²Combine errands and minimize stop-and-go driving.
Maintenance
²Keep tires properly inflated and use only recommended size.
²Operating a vehicle with the wheels out of alignment will reduce fuel
economy.
²Use recommended engine oil. Refer toLubricant Specifications.
²Perform all regularly scheduled maintenance items. Follow the
recommended maintenance schedule and owner maintenance checks
found in your vehicle scheduled maintenance guide.
Conditions
²Heavily loading a vehicle or towing a trailer may reduce fuel economy
at any speed.
²Carrying unnecessary weight may reduce fuel economy (approximately
0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried).
²Adding certain accessories to your vehicle (for example bug
deflectors, rollbars/light bars, running boards, ski/luggage racks) may
reduce fuel economy.
²Using fuel blended with alcohol may lower fuel economy.
²Fuel economy may decrease with lower temperatures during the first
12±16 km (8±10 miles) of driving.
Maintenance and care
189

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety
Administration Regulations require
that a Certification Label be affixed
to a vehicle and prescribe where the
Certification Label may be located.
The Certification Label is located on
the front door latch pillar on the
driver's side.
1
4
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
Capacities and specifications
215

GAWR ......................................128
GVWR ......................................128
trailer towing ..........................128
Locks
autolock .....................................71
childproof ..................................57
Lubricant specifications ...212±213
Lumbar support, seats ...............79
M
Mirrors .........................................54
cleaning ...................................206
heated ........................................58
side view mirrors (power) .......58
Moon roof ....................................54
Motorcraft parts ................186, 210
O
Octane rating ............................185
Odometer .....................................15
Oil (see Engine oil) ..................157
Overdrive ...................................124
P
Panic alarm feature, remote
entry system ................................65
Parking brake ............................120
Parts (see Motorcraft parts) ....210
Pedals (see Power
adjustable foot pedals) ...............46
Power adjustable foot pedals .....46
Power distribution box
(see Fuses) ...............................141Power door locks ........................57
Power steering ..........................122
fluid, checking and adding ....167
fluid, refill capacity ................211
fluid, specifications .........212±213
R
Radio ............................................29
Relays ................................138, 143
Remote entry system ...........63, 65
illuminated entry ......................65
locking/unlocking doors ...........64
opening the trunk .....................64
panic alarm ...............................65
replacement/additional
transmitters ...............................65
replacing the batteries .............66
Roof rack ...................................134
S
Safety belts (see Safety
restraints) ............13, 81, 83±87, 89
Safety defects, reporting ..........230
Safety restraints ..............81, 83±90
belt minder ...............................92
cleaning the safety belts ..95, 209
extension assembly ..................91
for adults .............................84±87
for children .....................103±104
lap belt ......................................89
warning light
and chime ........................9, 13, 92
Safety seats for children ..........105
Seat belts
(see Safety restraints) ...............81
Seats ............................................77
Index
235
