2001 MERCEDES-BENZ SL-Class technical data

6 Contents
Technical data Spare parts service ........................270
Warranty coverage .........................270
Identification labels ....................... 271
Layout of poly-V-belt drive ............272
Engine ..............................................273
Rims - Tires ..................................... 274
Weights ............................................ 276
Main Dimensions ........................... 276
Fuels, coolants, lubricants etc. -
capacities ...................................277
Engine oils ......................................279
Engine oil additives .......................279
Air conditioner refrigerant ...........279
Brake fluid ......................................279
Premium unleaded gasoline ........280
Fuel requirements .........................280
Gasoline additives ......................... 281
Coolants ........................................... 281
Consumer information ..................283
Index Index ............................................... 285

13 IntroductionWhere to find it
The Operator’s Manual is divided into eight sections:
•Instruments and controls: An overview of all the controls that can be operated from the driver’s seat.
•Operation: Information on the vehicle’s equipment and its operation.
•Driving: Important information on driving.
•Instrument cluster display: Displays and indicator lamps on the instrument cluster with brief instructions.
•Practical hints: Assistance and instructions in the event of an emergency.
•Car care: Instructions on caring for your vehicle.
•Technical data: All the important technical data for your vehicle as well as consumer information such as fuels,
coolants, lubricants etc. is contained here.
•Index: Key terms to help you find a topic quickly.
Other documents may also be supplied, depending on your vehicle’s equipment.
Explanation of color used:
Warning notices for the protection of yourself and
others appear on red background.

98 Audio system
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Audio and telephone, operation
These instructions are intended to help you become
acquainted with your Mercedes-Benz vehicle radio.
They contain useful tips and a detailed description of
the user functions.
The right to correct errors and make technical amendments is
reserved.
Operating safety1 Optional equipment
Dolby and the double-D symbol
Ù
are trademarks of Dolby
Laboratories Licensing Corporation. The Dolby noise reduction
system is manufactured under licence from Dolby Laboratories
Licensing Corporation.
Wa r n i n g !
In order to avoid distraction which could lead to an
accident, system settings should be entered with
the vehicle at standstill and systems should be
operated by the driver only when traffic conditions
permit. Always pay full attention to traffic
conditions first before operating system controls
while driving. Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is covering
a distance of approximately 50 feet (approximately
14 m ) e v e r y s e c o n d .
Wa r n i n g !
Any alternations made to electronic components
can cause malfunctionsThe radio, cassette deck, CD changer
1 and
telephone
1 are interconnected. Therefore, when
one of the components is defective or has not been
removed/replaced properly this may impair the
function of other components.
These malfunctions might seriously impair the
operating safety of your vehicle.We recommend that you have any service work or
alternations on electronic components done in an
authorized Mercedes-Benz Center.

269 Contents - Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Technical data Spare parts service ........................270
Warranty coverage .........................270
Identification labels ....................... 271
Layout of poly-V-belt drive ............272
Engine ..............................................273
Rims - Tires ..................................... 274
Weights ............................................ 276
Main Dimensions ........................... 276Fuels, coolants, lubricants etc. -
capacities ................................... 277
Engine oils ...................................... 279
Engine oil additives ...................... 279
Air conditioner refrigerant .......... 279
Brake fluid ...................................... 279
Premium unleaded gasoline ........ 280
Fuel requirements ........................ 280
Gasoline additives ......................... 281
Coolants .......................................... 281
Consumer information ................. 283

270 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Spare parts service
All authorized Mercedes-Benz Centers maintain a stock
of original spare parts required for maintenance and
repair work. In addition, strategically located parts
distribution centers provide quick and reliable parts
service.
More than 300 000 different spare parts, for
Mercedes-Benz models, are available.
Mercedes-Benz original spare parts are subjected to
stringent quality inspections. Each part has been
specifically developed, manufactured or selected for and
adapted to Mercedes-Benz vehicles.
Therefore, Mercedes-Benz original spare parts should
be installed.
Important!
The use of non-genuine parts and accessories not
authorized by Mercedes-Benz could damage the vehicle
which damage is not covered by the Mercedes-Benz
Limited Warranty or compromise its durability or safety.Warranty coverage
Your vehicle is covered under the terms of the
“warranties” printed in the Service and Warranty
Information booklet and your authorized
Mercedes-Benz Center will exchange or repair any
defective parts originally installed on the vehicle in
accordance with the terms of the following warranties:
1. New vehicle limited warranty
2. Emission system warranty
3. Emission performance warranty
4. California, Massachusetts, and Vermont emission
control systems warranty
Replacement parts and accessories are covered by the
Mercedes-Benz Spare Parts and Accessories warranties,
copies of which are available at any Mercedes-Benz
Center.
Loss of Service and
Warranty Information Booklet
Should you lose your Service and Warranty Information
booklet, have your authorized Mercedes-Benz Center
arrange for a replacement. It will be mailed to you.

271 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Identification labels
1Certification label
(left door pillar)
Note:
When ordering spare parts, please specify vehicle
identification and engine numbers.2VIN, visible (lower edge of windshield)
3Vehicle Identification No. (VIN)
4Engine number
5Body number and paintwork number
6Emission control label
7Information label
California version
Vacuum line routing for emission control system

272 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Layout of poly-V-belt drive
SL 500
1Automatic belt tensioner
2Crankshaft
3Air conditioner compressor
4SL 500: Coolant pump
SL 600: FanSL 600
5Generator (alternator)
6Idler pulley
7Power steering pump
8Air pump
9Coolant pump
For dimensions of the poly-V-belts, see page 273.

273 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Technical data
Model SL 500 (129.068)
1
SL 600 (129.076)
1
Engine113 1 2 0
Mode of operation 4-stroke engine,
gasoline injection4-stroke engine,
gasoline injection
No. of cylinders 8 12
Bore 3.82 in (97.00 mm) 3.50 in (89.00 mm)
Stroke 3.30 in (84.00 mm) 3.16 in (80.20 mm)
Total piston displacement 303 cu.in. (4966 cm
3) 365.4 cu.in. (5987 cm
3)
Compression ratio 8.8:1 10:1
Output acc.
to SAE J 1349302 hp/5600 rpm
(225 kW/5600 rpm)389 hp/5200 rpm
(290 kW/5200 rpm)
Maximum torque acc.
to SAE J 1349339ft.lb/2750 rpm
(460 Nm/2750 rpm)420ft.lb/3800 rpm
(570 Nm/3800 rpm)
Maximum engine speed 6000 rpm 6000 rpm
Firing order 1-5-4-2-6-3-7-8 1-12-5-8-3-10-6-7-2-11-4-9
Poly-V-belts length 2390 mm 2585 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies
and special equipment.
