2001 MAZDA MODEL TRIBUTE transmission oil

3.0L DOHC V6 Duratec engine
1. Power steering fluid reservoir
2. Engine coolant reservoir
3. Automatic transmission fluid dipstick
4. Brake fluid reservoir
5. Air filter assembly
6. Power distribution box
7. Battery
8. Engine oil dipstick
9. Engine oil filler cap
10. Windshield washer fluid reservoir
10987
123456
Maintenance and care
164

ENGINE OIL
Checking the engine oil
Refer to the service maintenance section for the appropriate intervals for
checking the engine oil.
1. Make sure the vehicle is on level ground.
2. Turn the engine off and wait a few minutes for the oil to drain into
the oil pan.
3. Set the parking brake and ensure the gearshift is securely latched in
P (Park) (automatic transmissions) or 1 (First) (manual
transmissions).
4. Open the hood. Protect yourself from engine heat.
5. Locate and carefully remove the engine oil level indicator (dipstick).
²2.0L DOHC I4 Zetec engine
FULL ADD
Maintenance and care
165

REFILL CAPACITIES
Fluid Classification Application Capacity
Brake fluid High
Performance
DOT 3 Motor
Vehicle Brake
FluidAll Fill to line on
reservoir
Engine oil
(including filter
change)API service SJ,
SAE 5W-20,
5W-30 Super
Premium Motor
Oil2.0L I4 Zetec
engine4.25L (4.5
quarts)
API service SH
or SJ, SAE
5W-20, 5W-30,
10W-30, ACEA
A1/B1 Super
Premium Motor
Oil3.0L V6 Duratec
engine5.2L (5.5
quarts)
Fuel tank N/A 2.0L I4 Zetec
engine57L (15 gallons)
3.0L V6 Duratec
engine61L (16 gallons)
Power steering
fluidMERCONtAll Fill to line on
reservoir
Transmission
fluid
1API service GL-4
or GL-5, SAE
75W-90Manual transaxle
(2WD)2.7L (2.85
quarts)2
Manual transaxle
(4X4)2.2L (2.32
quarts)2
MERCONtATF 3.0L engine with
Automatic
transaxle and oil
cooler12.7L (13.4
quarts)3
Capacities and specifications
212

interior .....................................210
mirrors .....................................211
plastic parts ............................209
safety belts ..............................211
washing ....................................206
waxing .....................................207
wheels ......................................209
windows ..................................211
wiper blades ............................209
woodtone trim ........................211
Climate control (see Air
conditioning or Heating) ............20
Clock ......................................28, 37
Clutch
fluid ..........................................170
operation while driving ..........116
recommended shift speeds ....117
Console ........................................53
overhead ....................................46
Controls
power seat .................................68
Coolant
checking and adding ..............171
refill capacities ................175, 212
specifications ..........................214
Cruise control
(see Speed control) ....................40
Customer Assistance ........217±218
D
Daytime running lamps
(see Lamps) ................................49
Defrost
rear window ..............................19
Dipstick
automatic transmission
fluid ..........................................177engine oil .................................165
Doors
door ajar warning .....................12
Driving under special
conditions ..................................123
mud ..........................................122
sand .........................................122
snow and ice ...................122, 124
through water .................122, 126
E
Emergencies, roadside
jump-starting ..........................147
Emission control system ..........198
Engine ........................................214
check engine/service engine
soon light ....................................8
cleaning ...................................208
coolant .....................................171
idle speed control ...................179
lubrication specifications .......214
refill capacities ........................212
service points ..................163±164
starting after a collision .........134
Engine block heater .................105
Engine oil ..................................165
checking and adding ..............165
dipstick ....................................165
filter, specifications ................168
recommendations ...................168
refill capacities ........................212
specifications ..........................214
Exhaust fumes ..........................106
F
Fluid capacities .........................212
Foglamps .....................................50
Index
226

Instrument panel
cleaning ...................................210
cluster ..........................................8
lighting up panel and
interior .......................................18
location of components ..............8
J
Jack ............................................142
positioning ...............................142
storage .....................................142
Jump-starting your vehicle ......147
K
Keys .......................................61±63
key in ignition chime ...............14
positions of the ignition ...........39
L
Lamps
bulb replacement
specifications chart ................204
cargo lamps ...............................18
daytime running light ...............49
fog lamps ...................................50
headlamps .................................49
headlamps, flash to pass ..........50
instrument panel, dimming .....18
interior lamps ...................48, 204
replacing bulbs .......200, 202±204
Lane change indicator
(see Turn signal) ........................50
Liftgate ........................................56
Lights, warning and indicator ......8
air bag ........................................10
anti-lock brakes (ABS) ....10, 108
anti-theft ...................................11brake ..........................................10
charging system ........................12
cruise indicator .........................11
door ajar ....................................12
fuel cap light .............................14
high beam .................................11
low coolant ................................13
low fuel ........................................9
oil pressure ...............................12
overdrive off ..............................13
safety belt .................................10
service engine soon ....................8
turn signal indicator .................11
Load limits .................................124
GAWR ......................................124
GVWR ......................................124
trailer towing ..........................124
Loading instructions .................126
Locks
childproof ..................................53
doors ..........................................52
Lubricant specifications ...........214
M
Manual transaxle .......................116
fluid, checking and adding ....179
reverse .....................................118
Manual transmission
fluid capacities ........................212
Mirrors
cleaning ...................................211
fold away ...................................19
side view mirrors (power) .......18
Moon roof ....................................47
Motorcraft parts ........................194
Index
228

Item Information
Required fuel Unleaded fuel only-87 octane.
Fuel tank capacity-2.0L I4 Zetec
engine57L (15 gallons)
Fuel tank capacity-3.0L V6 Duratec
engine61L (16 gallons)
Engine oil capacity-2.0L I4 Zetec
engine (includes filter change)4.25L (4.5 quarts). Use SAE
5W-20 Super Premium Motor
Oil.
Engine oil capacity-3.0L V6 Duratec
engine (includes filter change)5.2L (5.5 quarts). Use SAE
5W-20 Super Premium Motor
Oil.
Tire size and pressure Refer to the Certification
Label on inside of driver's
door.
Hood release Pull handle under the
instrument panel.
Coolant capacity-2.0L I4 Zetec engine
with manual transaxle
15.0L (5.3 quarts). Use
Premium Engine Coolant
Coolant capacity-3.0L V6 Duratec
engine with automatic transaxle
110.0L (10.6 quarts). Use
Premium Engine Coolant
Power steering fluid capacity Fill to line on reservoir. Use
MERCONtAT F.
Manual transaxle fluid capacity
22.7L (2.85 quarts) 2WD. 2.2L
(2.32 quarts) 4x4. Use 75W-90
Special Blend
Automatic transmission fluid capacity
212.7L (13.4 quarts). Use
MERCONtAT F.3
1
Use Premium Engine Coolant (green in color). DO NOT USE Extended
Life Engine Coolant (orange in color). Refer toAdding engine coolant,
in the Maintenance and Care chapter.
Filling station information
231
