2001 Lexus IS300 oil

8.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
viii
Page
1 Tachometer37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Headlight high beam indicator light 24
. . . . . . . . . . .
3 Low engine oil level warning light 42
. . . . . . . . . . . . .
4 Automatic headlight leveling system warning
light 23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
5 Turn signal indicator lights 24
. . . . . . . . . . . . . . . . . . .
6 Cruise control indicator light 177
. . . . . . . . . . . . . . . .
7 Momentary fuel consumption meter 36. . . . . . . . . . .
8 Voltmeter36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Engine coolant temperature gauge 35
. . . . . . . . . . . .
10 Anti±lock brake system warning light 43
. . . . . . . . . .
11 Malfunction indicator lamp 43
. . . . . . . . . . . . . . . . . . .
12 Fuel gauge 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Low fuel level warning light 44
. . . . . . . . . . . . . . . . . . .
14 Odometer and trip meter 38
. . . . . . . . . . . . . . . . . . . . .
15 Power mode indicator light 168
. . . . . . . . . . . . . . . . . . Page
16 Snow mode indicator light
168
. . . . . . . . . . . . . . . . . . .
17 ODO/TRIP knob 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18 Automatic transmission indicator lights 166 . . . . . .
19 M mode indicator 170
. . . . . . . . . . . . . . . . . . . . . . . . . . .
20 Gear position indicator for manual control 170 . . . .
21 Rear light failure warning light 44
. . . . . . . . . . . . . . . .
22 Discharge warning light 41
. . . . . . . . . . . . . . . . . . . . . .
23 Security indicator light 118. . . . . . . . . . . . . . . . . . . . . . .
24 Traction control system
off indicator/warning light 44 . . . . . . . . . . . . . . . . . . .
25 Low oil pressure warning light 42
. . . . . . . . . . . . . . . .
26 Slip indicator light 180
. . . . . . . . . . . . . . . . . . . . . . . . . .
27 Brake system warning light 39
. . . . . . . . . . . . . . . . . . .
28 SRS warning light 41
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
29 Open door warning light 44
. . . . . . . . . . . . . . . . . . . . . .
30 Driver's seat belt reminder light 40
. . . . . . . . . . . . . . .

10.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
x
Page
1 Tachometer37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Headlight high beam indicator light 24
. . . . . . . . . . .
3 Low engine oil level warning light 42
. . . . . . . . . . . . .
4 Automatic headlight leveling system warning
light 23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
5 Turn signal indicator lights 24
. . . . . . . . . . . . . . . . . . .
6 Cruise control indicator light 177
. . . . . . . . . . . . . . . .
7 Momentary fuel consumption meter 36. . . . . . . . . . .
8 Voltmeter36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Engine coolant temperature gauge 35
. . . . . . . . . . . .
10 Anti±lock brake system warning light 43
. . . . . . . . . .
11 Malfunction indicator lamp 43
. . . . . . . . . . . . . . . . . . .
12 Fuel gauge 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Low fuel level warning light 44
. . . . . . . . . . . . . . . . . . .
14 Odometer and trip meter 38
. . . . . . . . . . . . . . . . . . . . .
15 Power mode indicator light 168
. . . . . . . . . . . . . . . . . . Page
16 Snow mode indicator light
168
. . . . . . . . . . . . . . . . . . .
17 ODO/TRIP knob 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18 Automatic transmission indicator lights 166 . . . . . .
19 M mode indicator 170
. . . . . . . . . . . . . . . . . . . . . . . . . . .
20 Gear position indicator for manual control 170 . . . .
21 Rear light failure warning light 44
. . . . . . . . . . . . . . . .
22 Discharge warning light 41
. . . . . . . . . . . . . . . . . . . . . .
23 Security indicator light 118. . . . . . . . . . . . . . . . . . . . . . .
24 Traction control system
off indicator/warning light 44 . . . . . . . . . . . . . . . . . . .
25 Low oil pressure warning light 42
. . . . . . . . . . . . . . . .
26 Slip indicator light 180
. . . . . . . . . . . . . . . . . . . . . . . . . .
27 Brake system warning light 39
. . . . . . . . . . . . . . . . . . .
28 SRS warning light 41
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
29 Open door warning light 44
. . . . . . . . . . . . . . . . . . . . . .
30 Driver's seat belt reminder light 40
. . . . . . . . . . . . . . .

KEYS AND DOORS
16
11L029±1
2. Remove the module from the key frame.
11L030±1
3. Remove the 2 screws to take out the lid of the module.
4. Take out the discharged battery and put a new battery with
the positive side up.
NOTICE
Make sure the positive side and negative side of thebattery should be faced correctly.
Be careful not to bend the electrode of the batteryinsertion and that dust or oils do not adhere to theinside of the module.
Take care not to lose the screws and O±ring.
5. Install the lid with the 2 screws.
NOTICE
Take care not to damage or bend the O±ring wheninstalling.
6. Install the module into the key frame and secure the cover
with the screw.
7. When pushing any switch on the wireless key, make sure
the indicator light comes on.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
39
(e) Stop and check.

(f) Stop and check.
(g) Add engine oil.
(h) Take vehicle to Lexus dealer.
(i) Take vehicle to Lexus dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(j) Close all doors.
(k) Replace bulb. (l) Fill up tank.
(m) Take vehicle to Lexus
dealer.
(n) Take vehicle to Lexus dealer.
(o) Remove key.
(a) Brake System Warning Light and Buzzer
This l ight comes on in the following cases when the ignition key
is in the ºONº position.
 When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
turned to the ºONº position even after the parking brake is
released.
The buzzer beeps once if the vehicle is driven with its parking
brake applied.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
Have your vehicle checked at your Lexus dealer in the
following cases:
or
or
Low fuel level
warning light
Key reminder buzzer

GAUGES, METERS AND SERVICE REMINDER INDICATORS
42
(f) Low Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on ± evenfor one block. It may ruin the engine.
(g) Low Engine Oil Level Warning Light
This light warns that the engine oil level is too low. Add oil as
soon as possible. (For instructions, see ºChecking the engine
oil levelº on page 240.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this light may
come on due to the movement of engine oil in the engine.
NOTICE
Continued engine operation with low engine oil willdamage the engine.

AUDIO
139
(c) Your radio antenna
To remove an antenna, carefully turn it counterclockwise.
NOTICE
To prevent damage to the antenna, make sure it is
removed before driving your vehicle through anautomatic car wash.
(d) Your cassette player
When you insert a cassette, the exposed tape should be to the
right.
NOTICE
Do not oil any part of the cassette player, and do not insert anything except a cassette tape into the slot.
(e) Your automatic changer
SV22006
Your automatic changer can be store up to 6 discs and play
selected discs or continuously play all the discs set in the
player.
When you set discs into the player, make sure their labels face
up. If not, the player will display ºERR 1º and the disc number.
NOTICE
Never try to disassemble or oil any part of the compact disc player. Do not insert anything except acompact disc into the slot.
Do not insert a disc upon another one.
The player is intended for use with 12 cm (4.7 in.) discs only.

DRIVING TIPS
192
WINTER DRIVING TIPS
Make sure you have a proper freeze protection of engine
coolant.
Your coolant must contain ethylene±glycol type coolant for a
proper corrosion protection of aluminum components. Use
ºToyota Long Life Coolantº or equivalent. See ºChecking the
engine coolant levelº on page 243 for instructions.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
When it is extremely cold, we recommend to use 60% solution
for your Lexus, to provide protection down to about ±50C
(±58 F). Do not use more than 70% solution for better coolant
performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 266 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 242 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer ± they will be pleased to help. Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de±icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into ºPº and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.

DRIVING TIPS
195


Keep your vehicle tuned±up and in top shape. A dirty air
cleaner, improper valve clearance, dirty plugs, dirty oil and
grease, brakes not adjusted, etc. all lower engine
performance and contribute to poor fuel economy. For
longer life of all parts and lower operating costs, keep all
maintenance work on schedule, and if you often drive under
severe conditions, see that your vehicle receives more
frequent maintenance (For scheduled maintenance
information, please refer to the ºOwner's Manual
Supplement / Maintenance Scheduleº.)
CAUTION
Never turn off the engine to coast down hills. Your
power steering and brake booster will not function
without the engine running. Also, the emission control
system operates properly only when the engine is
running.
