2001 Lexus IS300 mirror

6.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
vi
Page
1 Power door lock switch and power window switches 18, 28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Power rear view mirror control switch 80
. . . . . . . . .
3 Headlight cleaner switch 26
. . . . . . . . . . . . . . . . . . . . .
4 Headlight, turn signal and fog light
switch 22, 25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Instrument panel light control 46
. . . . . . . . . . . . . . . . .
6 Cruise control switch 177
. . . . . . . . . . . . . . . . . . . . . . .
7 Wiper and washer switches 25
. . . . . . . . . . . . . . . . . . .
8 Emergency flasher switch 30
. . . . . . . . . . . . . . . . . . . .
9 Outside temperature display/Clock 50
. . . . . . . . . . . .
10 Front passenger's seat belt reminder light 40 . . . . . Page
11 Automatic air conditioning controls
122
. . . . . . . . . .
12 Car audio 135
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Seat heater switches 30
. . . . . . . . . . . . . . . . . . . . . . . . .
14 Glove box 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15 Parking brake lever 165
. . . . . . . . . . . . . . . . . . . . . . . . .
16 Driving pattern selector switch 166
. . . . . . . . . . . . . . .
17 Ashtray 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
18 Cigarette lighter 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19 Automatic transmission selector lever 166 . . . . . . . .
20 Traction control system off switch 180
. . . . . . . . . . .
21 Hood lock release lever 62
. . . . . . . . . . . . . . . . . . . . . .

12.
SVPC013
PICTORIAL INDEX
xii
EXTERIOR VIEW
Page
1 Rear window defogger27
. . . . . . . . . .
2 Trunk lid 63
. . . . . . . . . . . . . . . . . . . . . . .
3 Moon roof 67
. . . . . . . . . . . . . . . . . . . . .
4 Wiper and washer 25, 272
. . . . . . . . . .
5 Fuel filler door 65
. . . . . . . . . . . . . . . . .
6 Outside rear view mirror 79
. . . . . . . .
7 Door 17
. . . . . . . . . . . . . . . . . . . . . . . . . .
8 Tire and wheel 252
. . . . . . . . . . . . . . . .
9 Headlights 22, 274
. . . . . . . . . . . . . . . . .
10 Hood 62
. . . . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the description given in each section.

SECTION 1 ± 4
47
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Interior lights 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Personal lights 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Ignition switch light 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Clock 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
Outside temperature display 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Glove box 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Garage door opener 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Cup holders 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Warning reflector holder 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie±down hooks 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Floor mat 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
First±aid kit holder 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Luggage stowage precautions 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTERIOR EQUIPMENT
48
VANITY MIRRORS
SS14001
To use the vanity mirrors, swing the sun visor down and
open the cover.
The vanity light comes on when you open the cover.
Sun visors
SS14002
1To block out glare from the front , swing the sun visor
down.
2To block out glare from the side, remove the sun visor
from the hook and swing it to the side.

SECTION 1 ± 6
69
INSTRUMENTS AND CONTROLS
Comfort adjustment
Front seats70
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Trunk storage extension 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints 77
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Tilt steering wheel 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
Outside rear view mirrors 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Seat belts 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
SRS airbags 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Child restraint 102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .

COMFORT ADJUSTMENT
79
TILT STEERING WHEEL
SV16064
To change the steering wheel angle, hold the steering
wheel, pull the lock release lever toward you, tilt the
steering wheel to the desired angle and release the lever.
When the steering wheel is in a low position, it will spring up as
you release the lock release lever.
CAUTION
 Do not adjust the steering wheel while the vehicle is
moving. It may cause the driver to mishandle the
vehicle and an accident may occur resulting in death
or injuries.
 After adjusting the steering wheel, try moving it up
and down to make sure it is locked in position.
OUTSIDE REAR VIEW MIRRORS
SV16010
Adjust the mirror so that you can just see the side of your
vehicle in the mirror.
Be careful when judging the size or distance of any object seen
in the outside rear view mirror on the passenger's side. It is a
convex mirror with a curved surface. Any object seen in a
convex mirror will lock smaller and farther away than if seen in
a normal flat mirror.
When the ignition switch is turned ºONº, the heater panels in
the outside rear view mirrors will quickly clear the surface.
The outside rear view mirror heater will operate while the
ignition switch is ºONº.

COMFORT ADJUSTMENT
80
CAUTION
Do not adjust the mirror while the vehicle is moving.
It may cause the driver to mishandle the vehicle and
an accident may occur, resulting in personal death or
injuries.
 Since the mirror surfaces can get hot, keep your
hands off them when the rear window and outside
rear view mirror defogger switch is on.
Power rear view mirror control
SV16012

1Master switch 2Control switch
To adjust the power rear view mirror, first place the master
switch at ºLº (left) or ºRº (right), and push the contro\
l
switch on the desired side.
The power rear view mirror can be adjusted when the key is in
the ºACCº or ºONº position.
NOTICE
If ice should jam the mirror, do not operate the control
or scrape the mirror face. Use a spray de±icer to free themirror.
Folding rear view mirrors
SS16030
To fold the rear view mirror, push backward.
The rear view mirrors can be folded backward for parking in
restricted areas.
CAUTION
Do not drive with the mirrors folded backward. Both the
driver and passenger side rear view mirrors must be
extended and properly adjusted before driving.

COMFORT ADJUSTMENT
81
INSIDE REAR VIEW MIRROR
SV16011

1Day 2Night
When driving at night, pull the lever toward you to reduce
the glare from the headlights of vehicles behind you.
Before adjusting the mirror to the position with most clarity,
push the day±night change lever forward (daylight driving
position).
Remember that by reducing glare you also lose some rear view
clarity.
CAUTION
Do not adjust the mirror while the vehicle is moving. It
may cause the driver to mishandle the vehicle and an
accident may occur resulting in personal death or
injuries.
SEAT BELTS
Seat belt precautions
Lexus strongly urges that the driver and passengers in the
vehicle be properly restrained at all times with the seat belts
provided. Failure to do so could increase the chance of injury
and/or the severity of injury in accidents.
Child. Use a child restraint system appropriate for the child
until the child becomes large enough to properly wear the
vehicle's seat belts. See ºChild restraintº on page 102 for
details.
If a child is too large for a child restraint system, the child should
sit in the rear seat and must be restrained using the vehicle's
seat belt. According to accident statistics, the child is safer
when properly restrained in the rear seat than in the front seat.
If a child must sit in the front seat, the seat belts should be worn
properly. Do not let the child sit on your lap. It does not provide
sufficient restraint. If an accident occurs and the seat belts are
not worn properly, the force of the rapid inflation of the airbag
may cause severe injury to the child.
Do not allow the child to stand up or kneel on either rear or front
seats. An unrestrained child could suffer serious injury or
death during emergency braking or a collision.
Pregnant woman. Lexus recommends the use of a seat belt.
Ask your doctor for specific recommendations. The lap belt
should be worn securely and as low as possible over the hips
and not on the waist.
