2001 Lexus IS300 clock

6.
For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
vi
Page
1 Power door lock switch and power window switches 18, 28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Power rear view mirror control switch 80
. . . . . . . . .
3 Headlight cleaner switch 26
. . . . . . . . . . . . . . . . . . . . .
4 Headlight, turn signal and fog light
switch 22, 25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Instrument panel light control 46
. . . . . . . . . . . . . . . . .
6 Cruise control switch 177
. . . . . . . . . . . . . . . . . . . . . . .
7 Wiper and washer switches 25
. . . . . . . . . . . . . . . . . . .
8 Emergency flasher switch 30
. . . . . . . . . . . . . . . . . . . .
9 Outside temperature display/Clock 50
. . . . . . . . . . . .
10 Front passenger's seat belt reminder light 40 . . . . . Page
11 Automatic air conditioning controls
122
. . . . . . . . . .
12 Car audio 135
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 Seat heater switches 30
. . . . . . . . . . . . . . . . . . . . . . . . .
14 Glove box 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15 Parking brake lever 165
. . . . . . . . . . . . . . . . . . . . . . . . .
16 Driving pattern selector switch 166
. . . . . . . . . . . . . . .
17 Ashtray 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
18 Cigarette lighter 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19 Automatic transmission selector lever 166 . . . . . . . .
20 Traction control system off switch 180
. . . . . . . . . . .
21 Hood lock release lever 62
. . . . . . . . . . . . . . . . . . . . . .

SECTION 1 ± 4
47
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Interior lights 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Personal lights 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Ignition switch light 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Clock 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
Outside temperature display 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Glove box 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Garage door opener 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Cup holders 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Warning reflector holder 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie±down hooks 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Floor mat 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
First±aid kit holder 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Luggage stowage precautions 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTERIOR EQUIPMENT
50
IGNITION SWITCH LIGHT
SS14007
For easy access to the ignition switch, the ignition switch
light comes on when any of the doors are opened.
The light remains on for about 15 seconds and goes out after
all the doors are closed. However, the light goes out
immediately when all the doors are locked or the ignition key
is in the ºACCº or ºONº position.
CLOCK
SS14008
The digital clock indicates the time with the ignition key at
the ºACCº or ºONº position. To reset the hour, press the
ºHº button. To reset the minutes, press the ºMº button.
To adjust the time to the nearest hour, press the º:00º
button.
For example, if the º:00º button is pressed when the time is
between 9:30 ± 9:59 or between 10:01 ± 10:29, the time will
change to 10:00.
If the electrical power source has been disconnected from the
clock, the time display will automatically be set to 1:00 (one
o'clock).
When the headlight switch is in the first or second click stop,
you can also adjust the brightness of the display using the
instrument panel light control dial.

INTERIOR EQUIPMENT
54
GLOVE BOX
SS14012

1Unlock 2Open 3Lock
To open the glove box door, pull the lever. To lock the
glove box door, insert the master key and turn it
clockwise.
With the tail lights on, the glove box light will come on when the
glove box door is open.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.
GARAGE DOOR OPENER
The garage door opener is manufactured under license
from HomeLink and can be programmed to operate
garage doors, estate gates, security lighting, etc.
(a) Programming HomeLink
SV14007

1Buttons 2Indicator light
The HomeLink has 3 buttons and can be programmed
to operate 3 separate devices.
Prepare the HomeLink
 for programming by erasing all
codes or the memorized data programmed by the former
owner. Follow the procedure in º(c) Erasing the garage
door opener memoryº.
1. Decide which one of the 3 buttons you want to program.
Push and hold down the button for about 20 seconds until the
indicator light begins to flash. While holding this button, follow
steps º2º and º3º.

EXTERIOR EQUIPMENT
63
SS15021
In case of unlocking the support rod, lift up the hood a
little, move the support rod and unlock it as shown by the
arrow marks in the illustration.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. and return the support rod to its
clips±this prevents rattles. Then lower the hood and make
sure it locks into place. If necessary, press down gently on the
front edge to lock it.
CAUTION
Before driving, be sure that the hood is securely locked.
Otherwise, the hood may open unexpectedly while
driving and an accident may occur.
TRUNK LID
SS15005c
To unlock the trunk lid, insert the master key and turn it
clockwise.
To close the trunk lid, lower it and press down on it. After
closing the trunk lid, try pulling it up to make sure it is securely
closed.
The trunk lid can be unlocked using the wireless remote control
key. For details, see page 13.
If the theft deterrent system is set, unlock the trunk lid with the
wireless remote control. (For details, see page 118.)

EXTERIOR EQUIPMENT
65
Luggage security system
SS15013
After closing the trunk lid, insert the master key and turn
it counterclockwise to deactivate the lock release lever.
At this time, the trunk lid can be opened only by the
phosphorescent handle lever inside the trunk.
FUEL TANK CAP
SS15008
1. To open the fuel filler door, pull the lever up.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refueling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.

EXTERIOR EQUIPMENT
66
SV15007
2. To remove the fuel tank cap, turn the cap slowly
counterclockwise, then pause slightly before removing it.
After removing the cap, hang the tether as shown in the
illustration.
It is not unusual to hear a slight swoosh when the cap is
opened. When installing the cap, turn the cap clockwise until
you hear a click.
If the cap is not tightened securely, the malfunction indicator
lamp comes on. Make sure the cap is tightened securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
CAUTION
 Make sure the cap is tightened securely to prevent
fuel spillage in case of an accident.
 Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
Refueling the vehicle
As soon as the correctly operated nozzle switches off
automatically for the first time, the tank is full. Do not try
to add more fuel, because fuel may spill out.

AUDIO
139
(c) Your radio antenna
To remove an antenna, carefully turn it counterclockwise.
NOTICE
To prevent damage to the antenna, make sure it is
removed before driving your vehicle through anautomatic car wash.
(d) Your cassette player
When you insert a cassette, the exposed tape should be to the
right.
NOTICE
Do not oil any part of the cassette player, and do not insert anything except a cassette tape into the slot.
(e) Your automatic changer
SV22006
Your automatic changer can be store up to 6 discs and play
selected discs or continuously play all the discs set in the
player.
When you set discs into the player, make sure their labels face
up. If not, the player will display ºERR 1º and the disc number.
NOTICE
Never try to disassemble or oil any part of the compact disc player. Do not insert anything except acompact disc into the slot.
Do not insert a disc upon another one.
The player is intended for use with 12 cm (4.7 in.) discs only.
