2001 LAND ROVER FREELANDER relay

WIPERS AND WASHERS
84-8 REPAIRS
Switch - combined wiper/washer
$% 84.35.34
Remove
1.Remove instrument cowl.

+ INSTRUMENTS, REPAIRS, Cowl -
instrument - up to 04MY.
2.Remove rear wiper switch from instrument
cowl.
Refit
1.Fit switch to instrument cowl.
2.Fit instrument cowl.

+ INSTRUMENTS, REPAIRS, Cowl -
instrument - up to 04MY.
Relay - tailgate wipe - 5 door
$% 84.35.38
Remove
1.Remove RH rear quarter lower trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
2.Remove rear wiper motor relay.
Refit
1.Fit rear wiper motor relay.
2.Fit RH rear quarter lower casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.

CHARGING AND STARTING
86-1-14 REPAIRS
Relay - main
$% 86.55.08
Remove
1.Open engine compartment fuse box.
2.Identify and remove main relay.Refit
1.Fit main relay.
2.Close engine compartment fuse box.

CHARGING AND STARTING
86-1-18 REPAIRS
Relay - starter
$% 86.60.10
Remove
1.Open engine compartment fuse box.
2.Identify and remove starter relay.
Refit
1.Fit starter relay.
2.Close engine compartment fuse box.

CONTROL UNITS
REPAIRS 86-3-1
CONTROL UNITS REPAIRS
Control unit - window lift
$% 86.25.39
Remove
1.Remove driver's side fuse box.

+ HARNESSES, REPAIRS, Fuse box -
passenger compartment.
2.Remove 2 nuts securing window lift control unit
and release unit from studs.
3.Disconnect multiplug from window lift control
unit and remove unit from vehicle.
Refit
1.Connect multiplug to window lift control unit.
2.Position unit and secure with 2 nuts.
3.Fit fuse box.

+ HARNESSES, REPAIRS, Fuse box -
passenger compartment.
Relay - power folding mirrors - from
02MY
$% 86.55.13
CAUTION: If the power fold mirrors are operated
consecutively more than three times, then they
will cease to function for a period of one minute.
This is to prevent damage to the power fold
mirror motors.
Remove
1.Remove passenger side tread strip.
2.Release power fold mirror relay from 'A' post.
3.Remove relay from harness block connector.
Refit
1.Fit relay to harness block connector.
2.Fit relay to securing clip.
3.Fit tread strip.

WINDOWS
REPAIRS 86-5-3
Relay - control - tail door glass
$% 86.25.45
Remove
1.Remove RH rear quarter lower trim casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 3 door.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.
2.Remove tail door glass control relay.Refit
1.Fit tail door glass control relay.
2.Fit RH rear quarter lower casing.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 3 door.

+ INTERIOR TRIM COMPONENTS,
REPAIRS, Trim casing - rear quarter - lower
- 5 door.

WINDOWS
REPAIRS 86-5-5
Relay - heated front screen
$% 86.55.18
Remove
1.Release heated front screen fuse holder from
heated front screen relay holder.
2.Release heated front screen relay holder from
'E' box bracket.3.Remove cover from heated front screen relay.
4.Remove heated front screen relay.
Refit
1.Fit heated front screen relay.
2.Ensure cover seal is fitted correctly and fit
heated front screen relay cover.
3.Fit heated front screen relay holder to 'E' box
bracket.
4.Fit heated front screen fuse holder to heated
front screen relay holder.

HARNESSES
REPAIRS 86-7-1
HARNESSES REPAIRS
Fuse box - passenger compartment
$% 86.70.01
Remove
1.Disconnect battery earth lead.
2.Open glove box.
3.Remove hinge pins and lid.
4.Remove fuse box cover.
5.Remove relays from fuse box mounting plate.
6.Remove bolt securing fuse box mounting plate
to steering column bracket.
7.Remove 2 bolts securing mounting plate to
body.
8.Remove 2 bolts securing fuse box to mounting
plate.
9.Disconnect 3 multiplugs from CCU in rear of
fuse box.
10.Release fusebox and disconnect 8 multiplugs.
11.Remove fusebox.
12.Remove fuses and relays from fuse box.Refit
1.Identify and fit fuses.
2.Fit relays.
3.Fit fuse box.
4.Connect multiplugs to fusebox.
5.Connect multiplugs to CCU.
6.Fit bolts securing fuse box to mounting plate
and tighten to 8 Nm (6 lbf.ft).
7.Fit bolts securing fuse box mounting plate to
body and tighten to 8 Nm (6 lbf.ft).
8.Fit relays to mounting plate.
9.Fit fuse box cover.
10.Fit glove box lid and hinge pins.
11.Close lid.
12.Connect battery earth lead.

HARNESSES
REPAIRS 86-7-5
44.Disconnect multiplug from wiper motor and pull
into engine bay.
45.With assistance pull main harness into vehicle
interior.
46.Remove 6 screws securing front mud flaps and
remove mud flaps.
47.Release rear edges of front wheel arch liners.48.Release side repeater lamps, disconnect
multiplugs and remove lamps.
49.Remove 3 bolts from passenger compartment
fuse box and pull fuse box forward.
50.Release and disconnect multiplug from RH 'A'
post.
51.Disconnect coaxial cable.
52.Release relays from fuse box bracket.
