Engine Oil and Filter – KV6
Drain
1.Raise vehicle on ramp.
2.Remove underbelly panel.

+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
3.Place a suitable container under engine sump
drain plug, remove plug and discard sealing
washer. Allow oil to drain.
WARNING: Observe due care when draining
engine oil as the oil can be very hot.
WARNING: Avoid excessive skin contact
with used engine oil. Used engine oil
contains potentially harmful contaminants
which may cause skin cancer or other
serious skin disorders.
4.Remove and discard engine oil filter.

+ ENGINE - K SERIES KV6, REPAIRS,
Filter - engine oil.Refill
1.Fill canister of replacement oil filter with clean
engine oil.
2.Lubricate sealing ring of new filter with clean
engine oil.
3.Fit new filter and tighten by hand until it seats,
then tighten a further half turn.
4.Clean sump drain plug and fit new sealing
washer.
5.Fit sump drain plug and tighten to 25 Nm (18
lbf.ft).
6.Remove engine oil filler cap and fill engine with
oil to correct level.

+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.
7.Fit oil filler cap.
8.Fit underbelly panel.

+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
9.Lower vehicle.
10.Start engine. Run at 2500 rev/min until oil
pressure warning light extinguishes.
11.Stop engine. Recheck engine oil level.
12.Check for signs of leakage.

MAINTENANCE
10-26 MAINTENANCE
KV6 – Petrol engines
Check
1.Check security of all fuel hoses, paying
particular attention to those running under the
vehicle. Check all hoses and pipes are correctly
routed and secured. Check for signs of leakage
or damage.
Brake Hoses and Pipes
Check
1.Visually check condition of all brake hoses.
Look for any sign of damage or chafing. Check
for any signs of fluid leakage.
2.Check brake pipes for signs of leakage or
corrosion. Pay particular attention to pipe
unions and joints. Ensure all pipes and hoses
are correctly routed and secured.
Check Exhaust System
Check
1.Visually check condition of exhaust system for
signs of damage. Extra care should be taken to
ensure the catalyst is in good condition and
shows no signs of damage. Check condition of
exhaust heat shields.
2.Check exhaust system is firmly secured and
check condition of exhaust mounting rubbers,
clamps and brackets.

MAINTENANCE
10-28 MAINTENANCE
Steering
Check
1.Check/tighten steering unit and steering rod
ball joint fixings.
2.Check condition of ball joints and dust covers.
3.Check steering rack bellows for any signs of
leakage.
Road Test
There are two purposes for conducting a road test.
Firstly, to ensure the work completed within the
dealership meets the standards required as laid
down by dealership processes. Secondly, for a
skilled technician to assess the general condition of
the vehicle and report any conditions that the
customer should be made aware of.
CAUTION: Two wheel dynamometer tests must
not be carried out. Four wheel dynamometer
tests must be restricted to 3 mph (5 kph).
Engine Start
1.Check for correct operation of starter switch.
Ensure the engine starts in a correct manner.
Leave the engine running.
Starter Inhibitor Switch – (Automatic only)
1.Select 'D' gear lever position.
2.Check that engine will not start.
3.Select 'R' gear lever position and repeat start
check.
4.Check that engine will start in 'P' and 'N'
positions.
Selector Cable – (Automatic only)
1.Check for correct setting of gear selector cable.
Engine Performance and Throttle Operation
1.Start engine and check that it starts easily.
2.Check that 'oil pressure' and 'no charge'
warning lamps extinguish.
3.Check that throttle pedal movement is free and
unrestricted.
4.Check that engine is responsive to throttle
movement.
Clutch and Gear Selection –
(Manual only, normal driving conditions)
1.Check that clutch engages smoothly without
judder, slipping or noise.
2.Check for abnormal transmission noise.
3.Check for smooth quiet gear changes and that
gear selected engages easily.

MAINTENANCE
MAINTENANCE 10-29
Gear Change and Parking Pawl Engagement –
(Automatic only, normal driving conditions)
1.Select 'R' and check for smooth take up.
2.Select 'D' and check for smooth up-changes of
ratio from rest.
3.Slow down vehicle and check for smooth down-
changes of ratio.
4.Stop vehicle on a slope.
5.Select 'P' and release handbrake.
6.Check that vehicle does not move and that
selector does not slip out of 'P'.
7.Carry out a similar check with vehicle facing in
the opposite direction.
Steering
1.With vehicle stationary, turn steering from lock
to lock. Check for smooth operation and ensure
there is no undue noise from the power steering
pump or drive belt.
Suspension
1.Check for noise, irregularity in ride (e.g.
dampers) and wheel imbalance.
Foot brake
1.Check for pedal effort, travel, braking
efficiency, pulling and binding.
Handbrake
1.Apply handbrake firmly, check travel and
ratchet hold and release.
Instruments
1.Check for correct operation of all instruments
and warning devices where practical.
Body
1.Check for abnormal body noise.
Seat Belts
1.Check for operation of inertia reels.Road Test
1.Drive vehicle on a short road test. Check all
vehicle systems for correct operation. Pay
particular attention to:
lEngine noise
lGearbox noise
lSuspension noise
lBody noise
lBraking system operation
lGear selection
lEngine performance
2.Where possible, check for correct operation of
Hill Descent Control (HDC) system. This should
not be carried out if excessive journey time is
required.
3.After road test, carry out a final inspection of the
vehicle on vehicle ramps.
4.Check all underbonnet fluid levels and top-up if
necessary.

ENGINE - K SERIES KV6
ADJUSTMENTS 12-3-1
ENGIN E - K SERIES KV6 ADJUST ME NTS
Engine oil pressure check
$% 12.90.09.01
Check
1.Remove oil pressure switch.

+ ENGINE - K SERIES KV6, REPAIRS,
Switch - oil pressure.
2.Fit sealing washer from oil pressure switch to
LRT-12-052/10 oil pressure gauge adaptor.
3.Fit and tighten oil pressure gauge adaptor LRT-
12-052/10 to oil pump housing.
4.Connect oil pressure gauge LRT-12-052C and
tighten union.
5.Check and if necessary top up engine oil.
6.Start and run engine until normal operating
temperature is reached.
7.Note oil pressure readings with the engine
running at idle and at 3000 rev/min.

+ GENERAL DATA, Engine - KV6
Petrol.
8.Switch off engine, unscrew gauge union and
remove gauge.
9.Remove adaptor.
10.Wipe off oil spillage
11.Fit oil pressure switch.

+ ENGINE - K SERIES KV6, REPAIRS,
Switch - oil pressure.
12.Recheck engine oil and top up if necessary.

ENGINE - K SERIES KV6
12-3-12 REPAIRS
Crankshaft rear oil seal
$% 12.21.20
Remove
1.Remove torque converter drive plate.

+ ENGINE - K SERIES KV6, REPAIRS,
Torque converter drive plate.
2.Remove and discard 5 bolts securing
crankshaft rear oil seal to cylinder block.
3.Remove and discard crankshaft rear oil seal.Refit
1.Clean cylinder block face and oil seal running
surface on crankshaft; ensure bolt holes are
clean and dry.
2.Position oil seal protector, LRT-12-061 to
crankshaft.
3.Position oil seal to crankshaft.
CAUTION: Oil seal must be fitted dry.
4.Fit new Patchlok bolts securing oil seal to
cylinder block and using sequence shown,
tighten to 8 Nm (6 lbf.ft).
5.Remove oil seal protector.
6.Fit torque converter drive plate.

+ ENGINE - K SERIES KV6, REPAIRS,
Torque converter drive plate.
7.Check engine oil level, top-up if necessary.

+ MAINTENANCE, MAINTENANCE,
Engine Oil and Filter – KV6.

ENGINE - K SERIES KV6
REPAIRS 12-3-15
Refit
1.Clean cylinder head mating face.
CAUTION: Use suitable gasket removal
spray and a plastic scraper.
2.Remove bolts securing cylinder liner clamps
LRT-12-144 to cylinder block and remove
clamps.
CAUTION: Do not rotate crankshaft.
3.Clean cylinder block face and dowel holes.
4.Clean cylinder head bolts and wipe dry.
5.Lightly lubricate threads and beneath heads of
cylinder head bolts with clean engine oil.
6.Check that fitted height of dowels is between 10
to 11 mm (0.40 to 0.43 in) above cylinder block
top face. Replace dowels if fitted height is
incorrect.
7.Fit new cylinder head gasket onto cylinder
block with the word 'TOP' uppermost.
8.With assistance, fit cylinder head and carefully
position LH inlet to RH inlet manifold.
9.Carefully enter cylinder head bolts, DO NOT
DROP. Screw bolts into place by hand.10.Tighten cylinder head bolts progressively in the
sequence shown to :
lStage 1 - 25 Nm (18 lbf.ft)
lStage 2 - Tighten in the same sequence to
25 Nm (18 lbf.ft)
lStage 3 -Tighten in the same sequence to
25 Nm (18 lbf.ft)
lStage 4 - Using an angle torque gauge,
tighten bolts in the same sequence a further
180°
11.Fit LH camshaft cover gasket.

+ ENGINE - K SERIES KV6, REPAIRS,
Camshaft cover gasket - LH - Up to 03MY.
12.Remove and discard 'O' rings from injectors.
13.Clean injectors and injector locations in fuel rail.
14.Lubricate new 'O' rings with castor oil and fit to
injectors.
15.Position fuel rail assembly and secure injectors
to inlet manifolds.
16.Position injector protection cover - if fitted to RH
fuel rail and secure injector harness to
protection cover or fuel rail with clips.
17.Fit bolts securing fuel rail to inlet manifolds and
tighten to 9 Nm (7 lbf.ft).
18.Position CMP sensor bracket, fit and tighten
bolt to 9 Nm (7 lbf.ft).
19.Connect CMP sensor multiplug and secure to
bracket.
20.Connect breather hose to LH inlet manifold.
21.Connect coolant bleed hose to inlet manifold
and secure with clip.
22.Position ignition coils to LH inlet manifold.
23.Position earth lead, fit nuts and bolts securing
ignition coils to LH inlet manifold and tighten to
9 Nm (7 lbf.ft).
24.Position ht lead guide bracket, fit and tighten
special bolt.
25.Connect ht leads to spark plugs and secure ht
leads in guide clips.
26.Clean camshaft timing belt cover backplate
bolts and apply sealant, Part No. STC 50552 to
the first 3 threads.

ENGINE - K SERIES KV6
12-3-16 REPAIRS
27.Position backplate, fit and tighten bolts to 9 Nm.
28.Fit camshaft timing belt.

+ ENGINE - K SERIES KV6, REPAIRS,
Camshaft timing belt.
29.Fit LH exhaust manifold gasket.

+ MANIFOLDS & EXHAUST SYSTEMS
- K SERIES KV6, REPAIRS, Gasket - exhaust
manifold - LH - Non NAS.

+ MANIFOLDS & EXHAUST SYSTEMS
- K SERIES KV6, REPAIRS, Gasket(s) -
exhaust manifold - LH - NAS.
30.Fit inlet manifold chamber.

+ MANIFOLDS & EXHAUST SYSTEMS
- K SERIES KV6, REPAIRS, Seals - inlet
manifold chamber - up to 03MY.
31.Fill cooling system.

+ COOLING SYSTEM - K SERIES KV6,
ADJUSTMENTS, Coolant - drain and refill.
32.Check engine oil level and top-up if necessary.

+ MAINTENANCE, MAINTENANCE,
Engine Oil and Filter – KV6.
Cylinder head gasket - RH
$% 12.29.03
Remove
1.Disconnect battery earth lead.
2.Drain cooling system.

+ COOLING SYSTEM - K SERIES KV6,
ADJUSTMENTS, Coolant - drain and refill.
3.Remove inlet manifold chamber.

+ MANIFOLDS & EXHAUST SYSTEMS
- K SERIES KV6, REPAIRS, Seals - inlet
manifold chamber - up to 03MY.
4.Remove RH exhaust manifold gasket.

+ MANIFOLDS & EXHAUST SYSTEMS
- K SERIES KV6, REPAIRS, Gasket - exhaust
manifold - RH - Non NAS.

+ MANIFOLDS & EXHAUST SYSTEMS
- K SERIES KV6, REPAIRS, Gasket(s) -
exhaust manifold - RH - KV6 - NAS.
5.Remove camshaft timing belt.

+ ENGINE - K SERIES KV6, REPAIRS,
Camshaft timing belt.
6.Remove 4 bolts securing RH front timing belt
cover backplate to cylinder head and remove
backplate.
