Heating and Cooling

To Cool with A/C

1. Turn on the A/C by pressing the button. The light above the buttonshould come on when a fan speed
is selected.
2. Make sure the temperature control dial is set to maximum cool. 3. Select
4. If the outside air is humid, select Recirculation mode. If the outside
air is dry, select Fresh Air mode.
5. Set the fan to the desired speed.
If the interior is very warm from
being parked in the sun, you can cool it down more rapidly by setting up
the controls this way:
1. Start the engine.
2. Turn on the A/C by pressing the button. Make sure the tempera-ture control dial is set to maximum

cool.

3. Set the fan to maximum speed.
4. Open the windows partially. Select and Fresh Air mode. When the interior has cooled down
to a more comfortable temperature,close the windows and set the
controls as described for normal

cooling.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page 58) when driving in stop-and-go
traffic or climbing a long, steep hill. If it moves near the red zone, turn
off the A/C until the gauge reads
normally.

Comfort and Convenience Features
FAN CONTROL DIAL

MODE BUTTONS
TEMPERATURE

CONTROL DIAL

AIR CONDITIONING BUTTON

RECIRCULATION BUTTON

Audio System

Operating the Radio
The ignition switch must be in ACCESSORY (I) or ON (II) to
operate the audio system. Turn the
system on by pushing the PWR/

VOL knob.

Adjust the volume by turning the PWR/VOL knob.
The band and frequency that the
radio was last tuned to is displayed.
To change bands, press the AM/FM button. On the FM band, ST will bedisplayed if the station is broadcast-
ing in stereo. Stereo reproduction on
AM is not available. You can use any of four methods to
find radio stations on the selectedband: TUNE, SEEK, SCAN or thePreset buttons.
TUNE — Use the TUNE bar to tune the radio to a desired frequency. Press the upper part ( ) to tune
to a higher frequency, or the lower part ( ) to tune to a lower
frequency. The frequency numbers
will start to change rapidly. Release the bar when the display reaches the desired frequency. To change the
frequency in small increments, press and release the TUNE bar quickly. SEEK — The SEEK function
searches the band for a station with
a strong signal. To activate it, push
the SEEK switch up or down, then
release it. Depending on which way
you push the switch, the system scans upward or downward from the
current frequency. It stops when it
finds a station with a strong signal.
Comfort and Convenience Features

Audio System

Loading CDs in the Changer

To load multiple CDs in one
operation:

1. Press and hold the Load button until you hear a beep and see in the display, then
release the button.
2. On the left side of the display, the CD Loaded indicator for an empty
position will begin blinking.
3. When you see LOAd in the display, insert the disc into the CD slot.
Insert it only about halfway, thedrive will pull it in the rest of the
way. You will again see the dashes in the display as the CD is loaded.
4. When LOAd appears again in the display, insert the next disc into
the CD slot. 5. Repeat this until all six positions
are loaded. The system will then
begin playing the last CD loaded.
If you are not loading CDs into all six
positions, press the Load button again after the last CD has loaded.
The system will begin playing the last CD loaded.
If you stop loading CDs before all six
positions are filled, and you do not
press the Load button, the system
will wait for ten seconds, then stop
the load operation and begin playing the last CD loaded. To load a single CD:
1. Press and release the Load button.
2. When the CD Loaded indicator for an empty position starts to blink,
and you see LOAd in the display,
insert the disc into the CD slot. Insert it only about halfway, the
drive will pull it in the rest of the
way.
3. The system will load the CD, and begin playing it.
Comfort and Convenience Features

Audio System

If you press the Load button while a
CD is playing, the system will stop
playing that CD and start the loading sequence. It will then play the CD
just loaded.
You can also load a CD into an empty position while a CD is playing by
pressing the appropriate preset
button. Select an empty position (theCD Loaded indicator is off), and
press the preset button for that
position (1 to 6). The system will stop playing the current CD and start
the loading sequence. It will then
play the CD just loaded.

CONTINUED

Comfort and Convenience Features

LOAD BUTTON
CD LOADED
INDICATORAM
BUTTON CD SLOT

FM BUTTON
PRESET BUTTONSTAPE BUTTON

Automatic Transmission

Park (P) — This position mechani-cally locks the transmission. Use
Park whenever you are turning off or
starting the engine. To shift out of
Park, you must press on the brake
pedal and have your foot off the accelerator pedal. Press the release
button on the side of the shift lever
to move it.
If you have done all of the above andstill cannot move the lever out of
Park, see Shift Lock Release on page 200.
You must also press the release button to shift into Park. To avoid
transmission damage, come to a complete stop before shifting into
Park. The shift lever must be in Park
before you can remove the key from the ignition switch. Reverse (R) — To shift to Reverse
from Park, see the explanation under
Park. To shift to Reverse from
Neutral, come to a complete stop and
then shift. Press the release button
before shifting into Reverse from Neutral. Neutral (N) — Use Neutral if you
need to restart a stalled engine, or if
it is necessary to stop briefly with
the engine idling. Shift to Park posi-
tion if you need to leave the car for
any reason. Press on the brake pedal
when you are moving the shift lever from Neutral to another gear.
Drive (D4) — Use this position for
your normal driving. The transmis- sion automatically selects a suitable
gear for your speed and acceleration.
You may notice the transmission shifting up at higher speeds when
the engine is cold. This helps the
engine warm up faster.

Driving

Automatic Transmission

Drive (D3) —This position is similar
to D4, except only the first three
gears are selected. Use D3 when
towing a trailer in hilly terrain, or to
provide engine braking when going down a steep hill. D3 can also keep
the transmission from cycling
between third and fourth gears in stop-and-go driving.
For faster acceleration when in D3 or
D4, you can get the transmission to
automatically downshift by pushing
the accelerator pedal to the floor.
The transmission will shift down one or two gears, depending on your
speed.
Second (2) — To shift to Second,
press the release button on the side
of the shift lever. This position locks
the transmission in second gear. It does not downshift to first gear
when you come to a stop. Second
gives you more power when climbing, and increased engine braking when
going down steep hills. Use second
gear when starting out on a slippery surface or in deep snow. It will help
reduce wheelspin. First (1) — To shift from Second to
First, press the release button on theside of the shift lever. With the lever
in this position, the transmission
locks in First gear. By upshifting and downshifting through 1, 2, D3 and D4,
you can operate this transmission much like a manual transmission
without a clutch pedal.

Driving
