POWER DOOR LOCKS (IF EQUIPPED)
Press the top of the control to
unlock all doors and the bottom to
lock all doors.
POWER SIDE VIEW MIRRORS (IF EQUIPPED)
To adjust your mirrors:
1. Select
to adjust the left
mirror or
to adjust the right
mirror.
2. Move the control in the direction
you wish to tilt the mirror.
3. Return to the center position to
lock mirrors in place.
CENTER CONSOLE (IF EQUIPPED)
Your vehicle may be equipped with a
variety of console features. These
include:
²Utility compartment with
cassette/compact disc storage
²Cupholders
²Coin holder slots
²Flip up armrest
Use only soft cups in the cupholder. Hard objects can injure you
in a collision.
UNLOCK
LOCK
Controls and features
73

The fuses are coded as follows:
Fuse/Relay
LocationFuse Amp
RatingPassenger Compartment Fuse
Panel Description
1 5A Power Mirror Switch
2 10A Daytime Running Lights (DRL),
Back-up Lamps, Transmission,
Passenger Air Bag Deactivation
Switch, Blower Motor Relay
3 7.5A Right Stop/Turn Trailer Tow
Connector
4 Ð Not Used
5 15A 4x4 Control Module
6 Ð Not Used
7 7.5A Left Stop/Turn Trailer Tow
Connector
8 Ð Not Used
9 7.5A Brake Pedal Position Switch
10 7.5A Speed Control Servo/Amplifier
Assembly, Generic Electronic
Module (GEM), Shift Lock
Actuator, Turn Signals
11 7.5A Instrument Cluster, 4x4, Main
Light Switch, Truck Central
Security Module (TCSM)
12 Ð Not Used
13 20A Brake Pedal Position Switch
14 10A or Not Used 10A: If equipped with Anti-Lock
Brake System (ABS) Control
Module
15 Ð Not Used
16 30A Windshield Wiper Motor, Wiper
Hi-Lo Relay, Wiper Run/Park
Relay
Roadside emergencies
163

Cleaning the interior fabric
Remove dust and loose dirt with a whisk broom or a vacuum cleaner.
Remove fresh spots immediately. Do not use household or glass cleaners.
These agents can stain and discolor the fabric. Use a mild soap and
water solution if necessary.
Cleaning and maintaining the safety belts
Clean the safety belts with a mild soap solution recommended for
cleaning upholstery or carpets. Do not bleach or dye the belts, because
these actions may weaken the belt webbing.
Check the safety belt system periodically to make sure there are no
nicks, tears or cuts. If your vehicle has been involved in an accident,
refer to theSafety belt maintenancesection in theSeating and safety
restraintschapter.
Inside windows
Use Ultra-Clear Spray Glass Cleaner (E4AZ-19C507±AA) for the inside
windows if they become fogged.
Cleaning mirrors
Do not clean your mirrors with a dry cloth or abrasive materials. Use a
soft cloth and mild detergent and water. Be careful when removing ice
from outside mirrors because you may damage the reflective surface.
Tonneau cover care (if equipped)
To avoid damage to the vinyl tonneau cover, do not use any silicone
based cleaner or conditioner. Do not use stiff bristle brushes or abrasive
materials or cleaners.
Hot waxes applied by commercial car washes can affect the cleanability
of vinyl material.
Using high water pressure or wand-type car washes against the vinyl
cover and tonneau frame rails may cause water leaks and possible seal
damage.
Maintenance and care
239

Comfort and convenience
Air conditioning
Battery warmer
Cargo organizers
Cargo retention net
Cargo shades (Super Cab 2 door)
Engine block heaters
Manual sliding rear window
Tire step
Underbody lighting
Travel equipment
Automatic headlamp system with DRL
Bed extender
Bed rail caps
Bed tent (Short bed, Styleside only)
Cellular phone holder
Compass mirror
Compass mirror with outside temperature reading
Daytime running lights
First aid kit
Fog lights
Heavy-duty battery
Peace of mind kit
Pickup box rails (tubular)
Removable bike carrier (bed mount/hitch mount)
Running boards/bars
Speed control
Trailer hitch (Class III)
Trailer hitch bars and balls
Trailer hitch wiring adaptor
Customer assistance
258

Cleaning your vehicle ...............234
engine compartment ..............236
exterior ....................234±235, 239
exterior lamps .........................238
instrument cluster lens ..........238
instrument panel ....................238
interior .....................................239
mirrors .....................................239
plastic parts ............................237
safety belts ..............................239
washing ....................................234
waxing .....................................234
wheels ......................................235
windows ..................................239
wiper blades ............................238
Climate control (see Air
conditioning or Heating) ............22
Clock ..........................32, 39, 48, 62
Clutch
fluid ..........................................195
operation while driving ..........136
recommended shift speeds ....137
Console ........................................73
Coolant
checking and adding ..............197
refill capacities ................201, 240
specifications ..................243, 245
Cruise control (see Speed
control) ........................................65
Customer Assistance ................158
Ford accessories for your
vehicle .....................................256
Ford Extended Service
Plan ..........................................249
Getting assistance outside
the U.S. and Canada ..............255
Getting roadside assistance ...158
Getting the service
you need .................................249Ordering additional owner's
literature .................................260
The Dispute Settlement
Board .......................................252
Utilizing the
Mediation/Arbitration
Program ...................................255
D
Daytime running lamps
(see Lamps) ................................20
Dipstick
automatic transmission
fluid ..........................................203
engine oil .................................189
Doors
door ajar warning .....................14
lubricant specifications ..........243
Driveline universal joint and
slip yoke ....................................207
Driving under special
conditions ..........................142±143
mud ..........................................142
sand .........................................142
snow and ice ...........................143
through water .................142, 144
E
Emergencies, roadside
jump-starting ..........................178
Emission control system ..........225
Engine ................................245±246
check engine/service
engine soon light ......................10
cleaning ...................................236
coolant .....................................197
idle speed control ...................207
Index
264

trailer towing ..........................144
Loading instructions .................146
Lubricant specifications ...243, 245
Lumbar support, seats ...............90
M
Manual transmission .................136
fluid capacities ........................240
lubricant specifications ..........245
reverse .....................................138
Mirrors
cleaning ...................................239
side view mirrors (power) .......73
Moon roof ....................................64
Motorcraft parts ................221, 240
O
Octane rating ............................219
Odometer .....................................18
Oil (see Engine oil) ..................189
Overdrive .....................................69
P
Panic alarm feature, remote
entry system ................................83
Parking brake ............................129
Parts (see Motorcraft parts) ....240
Power distribution box (see
Fuses) ........................................165
Power door locks ........................73
Power steering ..........................130
fluid, checking and adding ....202
fluid, refill capacity ................240fluid, specifications .........243, 245
Preparing to drive your
vehicle ........................................131
R
Radio ............................................29
Relays ........................................161
Remote entry system ...........81, 83
illuminated entry ......................85
locking/unlocking doors ...........82
panic alarm ...............................83
replacement/additional
transmitters ...............................84
replacing the batteries .............83
S
Safety belts (see Safety
restraints) ........................15, 91±96
Safety defects, reporting ..........262
Safety restraints ....................91±96
belt minder ...............................99
cleaning the safety
belts .................................102, 239
extension assembly ..................98
for adults .............................92±95
for children .....................112±113
lap belt ......................................97
warning light and
chime .............................12, 15, 98
Safety seats for children ..........114
Seat belts (see Safety
restraints) ....................................91
Seats ............................................89
child safety seats ....................114
SecuriLock passive anti-theft
system ....................................85±87
Index
267
