2001 FORD F150 keyless

4. Turn the ignition to OFF and remove the second coded key from the
ignition.
5. Within 10 seconds of turning the ignition to OFF, insert the new
unprogrammed key (new key/valet key) into the ignition and turn the
ignition from OFF to ON (maintain ignition in ON for at least one
second). This step will program your new key to a coded key.
6. To program additional new unprogrammed key(s), repeat this
procedure from step 1.
If the programming procedure was successful, the new coded key(s) will
start the vehicle's engine. The theft indicator (located on the instrument
panel) will light for three seconds and then go out.
If the programming procedure was not successful, the new coded key(s)
will not operate the vehicle's engine. The theft indicator will flash on and
off. Wait at least one minute and then repeat the procedure from step 1.
If failure repeats, bring your vehicle to your dealership to have the new
spare key(s) programmed.
REMOTE ENTRY SYSTEM (IF EQUIPPED)
Your vehicle is equipped with a remote entry system which allows you to:
²unlock the vehicle doors without a key.
²lock all the vehicle doors without a key.
²activate the personal alarm.
The remote entry features only operate with the ignition in the OFF
position.
If there is any potential remote keyless entry problem with your vehicle,
ensureALL key fobs(remote entry transmitters) are brought to the
dealership, to aid in troubleshooting.
Controls and features
66

Illuminated entry
The illuminated entry system will turn on the interior lights when the
remote transmitter unlock control is pressed.
The illuminated entry system will turn off the interior lights if the
ignition switch is turned to the ON position, or if the remote transmitter
lock control is pressed, or after 25 seconds of illumination.
The inside lights will not turn off if:
²they have been turned on with the dimmer control or
²any door is open.
The battery save feature will turn off the interior lights 45 minutes after
the last door is closed, even if the dimmer control is on.
Keyless entry system (if equipped)
With the keyless entry keypad, you can:
²lock or unlock the vehicle doors without using the key.
Your vehicle has a factory set 5 digit code that operates the keyless entry
system. You can also program your own 5 digit personal entry code. The
factory-set code is located:
²on the owner's wallet card in the glove compartment
²taped to the computer module.
When pressing the controls on the keyless entry keypad, press the
middle of the controls to ensure a good activation.
Programming your own personal entry code
To program your own code:
1. Enter factory set code (keypad will illuminate when pressed).
2. Press 1/2 control within five
seconds of step 1.
3. Enter your personal 5 digit code.
Enter each digit within five seconds
of previous one.
Do not set a code that includes five
of the same number or presents
them in sequential order. Thieves
can easily figure out these types of codes.
123
45678
90
Controls and features
71

Your personal code does not replace the permanent code that the
dealership gave you. You can use either code to unlock your vehicle. If a
second personal code is entered, the module will erase it in favor of the
new code.
If you wish to erase your personal code, use the following instructions:
1. Enter factory set code.
2. Press 1/2 control within five
seconds of step one.
3. Press 7/8 control and 9/0 control
at the same time within five seconds
of step 2.
The system will now only respond
to the factory set code.
Unlocking the doors with the keyless entry system
To unlock the driver door, enter either the factory set code or the
personal code (each digit must be pressed within five seconds of the
prior digit). The interior lamps will also illuminate.
To unlock all doors, enter the factory set code or personal code (driver
door unlocks) and press the 3/4 control within five seconds.
Locking the doors with the keyless entry system
It is not necessary to enter the factory or personal code prior to locking
all doors. To lock the doors:
²Press the 7/8 control and the 9/0 control at the same time.
Activating/deactivating autolock with the keyless entry system
Before following the activation or deactivation procedures, make sure
that the anti-theft system (if equipped) is not armed, ignition is off, and
all vehicle doors and liftgate window are closed.
1. Enter 5 digit entry code
2. Press and hold 7/8 control
3. Press and release 3/4 control while holding 7/8 control
4. Release 7/8 control.
The horn will chirp once if autolock was deactivated or twice (one short
and one long chirp) if autolock was activated.
To re-activate autolock, repeat steps 1±4.
123
45678
90
Controls and features
72

cap ...........................................177
capacity ...................................194
choosing the right fuel ...........176
comparisons with EPA fuel
economy estimates .................181
detergent in fuel .....................177
filling your vehicle
with fuel ....................174,177,178
filter, specifications .........178,194
fuel pump shut-off switch .....129
gauge .........................................13
improving fuel economy ........178
low fuel warning light ................8
octane rating ....................176,199
quality ......................................176
running out of fuel .................177
safety information relating to
automotive fuels .....................174
Fuses ...................................130,131
Garage door opener ....................53
Gas cap (see Fuel cap) ............177
Gas mileage
(see Fuel economy) .................178
Gauges .........................................13
battery voltage gauge ...............15
engine coolant
temperature gauge ...................14
engine oil pressure gauge ........16
fuel gauge ..................................13
odometer ...................................15
speedometer .............................14
tachometer ................................15
trip odometer ............................15
GAWR
(Gross Axle Weight Rating) .....120
calculating ...............................122
definition .................................120
driving with a heavy load ......120
location ....................................120
GVWR (Gross
Vehicle Weight Rating) .............120
calculating ........................120,122definition .................................120
driving with a heavy load ......120
location ....................................120
Hazard flashers .........................129
Headlamps ...................................17
aiming ......................................188
autolamp system .......................18
bulb specifications ..................188
daytime running lights .............17
flash to pass ..............................17
high beam ............................11,17
replacing bulbs .......................184
turning on and off ....................17
warning chime ..........................13
Heating ........................................43
heating and air
conditioning system .................43
Hood ..........................................149
Ignition .......................................199
positions of the ignition ...........46
Infant seats (see Safety seats) ..96
Inspection/maintenance
(I/M) testing ..............................183
Instrument panel
cleaning ...................................192
cluster ...................................8,192
lighting up
panel and interior .....................18
location of components ..............8
Jump-starting your vehicle ......142
Keyless entry system
autolock .....................................70
locking and unlocking doors ....72
programming entry code .........71
Keys
key in ignition chime ...............13
positions of the ignition ...........46
Lamps
autolamp system .......................18
bulb replacement
specifications chart ................188
cargo lamps ...............................18
Index
218
