MOTORCRAFT PART NUMBERS
Component 4.6L V8 engine 5.4L V8 engine
Air filter element FA-1634 FA-1634
Fuel filter FG-986B FG-986B
Oil filter FL-820-S FL-820-S
PCV valve EV-233 EV-233
Battery (standard) BXT-59 BXT-59
Battery (heavy duty) BXT-65-650 BXT-65-650
Spark plugs-platinum* AGSF-32P AWSF-22E
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
REFILL CAPACITIES
Fluid Ford Part
NameApplication Capacity
Brake fluid High
Performance
DOT 3
Motor
Vehicle
Brake FluidAll Fill to line on
reservoir
Engine
coolant
1Premium
Engine
Coolant4.6L V8 engine with
1 row radiator19.5L (20.6 quarts)
4.6L V8 engine with
2 row radiator21.9L (23.1 quarts)
5.4L V8 engine with
1 row radiator22.6L (23.9 quarts)
5.4L V8 engine with
2 row radiator24.1L (25.5 quarts)
Engine oil
(includes
filter
change)Motorcraft
SAE 5W-30
Super
Premium
Motor OilAll 5.7L (6.0 quarts)
Capacities and specifications
194
cap ...........................................177
capacity ...................................194
choosing the right fuel ...........176
comparisons with EPA fuel
economy estimates .................181
detergent in fuel .....................177
filling your vehicle
with fuel ....................174,177,178
filter, specifications .........178,194
fuel pump shut-off switch .....129
gauge .........................................13
improving fuel economy ........178
low fuel warning light ................8
octane rating ....................176,199
quality ......................................176
running out of fuel .................177
safety information relating to
automotive fuels .....................174
Fuses ...................................130,131
Garage door opener ....................53
Gas cap (see Fuel cap) ............177
Gas mileage
(see Fuel economy) .................178
Gauges .........................................13
battery voltage gauge ...............15
engine coolant
temperature gauge ...................14
engine oil pressure gauge ........16
fuel gauge ..................................13
odometer ...................................15
speedometer .............................14
tachometer ................................15
trip odometer ............................15
GAWR
(Gross Axle Weight Rating) .....120
calculating ...............................122
definition .................................120
driving with a heavy load ......120
location ....................................120
GVWR (Gross
Vehicle Weight Rating) .............120
calculating ........................120,122definition .................................120
driving with a heavy load ......120
location ....................................120
Hazard flashers .........................129
Headlamps ...................................17
aiming ......................................188
autolamp system .......................18
bulb specifications ..................188
daytime running lights .............17
flash to pass ..............................17
high beam ............................11,17
replacing bulbs .......................184
turning on and off ....................17
warning chime ..........................13
Heating ........................................43
heating and air
conditioning system .................43
Hood ..........................................149
Ignition .......................................199
positions of the ignition ...........46
Infant seats (see Safety seats) ..96
Inspection/maintenance
(I/M) testing ..............................183
Instrument panel
cleaning ...................................192
cluster ...................................8,192
lighting up
panel and interior .....................18
location of components ..............8
Jump-starting your vehicle ......142
Keyless entry system
autolock .....................................70
locking and unlocking doors ....72
programming entry code .........71
Keys
key in ignition chime ...............13
positions of the ignition ...........46
Lamps
autolamp system .......................18
bulb replacement
specifications chart ................188
cargo lamps ...............................18
Index
218
