Downloaded from www.Manualslib.com manuals search engine 20. Remove the (A) three bolts and position the (B) power steering pressure hose aside.
21. WARNING: Do not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel-related components. Highly flammable mixtures are
always present and may be ignited. Failure to follo w these instructions may result in personal injury.
Use Disconnect Tool to disconnect the fuel supply l ine from the fuel injection supply manifold.
22. Remove the (A) five nuts and remove the (B) exha ust manifold heat shield.
23. Remove the four exhaust manifold-to-three way ca talytic converter (TWC) nuts.
24. Remove one upper starter bolt and position the b racket aside.
25. Disconnect the transaxle fluid cooler lines from the transaxle.
102001 Escort Workshop Manual
6/27/2010http://www.fordtechservice.dealerconnection.com/pub s/content/~WS1F/~MUS~LEN/19/S...
Downloaded from www.Manualslib.com manuals search engine
26. Remove the A/C line bracket bolt.
27. Disconnect the A/C manifold and tube spring lock coupling at the accumulator/drier. For additional information, refer to
Section 412-03.
28. Disconnect the A/C manifold and tube spring lock coupling at the condenser. For additional information, refer to
Section 412-03.
29. Remove the accessory drive belt, the auto tensio ner and, if vehicle is equipped with A/C, the accessory drive belt idler. For additional information, refer to
Section 303-05.
30. Suction out the power steering fluid from the po wer steering reservoir.
31. NOTE: Position a drain pan under the power steering reser voir.
Disconnect the power steering lines.
Loosen the clamp and disconnect the (A) power steer ing reservoir pump hose (3691) at the reservoir. Disconnect the (B) power steering pressure hose (3A719).
32. Raise and support the vehicle. For additional in formation, refer to
Section 100-02.
33. Remove the (A) wheel nuts (1012) and the (B) fro nt wheel and tire assemblies.
