53. Attach the Engine Lifting Bracket on the left re ar side of the cylinder head.
54. Install the Engine Support Bar as shown.
55. Raise and support the vehicle. For additional in formation, refer to
Section 100-02.
56. Remove the transaxle support crossmember. 1. Remove the two crossmember nuts and the two cross member bolts.
2. Remove the two LH front engine support insulator (6038) nuts.
3. Remove the two transmission support insulator (60 68) nuts.
57. Lower the vehicle.
58. Remove the four nuts and the transaxle mount.
102001 Escort Workshop Manual
6/27/2010http://www.fordtechservice.dealerconnection.com/pub s/content/~WS1F/~MUS~LEN/19/S...
Downloaded from www.Manualslib.com manuals search engine
59. Remove the RH engine support insulator through b olt.
60. Remove the Engine Support Bar.
61. NOTE: Install a universal lifting eye on the transaxle an d use for balance, if necessary.
Attach a suitable lifting device and remove the eng ine and transaxle assembly.
62. Separate the transaxle from the engine (6007).
63. Mount the engine on a stand and remove the lifti ng device.
