Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-9 Remote Keyless Entry (If Equipped)
2
-13 Trunk
2
-18 Theft
2
-19 Content Theft-Deterrent (Option)
2
-20 Vehicle Customization Settings
2
-28 Passlock

2-29 New Vehicle ªBreak-Inº
2
-29 Ignition Positions
2
-30 Starting Your Engine
2
-33 Engine Coolant Heater (Option)
2
-34 Automatic Transaxle Operation
2
-39 Parking Brake
2
-40 Shifting Into PARK (P)
2
-43 Shifting Out of PARK (P)
2
-43 Parking Over Things That Burn
2
-44 Engine Exhaust2
-44 Running Your Engine While You're Parked
2
-45 Tilt Wheel
2
-46 Turn Signal/Multifunction Lever
2
-52 Exterior Lamps
2
-55 Interior Lamps
2
-57 Mirrors
2
-63 Accessory Power Outlet
2
-64 Auxiliary Power Connection (Power Drop)
2
-64 Cellular Phone Readiness Package (Option)
2
-65 OnStar
System (If Equipped)
2
-68 Power Sunroof (Option)
2
-69 HomeLink
Transmitter (Option)
2
-74 The Instrument Panel -- Your
Information System
2
-76 Instrument Panel Cluster
2
-79 Warning Lights, Gages and Indicators
2
-88 Message Center
2
-97 Driver Information Center (DIC) (Option)

2-64
Auxiliary Power Connection
(Power Drop)
Your vehicle is
equipped with
an auxiliary
power connection.
This feature provides power, ground and accessory
wires which can be accessed to add aftermarket
electrical equipment to your vehicle. It is located on the
passenger's side of the vehicle, under the glove box, and
is labeled with a wire function and fuse rating. For
information on accessing the connection and electrical
hookup, please refer to your service manual. To order a
service manual, see ªService Publications, Orderingº in
the Index.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
Cellular Phone Readiness
Package (Option)
Your vehicle may be equipped with a wiring harness that
will work with a dealer
-installed GM Hughes
portable
phone. The phone has integrated features with the radio
and car audio speakers. See your dealer for more details.

3-17
Accessing RDS Stations:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST/AUDIO knob to display the program type list.
2. Turn knob either clockwise or counterclockwise to
select a program type. List is alphabetical. If you
select ANY TYPE your radio will seek to the first
PTY available.
3. Push SEEK TYPE button to activate search.
TRAF: Press this button to receive traffic announcements.
If the current tuned station does not broadcast traffic
announcements, the radio will seek to a station that does.
The TRAF icon will flash on the display. When the radio
finds a station that broadcasts traffic announcements,
it will stop. If no station is found, NO TRAF will appear
on the display.
Traffic Interrupt Feature: Your radio can be
programmed to interrupt the playback of a cassette
tape, CD or FM radio by enabling the traffic interrupt
feature. Press the TRAF button once to seek to an
RDS station that supports the traffic interrupt feature
if the current tuned station does not. The TRAF icon
will flash on the display when seeking for a station that
supports traffic interrupt. When the traffic interrupt
feature is on, TRAF will appear on the display.When a traffic announcement comes on the tuned radio
station, you will hear it, even if the volume is muted or
a cassette tape or compact disc is playing. The TRAF
icon and TRAFFIC will appear on the display while
the traffic announcement plays. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.
VOL: Turn this knob clockwise to increase volume when
RDS interrupts regular play. Turn it counterclockwise to
decrease volume.
INFO: If the current station has a message, the INFO
icon will appear on the display. These text messages are
from the RDS broadcaster to the listening public and
may be general information such as artist and song title,
call in phone numbers, etc. Press this button to see
the message. If the whole message does not appear
on the display, parts of the message will appear every
three seconds until the message is completed. To scroll
through the message at your own speed, press the INFO
button again for less than one second. A new group of
words will appear on the display. Once the completed
message has been displayed, INFO will disappear from
the display until another new message is received. The
old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to.

3-27
TRAF: Press this button to receive traffic
announcements. If the current tuned station does not
broadcast traffic announcements, the radio will seek
to a station that does. The TRAF icon will flash on the
display. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NO TRAF will appear on the display.
Traffic Interrupt Feature: Your radio can be
programmed to interrupt the playback of a cassette
tape, CD or FM radio by enabling the traffic interrupt
feature. Press the TRAF button once to seek to an RDS
station that supports the traffic interrupt feature if the
current tuned station does not. The TRAF icon will flash
on the display when seeking for a station that supports
traffic interrupt. When the traffic interrupt feature is on,
TRAF will appear on the display.
When a traffic announcement comes on the tuned radio
station, you will hear it, even if the volume is muted or
a cassette tape or compact disc is playing. The TRAF
icon and TRAFFIC will appear on the display while
the traffic announcement plays. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.VOL: Turn this knob clockwise to increase volume when
RDS interrupts regular play. Turn it counterclockwise to
decrease volume.
INFO: If the current station has a message, the INFO
icon will appear on the display. These text messages are
from the RDS broadcaster to the listening public and
may be general information such as artist and song title,
call in phone numbers, etc. Press this button to see the
message. If the whole message does not appear on the
display, parts of the message will appear every three
seconds until the message is completed. To scroll
through the message at your own speed, press the
INFO button again for less than one second. A new
group of words will appear on the display. Once the
complete message has been displayed, INFO will
disappear from the display until another new message
is received. The old message can be displayed by
pressing the INFO button until a new message is
received or a different station is tuned to.

3-36
VOL: Turn this knob clockwise to increase volume when
RDS interrupts regular play. Turn it counterclockwise to
decrease volume.
INFO: If the current station has a message, INFO will
appear on the display. These text messages are from the
RDS broadcaster to the listening public and may be
general information such as artist and song title, call in
phone numbers, etc. Press this button to see the
message. If the whole message does not appear on
the display, parts of the message will appear every
three seconds until the message is completed. To scroll
through the message at your own speed press the INFO
button again for less than one second. A new group
of words will appear on the display. Once the complete
message has been displayed, INFO will disappear from
the display until another new message is received. The
old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to.P-TYPE LIST: Turn this knob clockwise or
counterclockwise to select the Program Type (PTY) you
want to listen to. TYPE and a PTY will appear on the
display. Press the SEEK TYPE button and the radio
will seek to the first RDS broadcaster of the selected
P
-TYPE. If the radio cannot find the desired P-TYPE,
NONE will appear on the display and the radio will
return to the last station you were listening to.
SEEK TYPE: Press this button to go to a station with
the last selected PTY. TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off alert
announcements. ALERT! appears on the display when an
alert announcement plays. When an alert announcement
comes on the tuned radio station, you will hear it, even if
the volume is muted or a cassette tape or compact disc
is playing. If the cassette tape or compact disc player is
playing, play will stop for the announcement and resume
when the announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.

3-43 Understanding Radio Reception
AM
The range for most AM stations is greater than for FM,
especially at night. The longer range, however, can
cause stations to interfere with each other. AM can pick
up noise from things like storms and power lines. Try
reducing the treble to reduce this noise if you ever get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km).
Tall buildings or hills can interfere with FM signals,
causing the sound to come and go.
Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be
loud and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.To help avoid hearing loss or damage:

Adjust the volume control to the lowest setting.

Increase volume slowly until you hear comfortably
and clearly.
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you
can add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Delco Electronics
radio or other systems, and even damage them.
Your vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check Federal rules
covering mobile radio and telephone units.

3-46 Backglass Antenna
Your AM FM antenna is integrated with your rear
window defogger, located in the rear window. Be sure
that the inside surface of the rear window is not
scratched and that the lines on the glass are not
damaged. If the inside surface is damaged, it could
interfere with radio reception.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the rear defogger grid and affect your radio's
ability to pick up stations clearly. The repairs
wouldn't be covered by your warranty.
Because this antenna is built into your rear window,
there is a reduced risk of damage caused by car washes
and vandals.If you choose to add a cellular telephone to your vehicle,
and the antenna needs to be attached to the glass, be sure
that you do not damage the grid lines for the AM FM
antenna. There is enough space between the lines to
attach a cellular telephone antenna without interfering
with radio reception.
Vehicle Customization Settings
Your audio system can be used to control vehicle
customization settings using the DISP button when
the radio is off. See ªVehicle Customization Settingsº
in the Index.
Chime Level Adjustment
The radio is the vehicle chime producer. To change the
volume level, press and hold pushbutton six with the
ignition on and the radio power off. The chime volume
level will change from the normal level to loud, and
LOUD will be displayed on the radio. To change back
to the default or normal setting, press and hold the
pushbutton six again. The chime level will change
from the loud level to normal, and NORMAL will be
displayed. Each time the chime volume is changed,
three chimes will sound as an example of the new
volume selected. Removing the radio and not replacing
it with a factory radio or chime module will disable
vehicle chimes.

4-2
Defensive Driving
The best advice anyone can give about driving is:
Drive defensively.
Please start with a very important safety device in your
vehicle: Buckle up. See ªSafety Beltsº in the Index.Defensive driving really means ªbe ready for anything.º
On city streets, rural roads or freeways, it means
ªalways expect the unexpected.º
Assume that pedestrians or other drivers are going to be
careless and make mistakes. Anticipate what they might
do. Be ready for their mistakes.
Rear
-end collisions are about the most preventable of
accidents. Yet they are common. Allow enough
following distance. It's the best defensive driving
maneuver, in both city and rural driving. You never
know when the vehicle in front of you is going to brake
or turn suddenly.
Defensive driving requires that a driver concentrate on
the driving task. Anything that distracts from the
driving task
-- such as concentrating on a cellular
telephone call, reading, or reaching for something on
the floor
-- makes proper defensive driving more
difficult and can even cause a collision, with resulting
injury. Ask a passenger to help do things like this, or
pull off the road in a safe place to do them yourself.
These simple defensive driving techniques could
save your life.
