2001 CHEVROLET CAMARO Owners Manual

2-71
5. Pull the sunshade back a little and remove the backing
paper from the Velcro buttons. Push the sunshade back
into place, sticking the Velcro to the glass.
6. Install the T
-top, close the latch and lock the
T
-top. Repeat the previous steps for the passenger
side sunshade.
You can store the sunshades two different ways:

When the T
-tops are in use, store the sunshades in
their storage area in the rear of the vehicle. Make
sure the cargo cover is in its closed, upright position.

When you have the T
-tops off and in their storage
slots, store the sunshades on the T
-tops, in their
installed position.

2-72
Convertible Top (If Equipped)
The following procedures explain the proper operation
of your convertible top.
Lowering Your Convertible Top
NOTICE:
Don't leave your convertible out with the top
down for any long periods of time. The sun and
the rain can damage your seat material and other
things inside your vehicle.
1. It is recommended that you park on a level surface.
Set the parking brake firmly. Shift an automatic
transmission into PARK (P) or a manual
transmission into REVERSE (R).
2. Turn the ignition to ACC or RUN.
3. Lower both sun visors.
NOTICE:
It is not recommended that you raise or lower the
top while the vehicle is moving.
NOTICE:
Don't lower the top if it is damp or wet. When
the top is down, trapped water can cause stains,
mildew and damage to the inside of your vehicle.
Be sure to dry off the top before you lower it.
NOTICE:
It is not recommended to lower the top if the vehicle
is out in cold weather (0
F/
-18
C or lower), or you
may damage top components.
NOTICE:
Before lowering the convertible top into the
storage area, be sure there are no objects in the
way of the folded, stored top. The weight of a
stored top on items in the storage area will cause
the convertible top back glass to break.

2-73
4. Unlock the front of the convertible top by pushing on
the smaller part of the latch, then pulling down on the
larger part of the latch. Be sure the hook on the latch
that attaches into the hole at the windshield releases.
5. Make sure there is
nothing or anyone on or
around the top. Push and
hold the down arrow on
the lower part of the
convertible TOP switch.
The switch is located next to your cigarette lighter.
The top will automatically lower into the storage area.

2-74 Installing the Boot Cover
After lowering the convertible top, you'll want to install
the boot cover. The three
-piece boot cover is stored in a
bag in the hatch area.
1. Flip the two convertible top latches to the
closed position.
2. Open the hatch and remove the two side covers and
the middle section from the storage bag.
3. Install the two side covers by inserting the tab into the
front seatbelt cover. Lower the covers onto the vehicle.
4. Install the middle section of the cover by sliding the
tabs into the slots on the right side cover. Lower the
cover and insert the latch.
5. Close the hatch.

2-75 Removing Your Boot Cover
1. Open the hatch.
2. Remove the middle piece of the cover by pushing in
on the latch and lifting up on the cover.
3. Remove the two side pieces of the boot cover by
lifting the rear cover and sliding them out of their slots.

2-76
4. Store each piece of the cover in its separate
compartment according to the graphic printed inside
of the storage bag. Store the bag in the hatch and
close the hatch.
5. Disengage the two convertible top latches.

2-77 Raising Your Convertible Top
1. Park on a level surface and set the parking brake
firmly. If you have an automatic transmission, shift
into PARK (P). If you have a manual transmission,
shift into REVERSE (R).
2. Turn the ignition to ACC or RUN (or RAP must
be active).
3. Then lower both sun visors and lower both windows
at least 3 inches (8 cm). If the boot cover is in place,
it must be removed first.
NOTICE:
It is not recommended that you raise or lower the
top while the vehicle is moving.
4. Push and hold the up
arrow on the top part
of the convertible
TOP switch.

2-78
5. Pull down on the latches and align the hooks with
the holes. Push forward on the larger part of the latch
until it clicks. Do not force the latch. If it is hard to
lock, the top is not properly aligned.
NOTICE:
The convertible top may be tight when pushing
forward on the latch when your vehicle is new,
but it will loosen up with time. Make sure that
the hooks are properly aligned before using any
kind of force.
If your vehicle has a power loss, such as a dead battery,
you can still raise the top manually by turning the valve
in the driver's side of the hatch.
