2001 CADILLAC DEVILLE key

2-27
Column Shifter (Digital and Analog Cluster similar)
PARK (P): This position locks the front wheels. It's the
best position to use when you start the engine because
your vehicle can't move easily.
CAUTION:
It is dangerous to get out of your vehicle if the
shift lever is not fully in PARK (P) with the
parking brake firmly set. Your vehicle can roll.
CAUTION: (Continued)
CAUTION: (Continued)
Don't leave your vehicle when the engine is
running unless you have to. If you have left the
engine running, the vehicle can move suddenly.
You or others could be injured. To be sure your
vehicle won't move, even when you're on fairly
level ground, always set your parking brake and
move the shift lever to PARK (P).
See ªShifting Into PARK (P)º in the Index.
If you're pulling a trailer, see ªTowing a Trailerº
in the Index.
Ensure the shift lever is fully in PARK (P) before
starting the engine. Your vehicle has an automatic
transaxle shift lock control system. You have to fully
apply your regular brakes before you can shift from
PARK (P) when the ignition key is in ON. If you cannot
shift out of PARK (P), ease pressure on the shift
lever
-- push the shift lever all the way into PARK (P)
as you maintain brake application. Then move the shift
lever into the gear you wish. See ªShifting Out of
PARK (P)º in the Index.

2-34

Move the lever up as far as it will go.
3. With your right foot still holding the brake pedal
down, set the parking brake.
4. Turn the ignition key to OFF.
5. Remove the key and take it with you. If you can
leave your vehicle with the ignition key in your
hand, your vehicle is in PARK (P).
Console Shift Lever (If Equipped)
1. Hold the brake pedal down with your right foot.
2. Move the shift lever into PARK (P).
3. With your right foot still holding the brake pedal
down, set the parking brake.
4. Turn the ignition key to OFF.
5. Remove the key and take it with you. If you can
leave your vehicle with the ignition key in your
hand, your vehicle is in PARK (P).

2-36
Shifting Out of PARK (P)
Your vehicle has an automatic transaxle shift lock
control system. You have to fully apply your regular
brakes before you can shift from PARK (P) when the
ignition key is in ON. See ªAutomatic Transaxle
Operationº in the Index.
If you cannot shift out of PARK (P), ease pressure on
the shift lever
-- push the shift lever all the way into
PARK (P) as you maintain brake application. Then
move the shift lever into the gear you want. If you ever
hold the brake pedal down, but still can't shift out of
PARK (P), try the following:
1. Turn the ignition to ACCESSORY.
2. Apply and hold the brake until the end of Step 4.
3. Shift to NEUTRAL (N).
4. Start the vehicle and then shift to the drive gear
you want.
5. Have the vehicle fixed as soon as you can.
Shift Lock Release
This vehicle is equipped with an electric shift lock
release system. The shift lock release is designed to do
the following:

Prevent the ignition key from being removed unless
the shift lever is in PARK (P), and

Prevent movement of the console shift lever (DTS
only) out of PARK (P) unless the ignition is in a
position other than OFF. The shift lock release is
always functional except in the case of a dead battery
or low voltage (less than 9 V) battery.
If your vehicle has a dead battery or a battery with low
voltage, there is a procedure that will allow you to
override the shift lock release.

2-37
The following procedure allows the ignition to be turned
to OFF and for key removal in case of a dead or low
voltage battery.
1. Verify that the shift lever
is in PARK (P).
2. Locate the override
access slot underneath
the steering column
below the lock cylinder.
3. Remove the override access slot cap.
4. Insert a screwdriver into the access slot, press in
and hold.
5. Turn the ignition to OFF.
6. Remove the screwdriver from the slot.
7. Remove the key from the ignition.
8. Replace the override access slot cap.The following procedure applies only to vehicles with
the console shift lever and is used to shift the transaxle
out of PARK (P) (if the vehicle needs to be towed,
for example) in case of a dead or low voltage battery.
The console shift lock
release is located on the
front of the center console.
To access the shift lock release, do the following:
1. Verify that the shift lever is in PARK (P).
2. Pull up the rubber mat located on the front of the
center console.
3. Remove the shift lock release hole cover by prying it
open with a coin or small diameter screwdriver.

2-54
Light Sensor
The light sensor for the DRL and the Twilight Sentinel
is located in the center of the front defogger grille.
If you cover the sensor, it will read ªdarkº and the
lamps or the HEADLAMPS SUGGESTED message
will be on whenever the ignition is on.
Exterior Lighting Battery Saver
If the headlamp or manual parking lamp control
has been left on, the exterior lamps will turn off
approximately 10 minutes after the ignition is turned
to OFF. This protects draining the battery in case you
have accidentally left the headlamps or parking lamps
on. If you need to purposely leave the lamps on for
more than 10 minutes with the ignition in OFF or
ACCESSORY, turn the manual control knob off and
then back on. To delay the lamps from turning off,
see ªTwilight Sentinelº in the Index.
If the headlamp switch is turned on after the ignition key
is moved to either OFF or ACCESSORY, the lamps will
not time out.

2-55
Interior Lamps
Instrument Panel
Intensity/Brightness Control
The displays automatically dim when it becomes dark
outside and your lights are on. The displays automatically
brighten when it becomes light outside. Backlighting
will only remain active as long as the parking lamps
are on and it is dark outside. The brightness of the
backlighting can be adjusted by using the instrument
panel brightness control.
The button is located to
the right of the Twilight
Sentinel control. Push the
button in to release it to
the outward position.
Turn the button counterclockwise to dim and clockwise
to brighten the lighting. Push the button in to return it to
the original storage position.
Courtesy Lamps
The courtesy lamps are located on the headliner above
the rear seat. These lamps come on by turning the
instrument panel brightness control fully clockwise or
when any door is opened and it is dark outside. Puddle
lamps are located on the bottom of the front and rear
door trim.
Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door switches and
to the lamp control knob when a door is opened or if
you press the remote keyless entry transmitter unlock
button. If activated due to the transmitter, the lighting
will remain active for about 40 seconds. Since the
illuminated entry system uses the light sensor, it must be
dark outside in order for the courtesy lamps to turn on.
The courtesy lamps turn off approximately 25 seconds
after the last door is closed. They will dim to off if the
ignition key is placed in ON, or immediately deactivate
if the power locks are activated.

2-56
Parade Dimming
This feature prohibits dimming of the digital displays
and backlighting during daylight hours when the key is
in the ignition and the headlamps are on. This feature
operates with the light sensor for the Twilight Sentinel
and is fully automatic. When the light sensor reads
darkness outside and the parking lamps are active,
the digital displays can be adjusted by turning the lamp
control knob counterclockwise to dim and clockwise to
brighten lighting.
Reading Lamps
The reading lamps are located on the overhead console
on the headliner and in the rear door opening. These
lamps come on automatically when any door is opened
and it is dark outside. For manual operation, press the
button to turn them on. Press it again to turn them off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle at
a higher RPM (revolutions per minute) setting than
normal to make sure the battery charges. High electrical
loads may occur when several of the following are
on: headlamps, high beams, fog lamps, rear window
defogger, high blower fan, heated seats and engine
cooling fans.

2-61
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Glove Box
The glove box is located in front of the passenger's seat.
To lock the glove box door, insert the master key into
the lock cylinder and turn it clockwise. Turn the key
counterclockwise to unlock the door.
Front Storage Area (If Equipped)
The front storage area comes with a coinholder, a
storage compartment for CDs or tapes, an optional
cellular telephone and a dual cupholder.
Map Pocket
The map/storage pockets are located on each front door
and on the rear door trim as well as on the back of both
front seatbacks.
Center Instrument Panel Compartment
(If Equipped)
This storage compartment is located in the center of the
instrument panel below the radio. Pull the door out to
reveal the accessory power outlet and storage
compartment. To clean the storage compartment, lift out
while pulling on the sides.
Center Console Storage (If Equipped)
The center console includes a storage tray, storage
compartment for CDs or tapes, a dual cupholder that
unfolds, a coinholder, an optional cellular telephone and
an armrest. The cupholder can be opened by pressing on
the surface panel located in front of the armrest and
unfolding it.
