2001 CADILLAC DEVILLE display

2-106
SERVICE TPM SYSTEM - 51: When this message is
displayed, the Tire Pressure Monitor (TPM) system is
not working properly. See your dealer for service.
SERVICE TRANSMISSION
- 100: See your dealer
for repair.
SERVICE VEHICLE SOON
- 3: This message is
displayed when a non
-emissions related powertrain
malfunction occurs. Have your vehicle serviced by a
technician as soon as possible.
SPEED LIMITED TO 90
- 113: A failure in the
suspension control system has occurred when this
message appears. The Powertrain Control Module
(PCM) determines the speed to which your vehicle
is limited. Have your vehicle serviced if this
message appears.
STARTING DISABLED REMOVE KEY
- 33: This
message will appear when the Personalized Automotive
Security System (PASS
-Key
III) senses that an
improper ignition key is being used to try to start the
vehicle. Check the ignition key for damage. If it is
damaged, it may need to be replaced. If you see no
damage, remove the key and try to start the vehicle
again. If it still does not start, try another ignition key.THEFT ATTEMPTED
- 40: This message is
displayed if the theft system has detected a break
-in
attempt while you were away from your vehicle.
TOP SPEED FUEL CUT
-OFF - 111 : This message
will appear when the Powertrain Control Module (PCM)
senses that the maximum speed for your vehicle has
been reached. The speed of your vehicle will surge as
the fuel supply is cut off. This allows your vehicle to
stay in a safe tire operating range. The top speed is set
based on the top speed rating of the tires.
TRACTION ENGAGED
- 91: When your traction
control system is limiting wheel spin, the TRACTION
ENGAGED message will be displayed. Slippery road
conditions may exist if this message is displayed, so
adjust your driving accordingly. This message will stay
on for a few seconds after the traction control system
stops limiting wheel spin.
TRACTION OFF
- 89: This message will be displayed
after the traction control has been turned off by the
button on the center console.

2-107
TRACTION READY - 90: This message informs
the driver that the traction control system is available.
This occurs when the traction control switch on the
console has been returned to on (pressing the button
once turns the traction control system off: pressing the
button again turns the system back on). This message
will automatically disappear from the display after
five seconds.
TRACTION SUSPENDED
- 56: This message
displays when the traction control system has been
temporarily shut off because your vehicle's brakes have
overheated. This message does not indicate a problem
with your vehicle's traction control system. After a
few minutes, the traction control system will be
available again and the TRACTION READY message
will appear.TRANS HOT IDLE ENGINE
- 112: This message
indicates that the transaxle fluid in your vehicle is too
hot. Stop and allow your vehicle to idle until it cools
down or until this message is removed.
TRUNK OPEN
- 24: This message indicates that the
trunk is open when the ignition is on.
TURN SIGNAL ON
- 20: This message is a reminder,
after driving about a mile, that you have the turn signal
on. A multiple chime will also sound when this message
is displayed.
VEHICLE OVERSPEED
- 52: This message is
displayed when the vehicle speed exceeds a certain limit
as required by some export countries. A continuous
chime will also sound when this message is displayed.

2-108
Vehicle Programming and
Personalization Features
(If Equipped)
If your vehicle is equipped with personalization,
you can program certain features to a preferred setting
for up to two people. If your vehicle does not have
personalization then some of the features on your
vehicle have been programmed for all drivers. On all
vehicles, other features such as HVAC settings, radio
preset settings, exterior lighting at unlock, remote lock
and unlock confirmation, and automatic door locks have
already been programmed for your convenience. If the
vehicle is equipped with personalization then the seat
position, steering column position (if equipped) and
outside mirror position can also be programmed.
The Navigation screen preferences (if equipped) will
remain at the last set position.
If your vehicle is equipped with personalization the
driver's preferences are recalled by pressing the unlock
button on the remote keyless entry transmitter or by
pressing the appropriate memory button ª1º or ª2º
located on the driver's door. Certain features can be
programmed not to recall until the key is placed in the
ignition. To change feature preferences you must enter
feature programming (see below).
Entering Feature Programming
To begin programming, the ignition must be in ON,
your vehicle in PARK (P), and if your vehicle has
memory, you must press the appropriate memory button
ª1º or ª2º, located on the driver's door panel, prior to
programming. The display will show either ª1º or ª2º,
depending on which was selected. Press the INFO
button one or more times until the FEATURE
PROGRAMMING prompt appears on the DIC display.
Press the ON/OFF button to enter FEATURE
PROGRAMMING. To exit, press the INFO RESET
or INFO buttons.
Remote Recall Memory (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the REMOTE
RECALL MEMORY prompt appears. To turn the
feature on, press the ON/OFF button until ON is
displayed on the DIC. The seat and mirror memory
settings that have been previously programmed can be
recalled by pressing the unlock button on the remote
keyless entry transmitter. The steering column will
move when the key is inserted in the ignition and turned
to ON. To turn the feature off, press the ON/OFF button
until OFF is displayed.

2-109
Key in Recall Memory (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the KEY IN
RECALL MEMORY prompt appears on the DIC
display. To turn the feature on, press the ON/OFF button
until ON appears. The seat and mirror memory settings
that have been previously programmed will be recalled
when the key is inserted in the ignition. The steering
column will move when the key is turned to ON.
To turn the feature off, press the ON/OFF button until
OFF appears.
Auto Exit Seat (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the AUTO EXIT
SEAT prompt shows on the DIC display. This feature
will move the seat to the driver's exit position that was
previously programmed when the ignition is turned off
and the driver's door is opened. To turn this feature on,
press the ON/OFF button until ON appears on the DIC.
To turn this feature off, press the ON/OFF button until
OFF shows.
Auto Exit Steering Wheel (If Equipped)
Press the down arrow on the INFO button one or more
times until the AUTO EXIT STRG WHEEL prompt
appears on the DIC display. This feature will move the
column to the driver's previously stored exit position
when the ignition is turned off and the driver's door
is opened.
Lights Flash at Unlock
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the LIGHTS
FLASH AT UNLOCK prompt appears. To turn this
feature on, press the ON/OFF button until ON is
displayed on the DIC. If all the doors are closed, the
parking lamps will flash twice when the unlock button
on the remote keyless entry transmitter is pressed.
The lamps will not flash if the manual parking lamps or
headlamps are active. To turn the feature off, press the
ON/OFF button until the OFF prompt appears.

2-110
Lights Flash at Lock
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the LIGHTS
FLASH AT LOCK prompt appears on the DIC display.
To turn the feature on, press the ON/OFF button until
ON appears. If all the doors are closed, the parking
lamps will flash once when the lock button on the
remote keyless entry transmitter is pressed. To turn the
feature off, press the ON/OFF button until OFF appears.
This feature will not work if any door is open.
Horn Sounds at Lock
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the HORN
SOUNDS AT LOCK prompt appears on the DIC
display. To turn the feature on, press the ON/OFF button
until ON appears. If all the doors are closed, the horn
will sound once when the lock button on the remote
keyless entry transmitter is pressed. To turn the feature
off, press the ON/OFF button until OFF appears.
This feature will not work if any door is open.
Exterior Lights at Unlock
This personalization feature enables the driver to
program the exterior lamps to turn on or to remain off
when using the remote keyless entry transmitter to
unlock the vehicle.
During dark or night conditions, if exterior lighting is
selected, the parking lamps, taillamps, reverse lamps,
high
-beam headlamps, etc. will turn on for about
20 seconds or until a door is opened, the key is turned
out of OFF or the remote keyless entry transmitter is
used to lock the vehicle.
To turn the feature on, press the ON/OFF button
until ON is displayed. To turn the feature off,
press the ON/OFF button until OFF is displayed.
Doors Lock in Gear
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the DOORS
LOCK IN GEAR prompt appears. This feature will
automatically lock all doors when the vehicle is shifted
out of PARK (P) and all doors are closed. To turn the
feature on, press ON/OFF until ON is displayed on the
DIC. To turn the feature off, press ON/OFF until OFF
is displayed.

2-111
Driver Unlock in PARK (P)
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the DRIVER
UNLOCK IN PARK (P) prompt appears. This feature
will automatically unlock only the driver's door when
the vehicle is shifted into PARK (P). To turn the feature
on, press ON/OFF until ON is displayed on the DIC.
To turn the feature off, press ON/OFF until OFF
is displayed.
Driver Unlock Key Off
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the DOORS
UNLOCK KEY OFF prompt appears. This feature will
automatically unlock the driver's door when the ignition
key is turned to OFF. To turn the feature on, press
ON/OFF until ON is displayed on the DIC. To turn the
feature off, press ON/OFF until OFF is displayed.
Doors Unlock in PARK (P)
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the DOORS
UNLOCK IN PARK prompt appears. This feature
will automatically unlock all doors when the vehicle is
shifted into PARK (P). To turn the feature on, press
ON/OFF until ON is displayed on the DIC. To turn the
feature off, press ON/OFF until OFF is displayed.
Doors Unlock Key Off
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the DOORS
UNLOCK KEY OFF prompt appears. This feature will
automatically unlock all doors when the ignition key is
turned to OFF. To turn the feature on, press ON/OFF
until ON is displayed on the DIC. To turn the feature
off, press ON/OFF until OFF is displayed.

2-112
Mirror to Curb In Reverse (If Equipped)
Press the down arrow on the INFO button one or more
times until the MIRROR TO CURB IN REV prompts
appears on the DIC display. This feature will move the
passenger's outside rearview mirror to a curb view
position when the shifter is placed in REVERSE (R)
and it will return the mirror to the last known
driving position when the shifter is moved out of
REVERSE (R). To turn this feature on, press the
ON/OFF button until ON is displayed on the DIC.
To turn the feature off, press the ON/OFF button
until OFF is displayed. See ªCurb View Assist Mirrorº
in the Index for more information.
Tire Pressure Display (If Equipped)
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the TIRE
PRESSURE DISPLAY prompt appears. This feature
will allow each of the four (left front, right front, left
rear, right rear) tire pressure readings to be displayed
when using the INFO button to scroll through the
DIC displays. To turn the feature on, press ON/OFF
until ON is displayed on the DIC. To turn the feature off, press ON/OFF until OFF is
displayed. Even with this feature programmed to be
turned off, a low or high tire pressure condition will still
cause the CHECK TIRE PRESSURE message to be
displayed on the DIC. See ªDriver Information Center
(DIC) Messagesº in the Index for more information.
Driver's Names Set/Recall (If Equipped)
After the FEATURE PROGRAMMING prompt is
displayed on the DIC and the ON/OFF button is pressed,
the prompts DRIVER NO 1 or DRIVER NO 2 will
appear. These prompts correspond to which remote
keyless entry transmitter button or memory recall button
has been pressed on the driver's door armrest. You may
have your name and a second driver's name displayed
here, replacing the prompts DRIVER NO 1 and
DRIVER NO 2. A dealership can program your vehicle
to display the names you want. The names will appear
whenever the key is turned to ON only if remote keyless
entry transmitters 1 or 2 are used to enter the vehicle or
buttons 1 or 2 on the driver's door are pressed.

2-113
Comfort Controls and Radio
System Personalization
These features allow both drivers to personalize their
own climate control settings as well as their radio
settings. For more information, see ªClimate Control
Personalizationº and ªRadio Personalizationº in
the Index.
Continuous Variable Road Sensing
Suspension (CVRSS) (If Equipped)
The CVRSS automatically adjusts the ride of your
vehicle. Automatic ride control is achieved through a
computer used to control and monitor the suspension
system. The controller receives input from various
sensors to determine the proper system response.
If the controller detects a problem within the system,
the DIC will display a SERVICE SUSPENSION SYS
message. If this message appears, have your vehicle
serviced at your dealership.
Oil Life Indicator
This feature lets you know when to change the engine
oil. It's based on the engine oil temperatures and your
driving patterns. To see the display, press the INFO
button several times until ENGINE OIL LIFE appears.
If you see 99% ENGINE OIL LIFE, 99 percent of your
current oil life remains.
