Page 12 of 215

BMW 330Ci CONVERTIBLE 2001 E46 Owners Manual
Contents

Repairs
Advanced technology
Technical data

Replacement procedures:

Onboard tool kit166
Windshield wiper blades166
Lamps and bulbs166
Changing a wheel173
Battery176
Fuses179
Microfilte

Page 160 of 215

BMW 330Ci CONVERTIBLE 2001 E46 Owners Manual 160n
Vehicle storage
If you plan on parking the vehicle
for more than three months, have
the maintenance operations described
on this page performed.<
Preparations for storageHave your BMW center p

160n
Vehicle storage
If you plan on parking the vehicle
for more than three months, have
the maintenance operations described
on this page performed.<
Preparations for storageHave your BMW center perform the
following procedures:
1 Clean and apply a rustproofing agent
or other treatment to the engine,
engine compartment, undercarriage,
axles and major components in
accordance with approved repair
procedures. First wash the vehicle
surface, then clean the interior,
following up with paint and chrome
care, after which you clean the
rubber seals for the hood and doors.
2 Change the engine oil and oil filter at
operating temperature. As an addi-
tional corrosion protection measure,
an anticorrosive agent can be added
to the engine in accordance with the
manufacturer's instructions.
3 Check the coolant level and concen-
tration and top up if necessary.
4 Check the fluid level of the wind-
shield washer fluid reservoir and top
up if necessary.
5 Fill the fuel tank completely to pre-
vent the formation of condensation.
6 Increase the tire inflation pressure to
51 psi (350 kilopascal).
Before parking the vehicle1 To prevent the brake discs and
drums from corroding, dry the park-
ing and footbrake by applying the
brakes.
2 Park the vehicle in a covered, dry and
well-ventilated space. Place the
transmission in 1st gear or set the
selector lever to the "P" position.
Chock the wheels to prevent the
vehicle from rolling if necessary. Do
not set the parking brake.
3 Remove the battery, charge it
completely and store it in a cool (but
frost-free) room.
4 Remove the hardtop and store
separately. Refer to page 130.
5 Close the convertible top.During storageRecharge the battery every six months.
If it is not recharged, it will not be
serviceable. Every time the battery is
drained, especially over extended
periods, its service life is reduced.
Removing the vehicle from
storageRecharge the battery if the "Magic
Eye"
* turns black. Refer to page 176.
Then have Inspection I performed by
your BMW center, including a brake
fluid replacement if necessary. Refer
to the Service Manual.

Page 165 of 215

BMW 330Ci CONVERTIBLE 2001 E46 Owners Manual Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
165n
IndexDataTechnologyRepairsCar careControlsOverview
Replacement pro

Page 180 of 215

BMW 330Ci CONVERTIBLE 2001 E46 Owners Manual 180n
Microfilter/Activated-charcoal filter Fuel filler door1 Open the hood.
2 Loosen the three fasteners (arrows)
with a f-turn.
3 Remove the filter cover. 460de156
4 Remove the filter by pulling to

Page 199 of 215

BMW 330Ci CONVERTIBLE 2001 E46 Owners Manual 199n
IndexDataTechnologyRepairsCar careControlsOverview
Capacities
Notes
Fuel tank
Reserve gal. (liters)
gal. (liters)approx. 16.6 (approx. 63)
approx. 2.1 (approx. 8)Fuel specification: page 27
Wi

Page 210 of 215

BMW 330Ci CONVERTIBLE 2001 E46 Owners Manual Owner service procedures
A
Activated-charcoal filter 180
Adding brake fluid 148
Adding engine coolant 148
Adding engine oil 145
Air pressure, checking 27
Antifreeze 147
Avoiding unwanted alar
