2001 BMW 330Ci CONVERTIBLE cruise control

Contents

Overview
Controls and features

Cockpit16
Instrument cluster18
Indicator and warning lamps20
Multifunction steering wheel
(MFL)24
Hazard warning flashers25
Warning triangle25
First-aid kit25
Refueling26
Fuel specifications27
Tire inflation pressure27

Opening and closing:

Keys32
Electronic vehicle
immobilizer33
Central locking system34
Opening and closing Ð from the
outside34
Opening and closing Ð from the
inside38
Luggage compartment lid39
Luggage compartment40
Alarm system42
Electric power windows44
The manual convertible top45
The fully automatic convertible
top48
Wind deflector50

Adjusting:

Seats52
Seat and mirror memory56
Steering wheel57
Mirrors57
Car Memory, Key Memory59

Passenger safety systems:

Safety belts60
Airbags61
Transporting children safely64
Rollover protection system67

Driving:

Steering/Ignition lock69
Starting the engine69
Switching off the engine70
Parking brake71
Manual transmission72
Automatic transmission with
Steptronic73
Turn signal indicator/Headlamp
flasher76
Washer/Wiper system76
Rear window defroster78
Cruise control79

Everything under control:

Odometer81
Tachometer81
Energy Control81
Fuel temperature gauge82
Coolant temperature gauge82
Service Interval Display82
Check Control83
Computer83

Technology for driving comfort
and safety:

Park Distance Control (PDC)87
Automatic Stability Control plus
Traction (ASC+T)88
Dynamic Stability Control
(DSC)89
Tire Pressure Control (RDC)91

Contents

19n

IndexDataTechnologyRepairsCar careControlsOverview

Instrument cluster

1 Fuel gauge with indicator lamp
for fuel reserve82
2 Turn signal indicator23
3 Speedometer
4 Indicator lamp for:

>

Battery charge current20

>

High beams23

>

Engine oil pressure/Engine oil
level20, 22
5 Tachometer and
Energy control81
6 Engine coolant temperature gauge
with "Coolant temperature too high"
indicator82
7 Indicator and warning lamps (clock-
wise) for:

>

Parking brake/Brake hydraulic
system/Cornering Brake Control
(CBC)/DBC20

>

Antilock Brake System (ABS)22

>

Brake pads22

>

Tire Pressure Control
(RDC)

*
20, 22

>

Rollover protection system67

>

Airbags21

>

Adjust and lock backrest/Please
fasten safety belts21

>

Cruise control23
8 Set button for the clock849 Program display for automatic
transmission

*
75
Indicator lamp for automatic
transmission

*
21, 75
10 Indicator lamp for Automatic
Stability Control plus Traction
(ASC+T)/Dynamic Stability Control
(DSC)

*
and ADB22
11 Indicator for:

>

Odometer81

>

Trip odometer81

>

Clock84

>

Service Interval82
Indicator for computer,
operation using the turn signal lever,
refer to page 83:

>

Clock

>

Outside temperature

>

Average fuel consumption

>

Range

>

Average speed
12 Indicator for Check Control83
13 Trip odometer, reset to zero8114 Indicator and warning lamps (clock-
wise) for:

>

Front fog lamps23

>

Add washer fluid22

>

Coolant level23

>

Electronic Throttle Control
(EML)

*
23

>

Service engine soon22
You can display the outside
temperature and distance driven
in different units of measurement.

<

23n
IndexDataTechnologyRepairsCar careControlsOverview
Indicator and warning lamps
Engine electronics
* l
There is a fault in the engine's
electronic control system. The
electronics will allow you to continue
driving with reduced engine output or
reduced engine speed. Please have the
system inspected by your BMW center.
Add coolant
The coolant level is too low. Top
up the coolant at the earliest
opportunity.
For additional information, refer to
page 147.
Green: for your information
Turn signal indicator
Flashes when the turn signal is
on.
Rapid flashing indicates a system
malfunction.
For additional information, refer to
page 76.
Cruise control

Lights up when the cruise
control is activated: available for
operation via the multifunction steering
wheel.
For additional information, refer to
page 79.
Front fog lamps
Lights up whenever you switch
on the front fog lamps.
For additional information, refer to
page 94.
Blue: for your information
High beams
Comes on when the high beams
are on or the headlamp flasher
is actuated.
For additional information, refer to
pages 76, 94.

24n
Multifunction steering wheel (MFL)

The controls integrated in the multi-
function steering wheel are provided
so that you can operate a number of
accessories quickly and without being
distracted from traffic conditions. You
may operate:
>Selected radio functions,
>the cruise control,
>selected cellular phone functions.
In order to operate a system via
the MFL, the corresponding
systems must be switched on.<
Refer to the individual accessory
manuals for more detailed descriptions.
1 Radio/Telephone: select
2 Telephone: receive a call, initiate
dialing and terminate a call
3 Radio/Telephone: volume
4 Radio/Telephone: scan backward or
scan station keys or scroll through
the phone listings
5 Radio/Telephone: scan forward or
scan station keys or scroll through
the phone listings46cde085
6 Horn: the entire surface functions as
the horn
7 Cruise control: activate stored setting
(resume)
8 Cruise control: store and acceler-
ate (+); decelerate and store (Ð)
9 Cruise control: activate/interrupt/
deactivate

Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
31n
IndexDataTechnologyRepairsCar careControlsOverview
Driving:
Steering/Ignition lock69
Starting the engine69
Switching off the engine70
Parking brake71
Manual transmission72
Automatic transmission with
Steptronic73
Turn signal indicator/Headlamp
flasher76
Washer/Wiper system76
Rear window defroster78
Cruise control79
Everything under control:
Odometer81
Tachometer81
Energy Control81
Fuel gauge82
Coolant temperature gauge82
Service Interval Display82
Check Control83
Computer83
Technology for driving comfort
and safety:
Park Distance Control (PDC)87
Automatic Stability Control plus
traction (ASC+T)88
Dynamic Stability Control
(DSC)89
Tire Pressure Control (RDC)91Lamps:
Side lamps/Low beams93
Instrument panel lighting93
High beams/Parking lamps94
Fog lamps94
Interior lamps94
Controlling the climate
for pleasant driving:
Air conditioner96
Automatic climate control102
Seat heating107
Interior convenience:
Glove compartment107
BMW Universal Transmitter108
Storage facilities110
Cellular phone111
Ashtray, front111
Cigarette lighter112
Ashtray rear112
Loading and transporting:
Ski bag113
Cargo loading114
Roof-mounted luggage rack for
hardtop116

79n
IndexDataTechnologyRepairsCar careControlsOverview
Cruise controlStarting at about 20 mph (30 km/h), you
can maintain and store any vehicle
speed that you specify.
Do not use the cruise control on
winding roads, when high traffic
density prevents driving at a constant
speed, when the road surface is slick
(snow, rain, ice), or when the road
surface is loose (rocks, sand). Press button 1. The indicator lamp in
the instrument cluster comes on. You
can now use the cruise control.46cde086
To store and maintain speed or to
acceleratePress button 3 briefly:
The system registers and maintains the
current vehicle speed. Every time you
press the button, the speed increases
by approx. 0.6 mph (1 km/h).
Press and hold button 3:
The vehicle accelerates without pres-
sure on the accelerator pedal. When
you release the button, the system
registers and maintains the current
speed.
If, on a downhill gradient, the
engine braking effect is not
sufficient, the set cruise control speed
may be exceeded. Speed can drop on
uphill grades if the engine output is
insufficient.<
To deceleratePress button 2 briefly:
When the cruise control is active,
vehicle speed is reduced by approx.
0.6 mph (1 km/h) every time you tap the
button.
Press and hold button 2:
With the cruise control active, the
system automatically reduces the
throttle opening to slow the vehicle.
When you release the button, the
system registers and maintains the
current speed.

80n
Cruise controlTo interrupt the cruise control When the system is activated, press
and hold button 1. The indicator lamp
stays on. You can use the cruise control
again as desired.
In addition, cruise control is canceled
automatically:
>If the brakes are applied.
>When you apply pressure to the
clutch pedal, and when you move the
automatic transmission selector lever
from "Drive" to "Neutral".
>If you exceed or fall below the
programmed speed for an extended
period (by depressing the acceler-
ator, for example).
To resume the stored settingPress button 4:
The vehicle accelerates to and main-
tains the last speed stored. When you
turn the ignition key to position 0, the
stored speed is deleted and the system
is deactivated.
To deactivate the system When the cruise control has been inter-
rupted, press button 1 again. The indi-
cator lamp goes out and the stored
speed is deleted.

Everything from A to Z
A
ABS (Antilock Brake System) 22,122
Accessories 6
Activated-charcoal filter 106,180
Adaptive Transmission Control (ATC) 73,188
Adding engine oil 145
Adding washer fluid 144,199
Adjusting backrest 52
Adjusting headrests 53
Adjusting the steering wheel 57
Adjusting the temperature 98,104
Adjusting thigh support 54
Air conditioner 96
Air distribution 98,104
Air nozzles 96,102
Air outlets 96,102
ventilation 96,102
Air pressure, tires 27,132
Air supply 98,105
Airbags 21,61 ,159 ,189
sitting properly with 62
Alarm system 42
Antenna 129
Antenna, Diversity 190 Antifreeze
147
radiator 127
Antilock Brake System (ABS) 22,122
Anti-theft alarm system 42
Aquaplaning 121,132
Armrest 110
ASC+T (Automatic Stability Control plus
Traction) 22,88
Ashtray front 111
rear 112
ATC (Adaptive Transmission Control) 73,188
Attach vacuum cleaner 112
AUC (Automatic recirculated-air
control) 105
Automatic car washes 151
Automatic climate control 102
remove window
condensation 105
Automatic cruise control 79
Automatic dimming, interior rearview mirror 58
Automatic recirculated-air control (AUC) 105
Automatic Stability Control plus Traction
(ASC+T) 22,88 Automatic transmission with
Steptronic 21,73
Automatic windshield washer 77
Average consumption 85
Average speed 86
Avoiding unwanted alarm 43
Axle loads 198
B
Backrest adjusting 52
locking 21,55
releasing 55
Backup lamps 72
bulb replacement 169
Battery 176,200
capacity 200
charge current 20,176
charging 178
discharged 183
removal and
installation 178
Belts 60
Beverage holder 111
Blower 98,105
BMW High Performance Synthetic Oils 146
BMW Maintenance System 150 BMW sports seat
54
Bore 196
Brake fluid 148
Brake hydraulic system 20
Brake lamps, bulb replacement 169
Brake pads 22,126
Brake system 126
Brakes 125
malfunctions 126
Break-in procedures 120
Bulb replacement 166
C
California Proposition 65 Warning 161
Capacities 199
Car Memory 59
Car radio 129
reception 129,190
refer also to the Radio
Owner's Manual
Car washes 151
Care convertible top 157
exterior 152
interior 154
leather upholstery 155
rubber seals and
components 127
