Changing a Flat Tire
6. Turn the jack's end bracket counterclockwise to loosen it, then
remove the jack by lifting it
straight up. 7. Loosen the five wheel nuts 1/2
turn with the wheel wrench. 8. Locate the jacking point nearest
the tire you need to change. It is pointed to by a mark molded
into the underside of the body.
Place the jack under the jacking
point. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Makesure the jacking point tab is
resting in the jack notch.
Taking Care of the Unexpected JACKING
POINT
WHEEL WRENCH
JACK
Index
Identification Number, Vehicle.... 300
Ignition
Keys............................................... 77
Switch............................................ 80
Timing Control System............. 309
Immobilizer System......................... 78
Important Safety Precautions.......... 6
Indicators, Instrument
Panel.............................................. 53
Infant Restraint................................ 28
Infant Seats....................................... 28
Tether Anchorage Points........... 39
Inflation, Proper Tire .................... 243
Inside Mirror.................................... 99
Inspection. Tire.............................. 245
Instrument Panel............................. 53
Instrument Panel Brightness......... 66
Interior Cleaning............................ 267
Introduction......................................... i
Jacking up the Car......................... 274
Jack, Tire........................................ 274
Jump Starting................................. 280
Keys................................................... 77
Label, Certification........................ 300Lane Change. Signaling.................. 66
Lap/Shoulder Belt........................... 40
Learning Key.................................... 78
Leather, Cleaning.......................... 266
Lights On Indicator......................... 55
Lighter, Cigarette.......................... 116
Lights Bulb Replacement..................... 252
Ceiling......................................... 118
Courtesy...................................... 119
Indicator........................................ 53
Parking.......................................... 63
Turn Signal................................... 66
Load Limit...................................... 177
LOCK (Ignition Key Position)....... 80
Locks Anti-theft Steering Column........ 80 Childproof Door........................... 85
Fuel Fill Door............................. 169 Glove Box..................................... 88
Power Door.................................. 81
Trunk............................................ 86
Trunk Pass-through Cover......... 98
Low Coolant Level......................... 172
Low Fuel Indicator.......................... 57
Low Oil Pressure Indicator.... 54, 285 Lubricant Specifications Chart........................................... 302
Luggage.......................................... 176
Maintenance................................... 203
Owner Maintenance Checks.... 215
Record................................. 213 - 214
Required Indicator....................... 61 Safety........................................... 204
Schedule.............................. 208 - 212
Malfunction Indicator Lamp.. 55, 287
Memory, Driving Position............ 101
Meters, Gauges................................ 58
CONTINUED
