2001 Acura CL key

µµµ
µ
You can insert or
remove the key only in this position.
To switch f rom ACCESSORY to
LOCK, you must push the key in
slightly as you turn it. The shif t lever
must also be in Park. The anti-thef t
lock will lock the steering column
when you remove the key.
If the f ront wheels are turned, the
anti-thef t lock may sometimes make
it difficult to turn the key from
LOCK to ACCESSORY. Firmly turn
the steering wheel to the lef t or to
the right as you turn the key. In this position,
you can operate the audio system
and the accessory power sockets.
This is the normal key
position when driving. All f eatures
and accessories on the car are usable.
Several of the lights on the instru-
ment panel come on as a test when
you turn the ignition switch f rom
ACCESSORY to ON.
Use this position
only to start the engine. The switch
returns to ON (II) when you let go of
the key. The engine will not start if the
Immobilizer System does not
recognize the key’s coding (see page
).
You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or
ACCESSORY (I) position and open
thedriver’sdoor.Removethekeyto
turn of f the beeper. 78
Keys and Locks
Inst rument s and Cont rols
L OCK (0)
A CCESSORY (I)
ON (II)
ST A RT (III)
80

CONT INUED
Each door has a master door lock
switch. Either switch locks and
unlocks both doors. Push the switch
down to lock both doors and up to
unlock them.Each door has a lock tab at the top of
the door. When you push down the
lock tab on the driver’s door, both
doors lock. Pulling up the lock tab on
the driver’s door only unlocks that
door. The lock tab on the passenger’s
door only locks and unlocks that
door.To lock the passenger’s door when
getting out of the car, push the lock
tab down and close the door. To lock
the driver’s door, remove the key
f rom the ignition switch and push
the lock tab down or push the master
switch down, then close the door.
Both doors can be locked f rom the
outsidebyusingthekeyineither
door.
To unlock only the driver’s door
f rom the outside, insert the key in
the driver’s door lock, turn the key
and release it. If you turn the key
and hold it, both doors will unlock.
Both doors will unlock when you
unlock the passenger’s door with the
key.
Power Door L ocks
Keys and Locks
Inst rument s and Cont rols81
M M
A
AS
STTE
ER
R D
DO
OO ORR L
LOOC CKK S
SWWI ITT C
CH H L
LOOC CKK T
TA
A B
B

If you f orget and leave the key in the
ignition switch, Lockout Prevention
will not allow you to lock the driver’s
door. With the driver’s door open
andthekeyintheignition,both
master door lock switches are
disabled. However, if the driver’s
door is not open, the master door
lock switches are not disabled.
Pushing the switch down on the
open passenger’s door will lock both
doors. If you try to lock an open
driver’s door by pushing down the
lock tab, the tabs on both doors pop
up. Pushing down the lock tab on the
passenger’s door only locks that door.You can lock and unlock your car
with the remote transmitter. When
you push the LOCK button, both
doors lock. The parking lights, side
marker lights, taillights and license
plate light will f lash once.
When you push the LOCK button a
second time within 5 seconds after
you have locked the doors, you will
hear a beep to verify that the
security system will be set.When you push the UNLOCK button
once, only the driver’s door unlocks.
The passenger’s door unlocks when
you push the button a second time.
The parking lights, side marker
lights, taillights and license plate
light f lash twice each time you push
the button.
The ceiling light (if the ceiling light
switch is in the center position) will
come on when you press the
UNLOCK button. If you do not open
either door, the light stays on f or
about 10 seconds, then f ades out. If
you relock the doors with the remote
transmitter before 10 seconds have
elapsed, the light will go of f
immediately.
If you unlock the doors with the
remote transmitter, but do not open
either door within 30 seconds, the
doors automatically relock and the
security system sets.
Remote Transmitter
L ockout Prevent ion
Keys and Locks
Inst rument s and Cont rols82
L LE
E D
D
U
UN NLLOOC CKK
B
BU UT TT
TO
ON N L
LO
OC CKK
B
BU UT TT
TO
ON N
T
T R
RU UN NKK
R
RE EL
LEE A
A S
SEE
B
BU UT TT
TO
ON N
P
P A
A N
NI ICC
B
BU UT TT
TO
ON N

CONT INUED
To open the trunk, push the Trunk
Release button f or approximately
one second.
You can open the trunk with the
remote transmitter regardless of the
position of the main switch in the
glove box. The trunk will not open if
the key is in the ignition switch. You cannot lock the doors with the
remote transmitter if either door is
not f ully closed or the key is in the
ignition switch. You cannot unlock
the doors with the key in the ignition
switch.If the seat and mirrors are already in
the proper positions, you will hear
three beeps when you open the door.
Theremotetransmitterswillalso
activate the Driving Position
Memory System (see page ).
When you open the driver’s door
after unlocking it with the remote
transmitter, you will hear a beep.
The driver’s seat and outside mirrors
move to the positions stored in that
memory location. You will hear two
beeps when the movement is
complete. The driving position memory
activated (Memory 1, Memory 2) is
shownonthebackof each
transmitter. Make sure you store
your desired driving position in the
memory that is activated by the
transmitter you normally carry.
You can turn of f this driving position
memory activation. While standing
near the car, press and hold the
LOCK and UNLOCK buttons at the
same time. The LED in the remote
transmitter will blink twice. Then
release the buttons.
To turn it back on, repeat this
procedure. The LED will come on
f or one second to indicate the
f eature has been turned on.
103
Keys and Locks
Inst rument s and Cont rols
Recalling a Memorized Driving
Position
83
W Wi itth h M
M e
emm o
or
ryy 1
1 W
Wi
itth h M
M e
emm o
or
ryy 2
2

´
Panic mode allows you to remotely
activate your car’s security system to
attract attention. When activated, the
horn will sound, and the exterior
lights will f lash, f or about 30 seconds.
To activate panic mode, press and
hold the PANIC button for about two
seconds.
To cancel Panic mode bef ore 30
seconds, press any button on the
remote transmitter. You can also
turn the ignition switch to ON (II).
Panic mode will not activate if the
ignition switch is in the ON (II)
position.
When the remote transmitter’s
battery begins to get weak, it may
take several pushes on the button to
lock or unlock the doors, and the
LED will get dim. Replace the
battery as soon as possible.
Battery type: CR2025To replace the battery, remove the
round cover on the back of the trans-
mitter by turning it counterclockwise
with a coin.
Remove the old battery and note the
polarity. Make sure the polarity of
the new battery is the same ( side
f acing up), then insert it in the
transmitter.
Keys and Locks
Inst rument s and Cont rols
Panic Mode
Replacing t he Bat t ery
84
C Clloo s
see
O
Op
pe
enn R
RO
OU UNNDD
C
CO OV VE
ER
R
B
BA A T
TT
TE
ER
RY Y

ÜAs required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Clean the transmitter case with a
sof t cloth. Do not use strong
cleaners or solvents that could harm
the case. Immersing the transmitter
in any liquid will harm the trans-
mitter and cause it to not f unction
properly. Avoid severe shock to the trans-
mitter, such as dropping or throwing
it. Also, protect it f rom extreme hot
or cold temperatures.
If you lose a transmitter, you will
need to have the replacement
programmed to your car’s system by
your Acura dealer. Any other
transmitters you have will also need
to be reprogrammed.
Align the mark on the cover
with the mark on the
transmitter, then set the cover in
place and turn it clockwise.
Inst rument s and Cont rols
Keys and Locks
Transmitter Care
85

Youcanopenthetrunkinthree
ways:Press the trunk release button on
the driver’s door.
Press and hold the trunk release
button on the remote transmitter
f or approximately one second (see
page ). Reach through the trunk pass-
through and pull the trunk release
handle.
To close the trunk, press down on
the trunk lid.
See page f or cargo loading and
weight limit inf ormation. Keep the
trunk lid closed at all times while
driving to avoid damaging the lid,
and to prevent exhaust gas from
getting into the interior. See on page . As a saf ety f eature, your car has a
release lever on the trunk latch so
the trunk can be opened f rom the
inside.
To open the trunk, push the release
lever to the lef t.
169
49
82
U.S. models only
Keys and Locks
Inst rument s and Cont rols
Trunk
Carbon
Monoxide Hazard Emergency T runk Opener
86
T T
R
RU UN NKK R
REEL
LEE A
A S
SEE B
BUUT TT
TO
ON N T
T
R
RU UN NKK R
REEL
LEE A
A S
SEE H
HA
AN
ND DL
LEE

Even if the trunk main switch is
turned of f , you can open the trunk
with the remote transmitter.Lock the glove box with the
master key.
Give the person the valet key. Make sure the trunk pass-through
cover is locked (see page ).
Parents should decide if their
children should be shown how to use
this feature.
For more inf ormation about child
saf ety, see page .
Disable the trunk release button
on the driver’s door by turning of f
the trunk main switch in the glove
box.
To protect items in the trunk when
you need to give the key to someone
else:
1. 2.
3.
4.
100
23
Keys and Locks
Inst rument s and Cont rols87
T T R
RU UN NKK M
M A
AI
INN S
SWWI ITT C
CH H
