2001.5 Peugeot Expert Dag gearbox

TABLE OF FUSES
(According to model or country)V- 2
90
Fuses under the dashboard
Number Rating Functions
F1 10 A Audio system (supply)
F2 5 A Ignition + position - Speed sensor - PCPU - Instrument panel warning lamps
F3 15 A Stop lamp - Cruise control
F4 10 A Rear RH tailgate lamp - Front LH sidelamp - Headlamp adjustment
F5 10 A Air conditioning - Electric front windows - Air blower - Pressostat
F6 15 A Heated rear window & heated seats
F7 20 A Horn
F8 SHUNT Ñ
F9 5 A Headlamp washer - Front RH sidelamp - Number plate lighting - Rear LH lamp
F10 30 A Unused
F11 30 A Unused
F12 10 A ABS control unit Ð Reversing lamps Ð Diagnostic socket Ð Auto gearbox
F13 30 A Unused
F14 5 A PCPU

GENERAL INFORMATION*Combi115VI-2
(1) 95bhp (2) 110bhp BVM : manual gearbox. BVA : auto gearbox.
* According to model or country
** Towing weights Always keep within the towing weight limits of your vehicle.
You must observe the towing loads and speed limits as specified by local legislation. To learn more about the towing
capacity of your vehicle and its maximum authorised GTW, contact your dealer.
Weights (kg) Unladen weight 1 550 ➟1 692 1 551 ➟1 576 1 522 ➟1 570
Gross vehicle weight 2 285 2 205 2 330
Payload 815 815 815
Gross train weight 3 585 3 305 3 500
Gross trailer weight (with brakes)** 1 300 1 100 1 300
Gross trailer weight (without brakes)** 750 750 750Max. roof rack load 100 100 100
Engine type
2.0i 16V 1.9 D 2.0 HDi
(95bhp/110bhp)
Cubic capacity (cc) 1 997 1 868 1 997
Number of seats 5-6-8-9 8-9 5-6-8-9
French fiscal rating 9 6 7
Calculated maximum speed in km/h (mph) 175 (BVM) 138 160(1) / 165(2) 172 (BVA)

RECOMMENDATIONS FORAPPROVED LUBRICANTSVI-8
128
The oils which appear in the table opposite are suitable for most pur-poses. The diagram opposite states the optimum range of viscosity depen-ding on the temperatures at whichthe oils are to be used. It is also possible to use synthetic oils of 'superior quality'. In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJquality (for petrol engines), orCD/CF quality (for diesel engines)may be used by following the'Arduous Conditions' maintenanceschedule which specifies shorterintervals. Do not hesitate to ask for advice
from a PEUGEOT dealer to main-tain driving pleasure and to minimi-se the maintenance cost of yourvehicle. For countries outside Europe, please
contact a local PEUGEOT dealer.
0 W2 0 4 0
5 0
2 0 W
1 5 W
1 0 W
5 W
3 0
ESSENTIAL ESSENTIAL
Manual gearbox ESSO GEAR OIL BVTOTAL TRANSMISSION BV75W-80 PR 9736.41 75W-80
Automatic gearbox ESSENTIAL
ATF 4HP20-AL4 PR 9736.22
Power steering ESSO ATF D TOTAL FLUIDE AT42 PR 9730.94
Other approved products
Brake fluid PEUGEOT DOT4 Coolant
PROCOR TM108/GLYSANTIN G33 or REVKOGEL 2000
ESSENTIAL Protection to minus 35 ¡C
