IMPORTANT MANUAL INFORMATION
1
2
3
4
5
6
7
8
9Particularly important information is distinguished in this manual by the following notations:
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY
IS INVOLVED!
Failure to follow WARNING instructions could result in severe injury or death to the
motorcycle operator, a bystander or a person inspecting or repairing the motorcycle.A CAUTION indicates special precautions that must be taken to avoid damage to
the motorcycle.A NOTE provides key information to make procedures easier or clearer.
Qw
cCNOTE:
NOTE:
8This manual should be considered a permanent part of this motorcycle and should remain
with it even if the motorcycle is subsequently sold.
8Yamaha continually seeks advancements in product design and quality. Therefore, while this
manual contains the most current product information available at the time of printing, there
may be minor discrepancies between your motorcycle and this manual. If there is any ques-
tion concerning this manual, please consult your Yamaha dealer.
EAU00005
4PT-9-E6 (ENG) 1~5 12/27/00 1:28 PM Page 2

3-1
ON
OFF
LOCK
P
EAU00029
Main switch/steering lockThe main switch controls the ignition
and lighting systems. Its operation is
described below.
EAU00036
ON
Electrical circuits are switched on.
The engine can be started. The key
cannot be removed in this position.
EAU00038
OFF
All electrical circuits are switched off.
The key can be removed in this posi-
tion.
EAU00042
LOCK
The steering is locked in this position
and all electrical circuits are switched
off.
The key can be removed in this posi-
tion.
To lock the steering, turn the handle-
bars all the way to the left. With the
key at ÒOFFÓ, push it into the main
switch and release it, turn it counter-
clockwise to ÒLOCKÓ and remove it.
To release the lock, turn the key to
"OFF".
EW000016
wNever turn the key to ÒOFFÓ or
ÒLOCKÓ when the motorcycle is
moving. The electrical circuits will
be switched off which may result
in loss of control or an accident.
Be sure the motorcycle is stopped
before turning the key to ÒOFFÓ or
ÒLOCKÓ.
EAU01590
. .
(Parking)
The steering is locked in this position,
and the taillight and auxiliary light
come on but all other circuits are off.
The key can be removed in this posi-
tion.
To use the parking position, first lock
the steering, then turn the key to Ò
.
Ó.
Do not use this position for an
extended length of time as the bat-
tery may discharge.
EAU00027
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
12
1. Push2.Turn
4PT-9-E6 (ENG) 1~5 12/27/00 1:28 PM Page 14

3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
2
1
EAU00177
Fuel tank capTo open
Insert the key and turn it 1/4 turn
counterclockwise. Turn the cap 1/3
turn counterclockwise and remove it
from the tank.
To close
Put the cap in the filler neck and turn
it 1/3 turn clockwise. Lock the cap by
turning the key 1/4 turn clockwise,
and remove the key.1.Unlock
2.Open
NOTE:
The tank cap cannot be reinstalled
unless it is unlocked. The key must
remain in the cap until the cap is
properly installed and locked onto the
fuel tank.
EW000023
wBe sure the cap is properly
installed and locked in place
before riding the motorcycle.
2
1
1.Filler tube
2.Fuel level
EAU01183
FuelMake sure there is sufficient fuel in
the tank. Fill the fuel tank to the bot-
tom of the filler tube as shown in the
illustration.
EW000130
wDo not overfill the fuel tank. Avoid
spilling fuel on the hot engine. Do
not fill the fuel tank above the bot-
tom of the filler tube or it may
overflow when the fuel heats up
later and expands.
4PT-9-E6 (ENG) 1~5 12/27/00 1:28 PM Page 19

3-9
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
When reinstalling the seat, insert the
projections on the front of the seat
into the holders, then tighten the
bolts.NOTE:
Make sure that the seat is securely
fitted.
12
EAU00260
Helmet holderTo open the helmet holder, insert the
key in the lock and turn it as shown.
To lock the helmet holder, replace
the holder in its original position.
EW000030
wNever ride with a helmet in the hel-
met holder. The helmet may hit
objects, causing loss of control
and possibly an accident.1.Helmet holder
2.Open
EAU00240
SeatTo remove the seat, remove the
bolts.
4PT-9-E6 (ENG) 1~5 12/27/00 1:28 PM Page 22

5-6
EC000052
cCAfter 1,000 km of operation, be
sure to replace the engine oil and
oil filter.1,000 km and beyond
Full throttle can be used.
EC000053
cC8
8
Never let engine speeds enter
the red zone.
8 8
If any engine trouble should
occur during the break-in peri-
od, consult a Yamaha dealer
immediately.
EAU00457
ParkingWhen parking the motorcycle, stop
the engine and remove the ignition
key. Turn the fuel cock to ÒOFFÓ
whenever stopping the engine.
EW000058
wThe exhaust system is hot. Park
the motorcycle in a place where
pedestrians or children are not
likely to touch the motorcycle. Do
not park the motorcycle on a slope
or soft ground; the motorcycle
may overturn.OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9
4PT-9-E6 (ENG) 1~5 12/27/00 1:28 PM Page 37

9
CONSUMER INFORMATION
Identification number records.............................................................9-1
Key identification number...................................................................9-1
Vehicle identification number..............................................................9-1
Model label.........................................................................................9-2
9
4PT-9-E6 (ENG) 7~9 12/27/00 1:30 PM Page 13

1
2
3
4
5
6
7
89
1
1
EAU02944
Identification number
recordsRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided for assistance when order-
ing spare parts from a Yamaha deal-
er or for reference in case the vehicle
is stolen.
1.KEY IDENTIFICATION
NUMBER:
2.VEHICLE IDENTIFICATION
NUMBER:
3.MODEL LABEL INFORMATION:
EAU01041
Key identification numberThe key identification number is
stamped on the key tag.
Record this number in the space pro-
vided and use it for reference when
obtaining a new key.
EAU01043
Vehicle identification
numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your state.
1.Key identification number1.Vehicle identification number
9-1
EAU01039
CONSUMER INFORMATION1
6
4PT-9-E6 (ENG) 7~9 12/27/00 1:30 PM Page 14
