SPECIFICATIONS
1
2
3
4
5
6
78
9
Specifications
ModelXT500E/XT600E
Dimensions
Overall length2,220 mm
2.295 mm (N, S, CH only)
Overall width865 mm
825 mm (CH only)
Overall height1,205 mm
Seat height855 mm
Wheel base1,440 mm
Minimum ground clearance230 mm
Minimum turning radius2,300 mm
Basic weight (with oil and full
fuel tank)176 kg
172 kg (CH only)
Engine
Engine typeAir-cooled 4-stroke, SOHC,
gasoline
Cylinder arrangementForward inclined single
cylinder
Displacement499 cm
3
595 cm
3
Bore
´Stroke87.0 ´84.0 mm (XT500E)
95.0 ´84.0 mm (XT600E)
Compression ratio8.5:1
Starting systemElectric starter
Lubrication systemDry sumpEngine oil
Type
Recommended engine oil
classificationAPI Service SE, SF, SG type
or higher
cCBe sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled
ÒEnergy ConservingÓ) contain anti-friction additives which
will cause clutch and/or starter clutch slippage, resulting in
reduced component life and poor engine performance.
Capacity
Periodic oil change2.7 L
With oil filter replacement2.8 L
Total amount3.3 L
EAU01038
SPECIFICATIONS
8-1
–10° 0° 10° 20° 30°
40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50
–20°
SAE 15W/40 50°C
