Rav4(U)
792000 RAV4 (OM42479U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers81 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior light82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wipers and washer83 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1− 4
ProCarManuals.com
Rav4(U)
832000 RAV4 (OM42479U)
The personal lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
The center switch has the following posi-
tions:
”DOOR”—Turns both lights on when either
front door is opened. The light goes off
when both front doors are closed.
”OFF”—The lights are off unless you oper-
ate either outer switch.
Windshield wipers and washer
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ”ON” position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
To squirt washer fluid, pull the lever
toward you and release it.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.For instructions on adding washer fluid,
see ”Adding washer fluid” in Section 7−3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Personal lights
(without moon roof)
ProCarManuals.com
Rav4(U)
2352000 RAV4 (OM42479U)
Fuses
Engine compartment
(without daytime running light system)
Fuses (type A)
1. H−LP (RH) 15 A: Right−hand headlight
2. H−LP (LH) 15 A: Left−hand headlight
3. SPARE 10 A: Spare fuse
4. SPARE 15 A: Spare fuse
5. AM2 5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, seat belt
pretensioners, starting system, dis-
charge warning light
6. ALT−S 5 A: Charging system
7. HAZ 10 A: Emergency flashers
Engine compartment
(with daytime running light system)
8. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
9. DOME 15 A: Interior light, personal
lights, clock, daytime running light sys-
tem, gauge and meters, car audio sys-
tem
10. IGN 20 A: Charging system
11 . H−LP RH−H 10 A: Right−hand head-
light (high beam)
12. H−LP LH−H 10 A: Left−hand headlight
(high beam)
13. H−LP RH−L 10 A: Right−hand head-
light (low beam)
Engine compartment
14. H−LP LH−L 10 A: Left−hand headlight
(low beam)
15. PWR OUTLET 15 A: Power outlet
16. CIG 15 A: Cigarette lighter, clock, car
audio system, power rear view mirrors,
electronically controlled automatic
transmission system
17. SRS−ACC 10 A: SRS airbag system,
seat belt pretensioners
18. WIPER 20 A: Windshield wipers and
washer, rear window wiper and washer
