2000 Corolla(U)
143
INFORMATION BEFORE DRIVING YOUR
TOYOTA
Break- in period144 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel144 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system146 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries146 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Three- way catalytic converter146 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust cautions147 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumptio148 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Iridium- tipped spark plugs149 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system149 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear limit indicators152 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions153 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Your Toyota's identification153 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft prevention labels154 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension and chassis155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 2
ProCarManuals.com

2000 Corolla(U)
160

Do not drive in excess of the speed
limit. Even if the legal speed limit
permits it, do not drive over 140
km/h (85 mph) unless your vehicle
has high- speed capability tires.
Driving over 140 km/h (85 mph) may
result in tire failure, loss of control
and possible injury. Be sure to con-
sult a tire dealer to determine
whether the tires on your vehicle
are high- speed capability tires or
not before driving at such speeds.

Do not continue normal driving
when the brakes are wet. If they are
wet, your vehicle will require a
longer stopping distance, and it
may pull to one side when the
brakes are applied. Also, the park-
ing brake will not hold the vehicle
securely.
Winter driving tips
Make sure you have a proper freeze
protection of engine coolant.
Your coolant must contain ethylene- glycol
type coolant for a proper corrosion
protection of aluminum components. Use
TOYOTA Long Life Coolantº or equivalent.
See Section 7- 2 for details about coolant
type selection.
NOTICE
Do not use alcohol type antifreeze or
plain water alone.
When it is extremely cold, we recommend
to use 60% solution for your Toyota, to
provide protection down to about -50C
(- 58F). Do not use more than 70% solu-
tion for better coolant performance.
Check the condition of the battery and
cables.
Cold temperatures reduce the capacity of
any battery, so it must be in top shape
to provide enough power for winter start-
ing. Section 7- 3 tells you how to visually
inspect the battery. Your Toyota dealer
and most service stations will be pleased
to check the level of charge.Make sure the engine oil viscosity is
suitable for the cold weather.
See Section 7- 2 for recommended viscos-
ity. Leaving a heavy summer oil in your
vehicle during winter months may cause
harder starting. If you are not sure about
which oil to use, call your Toyota deal-
erÐhe will be pleased to help.
Keep the door locks from freezing.
Squirt lock de- icer or glycerine into the
locks to keep them from freezing. To open
a frozen lock, try heating the key before
inserting it.
Use a washer fluid containing an anti-
freeze solution.
This product is available at your Toyota
dealer and most auto parts stores. Follow
the manufacturer 's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle's paint.
ProCarManuals.com

2000 Corolla(U)
Publication No. OM12718U
Part No. 01999-12718
Printed in Japan 01- 9908- 00
(U)
Quick index

If a service reminder indicator or warning buzzer comes on 87. . . . . . . . . .

If your vehicle will not start 170. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If your engine stalls while driving 173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If your vehicle overheats 173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If you have a flat tire 174. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If your vehicle needs to be towed 183. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tips for driving during break- in period 144. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

How to start the engine 158. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General maintenance 195. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Complete index NO TAG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher
See page 144 for detailed information.
Fuel tank capacity:
50 L (13.2 gal., 11.0 lmp.gal.)
Engine oil:
API grade SJ, Energy- Conservingº or ILSAC multigrade engine
oil is recommended.
See page 206 for detailed information.
Automatic transmission fluid:
Automatic transmission fluid D- II or DEXRONIII (DEXRONII)
See page 232 for detailed information.
Tire information: See pages 210 through 214.
Tire pressure: See page 233.
eU-4
C
ProCarManuals.com

2000 Corolla(U)
231
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
Spark plug type:
DENSO SK16R11
NGK IFR5A11
Spark plug gap, mm(in.):
1.1 (0.043)ENGINE LUBRICATION
Oil capacity (drain and refill), L (qt., Imp.
qt.):
With filter 3.7 (3.9, 3.3)
Without filter 3.5 (3.7, 3.1)
Oil grade:
API grade SJ, Energy- Conservingº or
ILSAC multigrade engine oil is recom-
mended.
Recommended oil viscosity (SAE):COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Manual transmission
5.8 (6.1, 5.1)
Automatic transmission
5.7 (6.0, 5.0)
Coolant type:
TOYOTA Long Life Coolantº or equiva-
lent
With ethylene- glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
BATTERY
Open voltage
* at 20
C (68
F):
12.6- 12.8 V Fully charged
12.2- 12.4 V Half charged
11.8- 12.0 V Discharged
*: Voltage that is checked 20 minutes af-
ter the key is removed with all the
lights turned off
Charging rates:
5A max.
ProCarManuals.com

2000 Corolla(U)
232
CLUTCH
Pedal free play, mm (in.):
5Ð15 (0.2Ð0.6)
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSAXLE
Oil capacity, L (qt., Imp. qt.):
1.9 (2.0, 1.7)
Oil type:
Gear oil API GL- 4 or GL- 5
Recommended oil viscosity:
SAE 75W- 90
AUTOMATIC TRANSAXLE
Automatic transmission
Fluid capacity (drain and refill), L (qt.,
Imp. qt.):
Four- speed type
Up to 3.1 (3.3, 2.7)
Three- speed type
2.5 (2.6, 2.2)
Fluid type:
Automatic transmission fluid D- ll or
DEXRONIII (DEXRONII)Differential (three- speed type only)
Fluid capacity L (qt., Imp. qt.):
1.4 (1.5, 1.2)
Fluid type:
Automatic transmission fluid D- II or
DEXRONIII (DEXRONII)
BRAKES
Minimum pedal clearance when depressed
with the pressure of 490 N (50 kgf, 110
lbf) with the engine running, mm (in.):
Vehicles with anti- lock brake system
90 (3.5)
Vehicles without anti- lock brake system
85 (3.3)
Pedal free play, mm (in.):
1Ð6 (0.04Ð0.24)
Pad wear limit, mm (in.):
1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf):
4Ð7 clicks
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3STEERING
Wheel free play:
Less than 30 mm (1.2 in.)
Power steering fluid type:
Automatic transmission fluid DEXRONII
or III
ProCarManuals.com

2000 Corolla(U)
7
Indicator symbols on the instrument panel
(type A)
(type B)
(type A)
(type B)Brake system warning light*
1
Seat belt reminder light*
1
Discharge warning light*
1
Malfunction indicator lamp*
1
Low oil pressure warning light*
1
Anti- lock brake system warning light*
1
Open door warning light*
1
SRS warning light*
1
Low windshield washer fluid level warning
light*
1
Low fuel level warning light*
1
Turn signal indicator lights Headlight high beam indicator light
Overdrive- off indicator light
Cruise control indicator light
*
2
Rear window defogger indicator light
*
1: For details, see Service reminder indicators and warning
buzzersº in Section 1- 5.
*
2: If this light flashes, see Cruise controlº in Section 1- 6.
ProCarManuals.com

2000 Corolla(U)
203

Dispose of used oil and filter only
in a safe and acceptable manner.
Do not dispose of used oil and fil-
ter in household trash, in sewers or
onto the ground. Call your dealer or
a service station for information
concerning recycling or disposal.
NOTICE

Remember that battery and ignition
cables carry high currents or volt-
ages. Be careful of accidentally
causing a short circuit.

Add only demineralized or distilled
water to fill the radiator. And if you
spill some of the coolant, be sure
to wash off with water to prevent it
from damaging the parts or paint.

Do not allow dirt or anything else
to fall through the spark plugholes.

Use only spark plugs of the speci-
fied type. Using other types will
cause engine damage, loss of per-
formance or radio noise.

Do not reuse iridium- tipped spark
plugs by cleaning or regapping.

Do not overfill automatic transmis-
sion fluid, or the transmission
could be damaged.

Do not drive with the air cleaner
filter removed, or excessive engine
wear could result. Also backfiring
could cause a fire in the engine
compartment.

Be careful not to scratch the glass
surface with the wiper frame.

When closing the engine hood,
check to see that you have not for-
gotten any tools, rags, etc.
Parts and tools
Here is a list of parts and tools you will
need on performing do- it- yourself mainte-
nance. Remember all Toyota parts are de-
signed in metric sizes, so your tools must
be metric.
Checking the engine oil level
Parts (if level is low):

Engine oil API grade SJ,
Energy- Conservingº or ILSAC
multigrade having viscosity proper for
your climate
Tools:

Rag or paper towel

Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):

TOYOTA Long Life Coolantº or equiva-
lent
See Section 7- 2 for details about cool-
ant type selection.

Demineralized or distilled water
Tools:

Funnel (only for adding coolant)
ProCarManuals.com

2000 Corolla(U)
206
Checking the engine oil level
Low level Full level
Add oil O.K. Too full
With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.
1. To get a true reading, the vehicle
should be on a level spot. After turning
off the engine, wait a few minutes for
the oil to drain back into the bottom of
the engine.
2. Pull out the dipstick, and wipe it clean
with a rag.
3. Reinsert the dipstickÐpush it in as far
as it will go, or the reading will not be
correct.
4. Pull the dipstick out and look at the oil
level on the end.If the oil level is below or only slightly
above the low level, add engine oil of
the same type as already in the engine.
Remove the oil filler cap and add engine
oil in small quantities at a time, checking
the dipstick.
The approximate quantity of oil needed to
fill between the low level and the full level
on the dipstick is indicated below for ref-
erence.
When the level reaches within the correct
range, install the filler cap hand- tight.
Oil quantity, L (qt., lmp. qt.):
1.3 (1.4, 1.1)
NOTICE

Avoid overfilling, or the engine
could be damaged.

Check the oil level on the dipstick
once again after adding the oil.
Engine oil selection
Use API grade SJ, Energy- Conservingº
or ILSAC multigrade engine oil.
Recommended viscosity (SAE):
SAE 5W- 30 is the best choice for your
vehicle, for good fuel economy, and
good starting in cold weather.
If you use SAE 10W- 30 engine oil in
extremely low temperatures, the engine
may become difficult to start, so SAE
5W- 30 engine oil is recommended.
ProCarManuals.com
