2000 SUBARU IMPREZA Clutch

7-16Stopping the engine
WARNING
Do not stop the engine when the vehicle is moving. This will
cause loss of power to the power steering and the brake booster,making steering and braking more difficult. It could also result in
accidental activation of the “LOCK” position on the ignition
switch, causing the steering wheel to lock.
The ig nition switc h should b e turned off only when the eng ine is id ling .
Manual transmission
WARNING
Do not drive the vehicle with the clutch disengaged (i.e., when theclutch pedal is depressed) or with the shift lever in the neutralposition. Engine braking has no effect in either of these condi-tions and the risk of an accident is consequently increased.
CAUTION
Shift into reverse ONLY when the vehicle has completelystopped. It may cause damage to the transmission to try shiftinginto reverse when the vehicle is moving.
The manual transmission is a fully sync hromeshed 5- forward and 1-re-
verse sp eed transmission.

10
Maintenance and service
Maintenance schedule 10-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 10-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 10-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 10-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling system 10-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 10-13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 10-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 10-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive belts 10-18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 10-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission fluid 10-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (Automatic transmission vehicles) 10-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear differential gear oil 10-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering fluid 10-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 10-26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (2.5 liter MT models) 10-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake booster 10-29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery 10-29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield washer fluid 10-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 10-32 . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 10-34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch pedal (Manual transmission vehicles) 10-36 . . . . . . . . . . . . . . . . . . .
Replacement of brake pad and lining 10-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake stroke 10-38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 10-39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressure 10-39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 10-40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (if equipped) 10-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 10-44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse and fusible link 10-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 10-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 10-49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 10-49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-28Clutch fluid (2.5 liter MT models)
WARNING
Never let clutch fluid contact your eyes because clutch fluid can
be harmful to your eyes. If clutch fluid gets in your eyes, immedi-
ately flush them thoroughly with clean water. For safety, whenperforming this work, wearing eye protection is advisable.
CAUTION
Clutch fluid absorbs moisture from the air. Any absorbed
moisture can cause improper clutch operation. If the vehicle requires frequent refilling, there may be a leak. If
you suspect a problem, have the vehicle checked at your
SUBARU dealer. Never use different brands of clutch fluid together.
When clutch fluid is added, be careful not to allow any dirt into
the tank.
Chec k the fluid level on the outsid e of the reservo ir. If the level is b elow
“ MIN ” level mark, ad d the rec ommend ed c lutc h fluid to “MAX ” level mark.
Use only c lutc h fluid from a sealed c ontainer.
HG0355
“MAX”
level mark
“MIN”
level mark

Maintenance and service10-29
–
CONTINUED –

Recommended clutch fluid
FMVSS No. 116, fresh DOT 3 or 4 brake fluid
Brake booster
If the b rake b ooster d oes not op erate as d esc rib ed b elow, have it
c hec ked b y your SUBARU d ealer.
1. With the eng ine off, d ep ress the b rake p ed al seve ral times, ap p lying
the same p ed al forc e eac h time. The d istanc e the p e d al travels should
not vary.
2. With the b rake p ed al d ep ressed , start the eng ine. The p ed al should
move slig htly d own to the floor.
3. With the b rake p ed al d ep ressed , stop the eng ine a nd keep the p ed al
p ressed for 30 sec ond s. The p ed al heig ht should not c hang e.
4. Start the eng ine ag ain and run for ab out one minu te then turn it off.
Dep ress the b rake p ed al several times to c hec k the b rake b ooster.
Brake b ooster op erates p rop erly if the p ed al stroke d ec reases with eac h
d ep ression. Battery
WARNING
Before beginning work on or near any battery, be sure to extin-
guish all cigarettes, matches, and lighters. Never expose a bat- tery to an open flame or electric sparks. Batteries give off a gaswhich is highly flammable and explosive. For safety, in case an explosion does occur, wear eye protec-
tion or shield your eyes when working near any battery. Never
lean over a battery. Do not let battery fluid contact eyes, skin, fabrics, or paint be-
cause battery fluid is a corrosive acid. If battery fluid gets on yourskin or in your eyes, immediately flush the area with water thor-
oughly. Seek medical help immediately if acid has entered the

10-36Clutch pedal (Manual transmission vehicles)
Chec k the c lutc h p ed al free p lay and reserve d istan
c e ac c ord ing to the
maintenanc e sc hed ule in the “Warranty and Maintenanc e Booklet ”.
Checking the clutch function
Chec k the c lutc h eng ag ement and d iseng ag ement.
1. With the eng ine id ling , c hec k that there are no a b normal noises
when the c lutc h p ed al is d ep ressed , and that shifti ng into 1st or re-
verse feels smooth.
2. Start the vehic le b y releasing the p ed al slowly t o c hec k that the en-
g ine and transmission smoothly c oup le without any s ig n of slip p ag e.
Checking the clutch pedal free play
OM-H0224
2.5L MT models
0.11 — 5.59 in
(3.0 — 15.0 mm)
2.2L MT models 0.40 — 0.79 in
(10.0 — 20.0 mm)
Lig htly p ress the c lutc h p ed al d own with your fing e r until you feel re-
sistanc e, and c hec k the free p lay.
If the free p lay is not within p rop er sp ec ific ation , c ontac t your
SUBARU d ealer.
