2000 SUBARU IMPREZA light

Maintenance and service10-53
–
CONTINUED –

Front turn signal light Type A
HGA011BB
1. Remove the b olt sec uring the front turn sig nal li g ht assemb ly.
2. Remove the front turn sig nal lig ht assemb ly from the front b ump er
and remove the b ulb soc ket b y turning it c ounterc lo c kwise.
3. Remove the b ulb from the soc ket b y p ushing it in and turning
c loc kwise, then install a new b ulb .
4. Install the removed p arts in the reverse ord er of removal.
Type B
HG0194
1. Remove the front turn sig nal lig ht assemb ly mount ing sc rews using
the p hillip s sc rewd river.
2. Remove the lens from the front turn sig nal lig ht assemb ly.

10-543. Remove the b ulb from the soc ket b y p ushing it in
and turning
c ounterc loc kwise. Install a new b ulb .
4. Reinstall the lens to the front turn sig nal lig ht assemb ly and tig hten
the mounting sc rews.
Side turn signal light
OM-H0246
1. Pull the left sid e of the turn sig nal lig ht assem b ly while moving it for-
ward in relation to the vehic le.
2. Remove the b ulb hold er from the sid e turn sig nal lig ht assemb ly b y
turning it c ounterc loc kwise.
3. Pull the b ulb out of the soc ket. Install a new b u lb .
4. Set the b ulb hold er into the sid e turn sig nal lig ht assemb ly and turn it
c loc kwise until it loc ks.
5. Reinstall the sid e turn sig nal lig ht assemb ly on the sid e of the front
fend er.

Maintenance and service10-55
–
CONTINUED –

Rear combination lights Sedan and Coupe
OM-H0446
HG0241
1. Remove the sp are tire c over.
2. Remove the c lip from the rear trunk trim with a r eg ular sc rew d river.
3. Remove the nut sec uring the rear trunk trim.
OM-H0447
4. Op en the rear p ortion of the sid e trunk trim p ane l.
5. Remove the b ulb hold er from the rear c omb ination lig ht assemb ly
b y turning it c ounterc loc kwise.
6. Remove the b ulb from the soc ket b y p ushing it and turning c oun-
terc loc kwise. Install a new b ulb .
7. Set the b ulb hold er into the rear c omb ination lig ht assemb ly and
turn it c loc kwise until it loc ks.
8. Sec ure the rear trunk trim p anel with the nut and the c lip s.

Maintenance and service10-57
–
CONTINUED –

License plate light
HG0198
1. Remove the mounting sc rews using a p hillip s sc rew d river.
2. Remove the c over and lens.
3. Pull the b ulb out of the soc ket. Install a new b u lb .
4. Reinstall the lens and c over.
5. Tig hten the mounting sc rews. Interior light, spot light
OM-H0251
OM-H0250
1. Remove the lens b y p rying the ed g e of the lens wi th a reg ular sc rew-
d river.
2. Pull the b ulb out of the soc ket. Install a new b u lb .
3. Reinstall the lens.

10-58
Dome/Rear map reading lights (if equipped)
CAUTION
While sitting in the vehicle, be sure to touch the metal frame of
the vehicle to allow all static electricity to be discharged prior to replacing bulbs. Always use recommended replacement bulbs.
HBB038BA
HBB037BA
1. Remove the d ome lig ht lens as follows:
Insert a small flat-tip p ed sc rewd river into the c en ter slot in the front ed g e
of the lens and lever the lens d ownward in suc h a w ay that it may b e
b owed and d iseng ag ed from the mounting tab s.
2. To rep lac e the d ome lig ht b ulb (c enter b ulb ): rem ove the d ome lig ht
b y p ulling it out of its retainer c lip s, then inser t a new b ulb into the retain-
er c lip s.
3. To rep lac e the map lig ht b ulb s: use a Phillip s he ad sc rewd river to re-
move the two mounting sc rews loc ated on either sid e of the lamp assem-
b ly. Pull the assemb ly d ownward out of the head line r. At this time, use
c are not to touc h the c irc uit b oard .
4. Remove the nec essary b ulb soc ket from the c irc uit b oard b y g rasp ing
it on the b ac ksid e of the lamp assemb ly and twistin g c ounterc loc kwise to
d iseng ag e.
5. Pull the b ulb out of the soc ket. Install a new b u lb b y p ushing it into the
soc ket.
