8-6mod erate sp eed . Then start the eng ine of the vehic l
e that has the d is-
c harg ed b attery.
6. When finished , c arefully d isc onnec t the c ab les in exac tly the re-
verse ord er.
Flat tires
WARNING
Do not jack up the vehicle on an incline or a loose road sur-
face. The jack can come out of the jacking point or sink into theground and this can result in a severe accident. Use only the jack provided with your vehicle. The jack sup-
plied with the vehicle is designed only for changing a tire. Neverget under the vehicle while supporting the vehicle with this jack. Always turn the engine off before raising the flat tire off the
ground using the jack. Never swing or push the vehicle sup-ported with the jack. The jack can come out of the jacking pointdue to a jolt and this can result in a severe accident. Do not use oil or grease on the wheel studs or nuts when the
spare tire is installed. This could cause the nuts to become looseand lead to an accident. Never place a tire or tire changing tools in the passenger
compartment after changing wheels. In a sudden stop or colli-
sions, loose equipment could strike occupants and cause injury.Store the tire and all tools in the proper place.
If you have a flat tire while d riving , never b rake sud d enly; keep d riving
straig ht ahead while g rad ually red uc ing sp eed . Then slowly p ull off the
road to a safe p lac e.
1. Park on a hard , level surfac e, whenever p ossib le, then stop the en-
g ine.
2. Set the p arking b rake sec urely and shift a manual transmission ve-
hic le in reverse or an automatic transmission vehic le in the “P ” (Park)
p osition.

Maintenance and service10-51
–
CONTINUED –
4. Disc onnec t the c onnec tor b ehind the c ase c ap .
5. Release the retainer sp ring .
6. Rep lac e the b ulb with a new one. Then rec onnec t t
he c onnec tors
and reinstall the removed p arts in the reverse ord e r of removal.
Type B
HG0326
HG0325
1. Remove the front fog lig ht c over.
2. Remove the front fog lig ht assemb ly b y removing t he two b olts.
3. Disc onnec t the c onnec tor.
4. Remove the front fog lig ht c ase c ap b y turning it c ounterc loc kwise.
HG0327
Spring
Connector
5. Disc onnec t the c onnec tor b ehind the c ase c ap .
6. Release the retainer sp ring .
7. Rep lac e the b ulb with a new one. Then rec onnec t t he c onnec tors
and reinstall the removed p arts in the reverse ord e r of removal.

Maintenance and service10-53
–
CONTINUED –

Front turn signal light Type A
HGA011BB
1. Remove the b olt sec uring the front turn sig nal li g ht assemb ly.
2. Remove the front turn sig nal lig ht assemb ly from the front b ump er
and remove the b ulb soc ket b y turning it c ounterc lo c kwise.
3. Remove the b ulb from the soc ket b y p ushing it in and turning
c loc kwise, then install a new b ulb .
4. Install the removed p arts in the reverse ord er of removal.
Type B
HG0194
1. Remove the front turn sig nal lig ht assemb ly mount ing sc rews using
the p hillip s sc rewd river.
2. Remove the lens from the front turn sig nal lig ht assemb ly.

Maintenance and service10-59
–
CONTINUED –
6. Reinstall the soc ket in the c irc uit b oard . Then,
fit the lamp assemb ly
b ac k into the head liner.
7. Reinstall the lens in the reverse ord er of remova l.
