2000 SUBARU IMPREZA Brake fluid

10
Maintenance and service
Maintenance schedule 10-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 10-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 10-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 10-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling system 10-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 10-13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 10-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 10-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive belts 10-18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 10-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission fluid 10-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (Automatic transmission vehicles) 10-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear differential gear oil 10-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering fluid 10-25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 10-26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (2.5 liter MT models) 10-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake booster 10-29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery 10-29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield washer fluid 10-31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 10-32 . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 10-34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch pedal (Manual transmission vehicles) 10-36 . . . . . . . . . . . . . . . . . . .
Replacement of brake pad and lining 10-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake stroke 10-38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 10-39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressure 10-39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 10-40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (if equipped) 10-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 10-44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse and fusible link 10-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 10-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 10-49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 10-49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-4
Always use the proper tools and make certain that they are
well maintained. Never get under the vehicle supported only by jack. Always
use a safety stands to support the vehicle. Never keep the engine running in a poorly ventilated area,
such as a garage or other closed areas. Do not smoke or allow open flames around the fuel or battery.
This will cause a fire. Wear adequate eye protection to guard against getting oil or
other fluids in your eyes. If something does get in your eyes,
thoroughly wash it out with clean water. Because the fuel system is under pressure, replacement of the
fuel filter should be performed only by your SUBARU dealer. The SRS airbag has no user-serviceable parts. Tampering with
or disconnecting the system ’s wiring could result in accidental
inflation of the airbag or could make the system inoperative,
which may result in serious injury. The wiring harnesses of theSRS airbag system are covered with yellow insulation and the
connectors of the system are yellow, for easy identification. Donot use electrical test equipment on any circuit related to the SRSairbag system. For required servicing of the SRS airbag, see your
nearest SUBARU dealer. Before checking or servicing in the engine compart- ment
Always stop the engine and set the parking brake firmly to pre-
vent the vehicle from moving. Always let the engine cool down. Engine parts become very
hot when the engine is running and remain hot for some time af-ter the engine is stopped. Do not spill engine oil, engine coolant, brake fluid or any other
fluid on hot engine components. This may cause a fire. Always remove the key from the ignition switch. When the
ignition switch is in the “ON” position, the cooling fan may oper-
ate suddenly even when the engine is stopped.

10-6Engine compartment overview
1 Manual transmission oil level
g aug e (MT) (p ag e 10-19) or
Differential g ear oil level
g aug e (AT) (p ag e 10-22)
2 Air c leaner element
(p ag e 10-16)
3 Clutc h fluid reservoir
(p ag e 10-28)
4 Automatic transmission fluid
level g aug e (p ag e 10-20)
5 Brake fluid reservoir
(p ag e 10-26)
6 Fuel filter 7
Wind shield washer tank
(p ag e 10-31)
8 Fuse b ox (p ag e 10-44)
9 Battery (p ag e 10-29)
Q Eng ine oil filler c ap
(p ag e 10-7)
W Eng ine c oolant reservoir
(p ag e 10-13)
E Eng ine oil level g aug e
(p ag e 10-7)
R Power steering fluid reservoir
(p ag e 10-25)
T Rad iator c ap (p ag e 10-13) HGA017BB

10-264. Remove the d ip stic k ag ain and c hec k the fluid lev
el on it. If it is
b elow the lower level of the “HOT ” rang e, ad d the rec ommend ed
steering fluid up to the sp ec ified rang e of the d ip stic k.
If the fluid level is extreme low, it may ind ic ate p ossib le leakag e. Con-
sult your SUBARU d ealer for insp ec tion. Checking the fluid level when the fluid is cold
When the fluid level has to b e c hec ked without warm ing up the p ower
steering system (ap p roximately 70 F [ 21 C] ), read the fluid level on
the “COLD ” rang e.
Recommended fluid
“ Dexron II, Dexron II E or Dexron III ” Type Automatic Transmis-
sion Fluid
Brake fluid
Checking the fluid level
WARNING
Never let brake fluid contact your eyes because brake fluid can
be harmful to your eyes. If brake fluid gets in your eyes, immedi-
ately flush them thoroughly with clean water. For safety, whenperforming this work, wearing eye protection is advisable. Brake fluid absorbs moisture from the air. Any absorbed mois-
ture can cause a dangerous loss of braking performance. If the vehicle requires frequent refilling, there may be a leak. If
you suspect a problem, have the vehicle checked at your
SUBARU dealer.

Maintenance and service10-27
–
CONTINUED –
CAUTION
Never use different brands of brake fluid together.
When adding brake fluid, be careful not to allow any dirt into
the reservoir. Never splash the brake fluid over painted surfaces or rubber
parts. Alcohol contained in the brake fluid may damage them.
Chec k the fluid level monthly.
HGA009BB
Chec k the fluid level on the outsid e of the reservo ir. If the level is b e-
low “MIN ”, ad d the rec ommend ed b rake fluid to “MAX ”.
Use only b rake fluid from a sealed c ontainer. Recommended brake fluid
FMVSS No. 116, fresh DOT 3 or 4 brake fluid

Maintenance and service10-29
–
CONTINUED –

Recommended clutch fluid
FMVSS No. 116, fresh DOT 3 or 4 brake fluid
Brake booster
If the b rake b ooster d oes not op erate as d esc rib ed b elow, have it
c hec ked b y your SUBARU d ealer.
1. With the eng ine off, d ep ress the b rake p ed al seve ral times, ap p lying
the same p ed al forc e eac h time. The d istanc e the p e d al travels should
not vary.
2. With the b rake p ed al d ep ressed , start the eng ine. The p ed al should
move slig htly d own to the floor.
3. With the b rake p ed al d ep ressed , stop the eng ine a nd keep the p ed al
p ressed for 30 sec ond s. The p ed al heig ht should not c hang e.
4. Start the eng ine ag ain and run for ab out one minu te then turn it off.
Dep ress the b rake p ed al several times to c hec k the b rake b ooster.
Brake b ooster op erates p rop erly if the p ed al stroke d ec reases with eac h
d ep ression. Battery
WARNING
Before beginning work on or near any battery, be sure to extin-
guish all cigarettes, matches, and lighters. Never expose a bat- tery to an open flame or electric sparks. Batteries give off a gaswhich is highly flammable and explosive. For safety, in case an explosion does occur, wear eye protec-
tion or shield your eyes when working near any battery. Never
lean over a battery. Do not let battery fluid contact eyes, skin, fabrics, or paint be-
cause battery fluid is a corrosive acid. If battery fluid gets on yourskin or in your eyes, immediately flush the area with water thor-
oughly. Seek medical help immediately if acid has entered the
