Seat, seat belt and SRS airbag2-37
–
CONTINUED –

SRS airbag system monitors
HS0154
SRS airbag system warning light
A d iag nostic system c ontinually monitors the read in
ess of the SRS air-
b ag system while the vehic le is b eing d riven. The S RS airb ag system
warning lig ht “AIRBAG ” will show normal system op eration b y lig hting for
ab out 6 sec ond s when the ig nition key is turned to the “ON ” p osition.
The following c omp onents are monitored b y the ind ic ator:
Front sub sensor (Rig ht hand sid e)
Front sub sensor (Left hand sid e)
Airb ag c ontrol mod ule (inc lud ing imp ac t sensors)
Airb ag mod ule (Driver ’s sid e)
Airb ag mod ule (Passeng er ’s sid e)
All related wiring
In the event of a malfunc tion ind ic ated b y any of f ollowing , the vehic le
should b e taken p romp tly to your nearest SUBARU d ea ler to have the
system c hec ked . Unless c hec ked and rep aired , the SR S airb ag s will not
func tion reliab ly: Flashing or flic kering of the ind ic ator lig ht.
No illumination of the warning lig ht when the ig nit ion switc h is first
turned to the “ON ” p osition.
Continuous illumination of the warning lig ht.
Illumination of the warning lig ht while d riving .

2-38
SRS airbag system servicing
WARNING
When discarding an airbag module or scrapping the entire car
damaged by a collision, consult your SUBARU dealer. The SRS airbag has no user-serviceable parts. Do not use
electrical test equipment on any circuit related to the SRS airbag
system. For required servicing of the SRS airbag, see your near-
est SUBARU dealer. Tampering with or disconnecting the sys-
tem’ s wiring could result in accidental inflation of the SRS airbag
or could make the system inoperative, which may result in seri-
ous injury. The wiring harnesses of the SRS airbag system arecovered with yellow insulation and the system connectors areyellow for easy identification.
CAUTION
If you need service or repair in areas listed below, we recommend
that you have an authorized SUBARU dealer perform the work. The
SRS airbag control module, impact sensors and airbag modules
are stored in these areas.
Under the center console
Inside each front fender
Steering wheel and column and nearby areas
Instrument panel and nearby areas
In the event that the SRS airbag is deployed, replacement of the sys-
tem should be performed only by an authorized SUBARU dealer.When the components of the SRS airbag system are replaced, useonly genuine SUBARU parts.
To ensure their long -term reliab ility, the SRS airb ag s must b e insp ec ted
b y a SUBARU d ealer ten years after the d ate of manu fac ture, whic h is
shown on the c ertific ation lab el attac hed to the d r iver’s d oor.

Seat, seat belt and SRS airbag2-39
–
CONTINUED –
NOTE In the following cases, contact your SUBARU dealer as soon as pos- sible.
The front part of the vehicle was involved in an accident in
which the SRS airbags did not deploy. The pad section of the steering wheel or front passenger ’s air-
bag cover is scratched, cracked, or otherwise damaged.
Precautions against vehicle modification
WARNING
To avoid accidental activation of the system or rendering the
system inoperative, which may result in serious injury, no modifi-cations should be made to any components or wiring of the SRSairbag system.This includes following modifications: Installation of custom steering wheel
Attachment of additional trim materials to the dashboard
Installation of additional electrical/electronic equipment such
as a mobile two-way radio on or near the SRS airbag system
components and/or wiring is not advisable. This could interferewith proper operation of the SRS airbag system.
CAUTION
Do not perform any of the following modifications. Such modifi-cations can interfere with proper operation of the SRS airbag sys-tem.
Attachment of any equipment (brush bar, winches, snow
plow, skid plate, etc.) other than SUBARU genuine accessoryparts to the front end Modification of the suspension system or front end structure
Installation of a tire of different size and construction from
the original tires listed on the tire placard attached to the doorjamb

7-56c ient slac k in the c hains taking tig ht-turn situati
ons into ac c ount; how-
ever, b e c areful not to let them d rag on the g round .
For more information ab out the safety c hain c onnec t ion, refer to the
instruc tions for your hitc h and trailer. n Side mirrors
After hitc hing a trailer to your vehic le, c hec k tha t the stand ard sid e
mirrors p rovid e a g ood rearward field of view witho ut sig nific ant b lind
sp ots. If sig nific ant b lind sp ots oc c ur with the ve hic le’s stand ard sid e
mirrors, use towing mirrors that c onform with Fed er al, state/p rovinc e
and /or other ap p lic ab le reg ulations.
HS0146
n Trailer lights CAUTION
Direct splicing or other improper connection of trailer lights may
damage your vehicle ’s electrical system and cause a malfunction
of your vehicle ’s lighting system.
Connec tion of trailer lig hts to your vehic le ’s elec tric al system req uires
mod ific ations to the vehic le ’s lig hting c irc uit to inc rease its c ap ac ity
and ac c ommod ate wiring c hang es. To ensure the trail er lig hts are
c onnec ted p rop erly, p lease c onsult your SUBARU d eal er. Chec k for
p rop er op eration of the turn sig nals and the b rake lig hts and p arking
lig hts eac h time you hitc h up .

10-4
Always use the proper tools and make certain that they are
well maintained. Never get under the vehicle supported only by a jack. Always
use a safety stand to support the vehicle. Never keep the engine running in a poorly ventilated area,
such as a garage or other closed areas. Do not smoke or allow open flames around the fuel or battery.
This will cause a fire. Wear adequate eye protection to guard against getting oil or
other fluids in your eyes. If something does get in your eyes,
thoroughly wash it out with clean water. Because the fuel system is under pressure, replacement of the
fuel filter should be performed only by your SUBARU dealer. The SRS airbag has no user-serviceable parts. Tampering with
or disconnecting the system ’s wiring could result in accidental
inflation of the airbag or could make the system inoperative,
which may result in serious injury. The wiring harnesses of theSRS airbag system are covered with yellow insulation and the
connectors of the system are yellow, for easy identification. Donot use electrical test equipment on any circuit related to the SRSairbag system. For required servicing of the SRS airbag, see your
nearest SUBARU dealer. Before checking or servicing in the engine compartment
Always stop the engine and set the parking brake firmly to pre-
vent the vehicle from moving. Always let the engine cool down. Engine parts become very
hot when the engine is running and remain hot for some time af-ter the engine is stopped. Do not spill engine oil, engine coolant, brake fluid or any other
fluid on hot engine components. This may cause a fire. Always remove the key from the ignition switch. When the
ignition switch is in the “ON” position, the cooling fan may oper-
ate suddenly even when the engine is stopped.

10-42b e sure to rep lac e them with g enuine SUBARU p arts d
esig ned for alumi-
num wheels.
Fuses
HS0203
HS0202
The fuses are d esig ned to melt d uring an overload t o p revent d amag e to
the wiring harness and elec tric al eq uip ment. The fu ses are loc ated in
two fuse b oxes.
If any lig hts, ac c essories or other elec tric al c ont rols d o not op erate, in-
sp ec t the c orresp ond ing fuse. If a fuse has b lown, rep lac e it.
HS0204
Good Blown

Maintenance and service10-45
–
CONTINUED –
Main fuse and fusible link
HS0203
The main fuses and fusib le link are d esig ned to mel
t d uring an overload
to p revent d amag e to the wiring harness and elec tri c al eq uip ment.
Chec k the main fuses and fusib le link if any elec tr ic al c omp onent fails to
op erate (exc ep t the starter motor) and other fuses are g ood . A melted
main fuse or fusib le link must b e rep lac ed . Use onl y rep lac ements with
the same sp ec ified rating as the melted main fuse o r fusib le link. If a
main fuse or fusib le link b lows after it is rep lac e d , have the elec tric al sys-
tem c hec ked b y your nearest SUBARU d ealer.
Installation of accessories
Always c onsult your SUBARU d ealer b efore installing fog lig hts or any
other elec tric al eq uip ment in your vehic le. Suc h ac c essories may c ause
the elec tronic system to malfunc tion if they are in c orrec tly installed or if
they are not suited for the vehic le.
