2000 PONTIAC FIREBIRD headlamp

2-21 Remote Keyless Entry Verification
This feature provides feedback when the vehicle receives a
command from the remote keyless entry transmitter.
Programmable Modes
Your vehicle can be programmed to one of the
following modes:
Mode 1: All Off (The headlamps will not flash and the
horn will not sound to provide you feedback that a
lock/unlock command has been received by the remote
keyless entry transmitter.)
Mode 2: Horn and Lamps/Lamps (Your horn will sound
briefly and your parking lamps will flash when you
press LOCK on the remote keyless entry transmitter.
Only your parking lamps will flash when you press
UNLOCK.)
Mode 3: Horn and Lamps (Your horn will sound briefly
and your parking lamps will flash every time you push
LOCK or UNLOCK.)
Mode 4: Lamps (Your parking lamps will flash every
time you press LOCK or UNLOCK.)Mode 5: Lamps/Horn and Lamps/Lamps (Your lamps
will flash upon the first press on LOCK, your lamps will
flash and your horn will sound upon the second press
on LOCK and your lamps will flash upon any press
on UNLOCK.)
Vehicles are delivered programmed in Mode 5.
To change the mode, do the following:
1. Press the UNLOCK button on the remote keyless
entry transmitter.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is
set for.
3. Press the UNLOCK button, again, on the remote
keyless entry transmitter until you hear the number
of chimes that correspond to the mode selection
you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-46
Tilt Wheel
A tilt wheel allows you to adjust the steering wheel
before you drive. The tilt wheel is located on the left
side of the steering column.
You can also raise it to the highest level to give your
legs more room when you exit and enter the vehicle.
To tilt the wheel, hold the steering wheel and pull the
lever. Move the steering wheel to a comfortable level,
then release the lever to lock the wheel in place.
Turn Signal/Multifunction Lever
The lever located on the left side of the steering column
includes your:

Turn Signal and Lane Change Indicator

Headlamp High/Low
-Beam Changer and
Passing Signal

Windshield Wipers

Windshield Washer

Cruise Control

2-47 Turn Signal and Lane Change Indicator
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is finished, the lever will return automatically.
An arrow on the instrument
panel cluster will flash in
the direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
As you signal a turn or a lane change, if the arrows don't
flash but just stay on as you signal a turn or lane change,
a signal bulb may be burned out and other drivers won't
see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse (see ªFuses and Circuit
Breakersº in the Index).
Headlamp High/Low-Beam Changer
When the high beams are
on, this light located on the
instrument panel cluster
also will be on.
To change the headlamps from low beam to high or
from high beam to low, pull the turn signal lever all the
way toward you. Then release it.
Windshield Wipers
You control the windshield wipers by turning the band
with the wiper symbol on it, located on the turn
signal/multifunction lever.
For a single wiping cycle, turn the band to MIST. Hold
it there until the wipers start, then let go. The wipers will
stop after one cycle. If you want more cycles, hold the
band on MIST longer.
You can set the wiper speed for a long or short delay
between wipes. This can be very useful in light rain or
snow. Turn the band to choose the delay time. The
closer to LO, the shorter the delay.

2-51
Ending Out of Cruise Control
There are several ways to turn off the cruise control:

Step lightly on the brake pedal or push the clutch
pedal, if you have a manual transmission, or

Move the cruise switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Exterior Lamps
The main lamp control is a knob that works these lamps:

Headlamps

Taillamps

Parking Lamps

License Lamps

Sidemarker Lamps

Instrument Panel Lights
This setting turns on your parking lamps and other
operating lamps without your headlamps.
This setting turns on your headlamps and other
operating lamps and lights.
Turn the knob to OFF to turn off the lamps.
Headlamps on Reminder
If you turn the ignition off and leave the lamps on, you
will hear a chime lasting up to five seconds. If the lamps
are still on when you open the driver's door, the chime
will sound again.

2-52 Headlamp Doors
The headlamp doors are designed to open when you turn
the headlamps on and close when you turn the
headlamps off. The headlamp doors can be opened
without turning on the headlamps by turning the
headlamps on, then turning the switch back to the
parking lamps position.
The headlamp doors should be open when driving in icy
or snowy conditions to prevent the doors from freezing
closed, and when washing the vehicle to help clean
the headlamps.
To open the headlamp doors manually:
1. Open the hood.
2. Remove the plastic cover from the retractor
motor knob.
3. Turn the retractor motor knob counterclockwise until
the headlamp door is fully open. The knob will get
harder to turn when the headlamp door is all the
way up.
4. Reinstall the plastic cover on the retractor
motor knob.
To manually close the headlamp doors, turn the lamps off
and turn the retractor motor knob clockwise. If the
headlamp doors aren't working properly, see your dealer.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
For Canadian vehicles, a light sensor on top of the
instrument panel automatically turns the headlamps on,
so be sure it isn't covered.
The DRL system will not activate if the parking brake is
engaged prior to turning the ignition on.
The DRL system will make your front turn signal lamps
come on when:

The ignition is on,

the headlamp switch is OFF,

the parking brake is released, and

it is bright enough outside (on Canadian vehicles).

2-53
When the DRL are on, only your front turn signal lamps
will be on. The taillamps, sidemarker and other lamps
won't be on. Your instrument panel won't be lit up
either. When you use your turn signals, the front turn
signal and the taillamp of the desired side will flash.
For Canadian vehicles, when it's dark enough outside,
your front turn signal lamps will go out and your
headlamps will come on. The other lamps that come on
with your headlamps will also come on. When it's bright
enough outside, the regular lamps will go off, and your
front turn signal lamps will come on.
On a non
-Canadian vehicle, the headlamps have to be
turned on manually when you need them. On Canadian
and non
-Canadian vehicles, when the headlamps are
turned on, the front turn signal lamps will go out. When
you use your turn signals, the front turn signal lamp and
the taillamp on the desired side will flash.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Fog Lamps
Use your fog lamps for better vision in foggy or misty
conditions. Your parking lamps must be on or your fog
lamps won't work.
Your fog lamp switch is
located on your instrument
panel located to the left of
the steering wheel.
To turn the fog lamps on, push the right side of the fog
lamp switch and a light on the switch will come on
indicating that the fog lamps are on. Push the left side of
the fog lamp switch to turn the fog lamps off.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beam headlamps go
off, the fog lamps will come on again.
If your vehicle is equipped with the content
theft
-deterrent/alarm system and your fog lamp switch is
on, the fog lamps may flash to indicate operation of the
content theft
-deterrent/alarm system. See ªContent
Theft
-Deterrent/Alarm Systemº in the Index.

4-16
Driving at Night
Night driving is more dangerous than day driving. One
reason is that some drivers are likely to be impaired
-- by
alcohol or drugs, with night vision problems, or by fatigue.Here are some tips on night driving.

Drive defensively.

Don't drink and drive.

Adjust your inside rearview mirror to reduce the
glare from headlamps behind you.

Since you can't see as well, you may need to
slow down and keep more space between you and
other vehicles.

Slow down, especially on higher speed roads. Your
headlamps can light up only so much road ahead.

In remote areas, watch for animals.

If you're tired, pull off the road in a safe place
and rest.

4-17
No one can see as well at night as in the daytime. But as
we get older these differences increase. A 50
-year-old
driver may require at least twice as much light to see the
same thing at night as a 20
-year-old.
What you do in the daytime can also affect your night
vision. For example, if you spend the day in bright
sunshine you are wise to wear sunglasses. Your eyes will
have less trouble adjusting to night. But if you're
driving, don't wear sunglasses at night. They may cut
down on glare from headlamps, but they also make a lot
of things invisible.
You can be temporarily blinded by approaching
headlamps. It can take a second or two, or even several
seconds, for your eyes to readjust to the dark. When you
are faced with severe glare (as from a driver who
doesn't lower the high beams, or a vehicle with
misaimed headlamps), slow down a little. Avoid staring
directly into the approaching headlamps.Keep your windshield and all the glass on your vehicle
clean
-- inside and out. Glare at night is made much
worse by dirt on the glass. Even the inside of the glass
can build up a film caused by dust. Dirty glass makes
lights dazzle and flash more than clean glass would,
making the pupils of your eyes contract repeatedly.
Remember that your headlamps light up far less of a
roadway when you are in a turn or curve. Keep your
eyes moving; that way, it's easier to pick out dimly
lighted objects. Just as your headlamps should be
checked regularly for proper aim, so should your eyes
be examined regularly. Some drivers suffer from night
blindness
-- the inability to see in dim light -- and
aren't even aware of it.
