Windshield wiper/washer switch (P.2-15)
Instrument brightness control switch (P.2-18)Meters/gauges (P.2-3)Security indicator light (P.2-12) Cruise control main switch (P.5-14)
Headlight, fog light (if so equipped)
and turn signal switch (P.2-17)
Outside mirror remote control (P.3-13)Fuse box cover (P.8-23)
Tilting steering wheel lock lever (P.3-12) Driver supplemental air bag (P.1-8)
Ignition switch/steering lock (P.5-4) Cruise control set switch (P.5-14)
Power outlet (P.2-22) or cigarette lighter (accessory) (P.2-23)
Hazard warning flasher switch (P.2-20)Ventilator (P.4-2)
Heater/air conditioner control (P.4-3)
Clock (P.2-30)
Radio/cassette player (P.4-14)/CD player (P.4-19) Rear window and outside mirror (if so equipped) defogger switch (P.2-16)
Passenger supplemental air bag (P.1-8)
Glove box (P.2-25)
Tray (P.2-23) or ashtray (accessory) (P.2-23)
SIC1225
See the page indicated in parentheses for operating details.
Traction control system (TCS) cancel switch (if so equipped) (P.2-22)
INSTRUMENT PANEL2-2
Instruments and controls
Z
00.1.17/A33-D/V5.0
X

BRAKE BOOSTERCheck the brake booster function as follows:
1. With the engine off, press and release the
brake pedal several times. When brake
pedal movement (distance of travel) re-
mains the same from one pedal application
to the next, continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a
little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without
depressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradu-
ally with each depression as the vacuum is
released from the booster.
If the brakes do not operate properly, see your
NISSAN dealer.Press the pedal by hand and be sure the free
travel is within the limits shown above. If free
travel is too little or too much, see your
NISSAN dealer.
CAUTION
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
DI1021MC
CLUTCH PEDAL FUSES
Do-it-yourself
8-21
Z
00.1.17/A33-D/V5.0
X

PASSENGER COMPARTMENTIf any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are OFF.
2. Pull to open the fuse box lid.
3. Remove the fuse with the fuse puller.
4. If the fuse is open, replace it with a new
fuse.
5. If a new fuse also opens, have the electrical
system checked and repaired by your
NISSAN dealer.
SDI0966
Do-it-yourself
8-23
Z
00.1.17/A33-D/V5.0
X

Filler lid ...................................................... 3-10
Filler lid and cap ........................................ 3-10
Filler lid opener lever................................. 3-10
Fuel economy ............................................ 5-16
Fuel octane rating ..................................... 10-3
Fuel recommendation................................ 10-3
Gauge .......................................................... 2-5
Fuses .............................................................. 8-21
Fusible links .................................................... 8-22
G
Garage door opener, Integrated HomeLink
Universal Transceiver ..................................... 2-33
Gas cap .......................................................... 3-10
Gauge ............................................................... 2-3
Engine coolant temperature gauge ............. 2-5
Fuel gauge .................................................. 2-5
Odometer..................................................... 2-4
Speedometer ............................................... 2-4
Tachometer ................................................. 2-4
General maintenance ................................ 9-2, 9-3
Glasses case .................................................. 2-24
Glove box........................................................ 2-25
Glove box lock ................................................ 2-25
H
Hazard warning flasher switch........................ 2-20
Head restraints ................................................. 1-7
Headlamps, (Bulb replacement) ..................... 8-26
Headlights, (Bulb replacement) ...................... 8-26Headlights, Headlight switch........................... 2-17
Heated seats................................................... 2-21
Heater
Engine coolant heater ............................... 5-22
Heater and air conditioner controls ............. 4-3
Heater operation.......................................... 4-3
Operation, Semiautomatic air conditioner ... 4-4
HomeLink
Universal Transceiver .................. 2-33
Hood, release ................................................... 3-8
Horn ................................................................ 2-20
How to stop alarm, Theft warning .................. 2-13
I
Ignition switch ................................................... 5-4
Automatic transmission models .................. 5-4
Key positions ............................................... 5-6
Manual transmission models....................... 5-5
Immobilizer system ......................................... 2-13
Indicator lights and chimes (See warning/indicator
lights and chimes) ............................................. 2-9
Inside mirror .................................................... 3-13
Inspection/maintenance (I/M) test................. 10-20
Instrument panel ............................................... 2-2
Integrated HomeLink
Universal
Transceiver ..................................................... 2-33
Interior and cargo light .................................... 2-30
Interior light ..................................................... 2-30
Interior light replacement ................................ 8-27J
Jump starting .................................................... 6-7
K
Keyless entry, (See multi-remote control
system) ............................................................. 3-4
Keys .................................................................. 3-2
L
Label, Air conditioner specification label ...... 10-12
Label, Emission control information label ..... 10-11
Label, F.M.V.S.S. certification label.............. 10-11
Labels
Air bag warning labels............................... 1-19
Air conditioner specification label................ 4-3
Engine serial number .............................. 10-11
Vehicle identification number (VIN)......... 10-10
License plate, Installing front license plate... 10-13
Light
Air bag warning light ................................. 1-18
Bulb replacement ...................................... 8-25
Fog light switch ......................................... 2-19
Headlamps (Bulb replacement)................. 8-26
Headlight switch ........................................ 2-17
Headlights (Bulb replacement) .................. 8-26
Interior and cargo light .............................. 2-30
Interior light................................................ 2-30
Personal light............................................. 2-31
