2000 Mercury Sable tow bar

All Front Wheel Drive (FWD) vehicles
An example of recreational towing is towing your vehicle behind a
Motorhome. The following recreational towing guidelines are designed to
ensure that your transmission is not damaged. It is not recommended to
tow front wheel drive vehicles with the front drive wheels on the ground.
It is recommended to tow your vehicle with the drive wheels on a dolly
or two wheel car hauling trailer.
In case of a roadside emergency with a disabled vehicle (without access
to wheel dollies, car hauling trailer or flatbed transport vehicle) your
vehicle can be flat towed (all wheels on the ground) under the following
conditions:
²Place the transmission in N (Neutral).
²Maximum speed is 56 km/h (35 mph).
²Maximum distance is 80 km (50 miles).
LUGGAGE RACK (IF EQUIPPED)
The rear crossbar can be adjusted to fit the item being carried. The front
crossbar does not move. Do not load more than 44 kg (100 lbs.) on the
luggage rack.
To adjust cross-bar position:
1. Loosen the thumbwheel at both
ends of the cross-bar.
2. Slide the cross-bar to the desired
location.
3. Tighten the thumbwheel at both
ends of the cross-bar.
Use adjustable tie down loops to secure the load.
Driving
128

²Anticipate stopping; slowing down may eliminate the need to stop.
²Sudden or hard accelerations may reduce fuel economy.
²Slow down gradually.
²Driving at reasonable speeds (traveling at 88 km/h [55 mph] uses 15%
less fuel than traveling at 105 km/h [65 mph]).
²Revving the engine before turning it off may reduce fuel economy.
²Using the air conditioner or defroster may reduce fuel economy.
²You may want to turn off the speed control in hilly terrain if
unnecessary shifting between third and fourth gear occurs.
Unnecessary shifting of this type could result in reduced fuel
economy.
²Warming up a vehicle on cold mornings is not required and may
reduce fuel economy.
²Resting your foot on the brake pedal while driving may reduce fuel
economy.
²Combine errands and minimize stop-and-go driving.
Maintenance
²Keep tires properly inflated and use only recommended size.
²Operating a vehicle with the wheels out of alignment will reduce fuel
economy.
²Use recommended engine oil. Refer toLubricant Specifications.
²Perform all regularly scheduled maintenance items. Follow the
recommended maintenance schedule and owner maintenance checks
found in your vehicle Scheduled Maintenance Guide.
Conditions
²Heavily loading a vehicle or towing a trailer may reduce fuel economy
at any speed.
²Carrying unnecessary weight may reduce fuel economy (approximately
0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried).
²Adding certain accessories to your vehicle (for example bug
deflectors, rollbars/light bars, running boards, ski/luggage racks) may
reduce fuel economy.
²Using fuel blended with alcohol may lower fuel economy.
Maintenance and care
184

IDENTIFYING YOUR VEHICLE
Certification label
The National Highway Traffic Safety
Administration Regulations require
that a Certification Label be affixed
to a vehicle and prescribe where the
Certification Label may be located.
The Certification Label is located on
the front door latch pillar on the
driver's side.
1
4
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
Capacities and specifications
209

anti-lock brakes (ABS) .....11,113
anti-theft ...................................11
brake ..........................................12
charging system ........................12
check coolant ............................11
cruise indicator .........................11
door ajar ......................................9
high beam ...................................8
low coolant ................................10
low fuel ......................................10
oil pressure ...............................12
safety belt ...................................9
service engine soon ....................9
speed control ............................46
traction control active ................8
turn signal indicator ...................8
Load limits .................................122
GAWR ......................................122
GVWR ......................................122
trailer towing ..........................122
Locks
autolock .....................................68
childproof ..................................53
Lubricant specifications ....206,207
Lumbar support, seats ...............75
Mirrors .........................................50
cleaning ...................................199
heated ........................................54
side view mirrors (power) .......54
Moon roof ....................................50
Motorcraft parts .................182,204
Octane rating ............................180
Odometer .....................................15
Oil (see Engine oil) ..................151
Overdrive ...................................118
Panic alarm feature, remote
entry system ................................60
Parking brake ............................114
Parts (see Motorcraft parts) ....204
Pedals (see Power adjustable
foot pedals) .................................42
Power adjustable foot pedals .....42Power distribution box
(see Fuses) ...............................135
Power door locks ........................53
Power steering ..........................116
fluid, checking and adding ....161
fluid, refill capacity ................205
fluid, specifications ..........206,207
Radio ............................................28
Relays .................................132,137
Remote entry system ............59,60
illuminated entry ......................61
locking/unlocking doors ......59,60
opening the trunk .....................60
panic alarm ...............................60
replacement/additional
transmitters ...............................61
replacing the batteries .............62
Roof rack ...................................128
Safety belts
(see Safety restraints) .....13,78,80
81,82,83,84,85
Safety defects, reporting ..........223
Safety
restraints ..78,80,81,82,83,84,85,86
belt minder ...............................89
cleaning the safety belts ...92,203
extension assembly ..................88
for adults ....................81,82,83,84
for children ........................99,100
lap belt ......................................86
warning light and chime ..9,13,88
Safety seats for children ..........101
Seat belts
(see Safety restraints) ...............78
Seats ............................................73
child safety seats ....................101
cleaning ............................202,203
SecuriLock passive
anti-theft system ....................69,70
Servicing your vehicle ..............147
Spark plugs,
specifications ......................204,207
