2000 MERCEDES-BENZ S CLASS parking brake

3 ContentsParcel net in trunk ........................204
Telephone, general ........................205
Garage door opener .......................206
Infrared reflecting
windshield ................................. 210
DrivingControl and operation of
radio transmitters ..................... 212
The first 1 000 miles
(1 500 km) ................................. 213
Maintenance ................................... 213
Tele Aid ........................................... 214
Catalytic converter ........................224
Emission control ............................225
Starter switch .................................226
Starter switch –
KEYLESS-GO ..............................228
Starting and turning off
the engine .................................. 231Automatic transmission ............... 233
Parking brake ................................ 242
Driving instructions ...................... 243
Drive sensibly – Save Fuel ....... 243
Drinking and driving ................ 243
Pedals .......................................... 243
Power assistance ........................ 244
Brakes .......................................... 244
Driving off ................................... 245
Parking ........................................ 246
Tires ............................................. 247
Snow chains ............................... 249
Winter driving instructions ..... 250
Block heater ................................ 251
Deep water .................................. 252
Passenger compartment ........... 252
Traveling abroad ........................ 252
Cruise control ................................ 253
Distronic (DTR) .............................. 256Brake assist system
(BAS) ........................................... 271
Antilock brake system
(ABS) ...........................................272
Electronic stability program
(ESP) ........................................... 274
Active body control (ABC) ............278
Level control system
for vehicles
with Airmatic system ...............279
Level control system
for vehicles
with Active Body Control
(ABC) ..........................................280
Ad aptive da mping system
(ADS) ...........................................283
Parking assist (Parktronic) ..........285
What you should know
at the gas station .......................290
Check regularly and
before a long trip ......................293

4 Contents
Instrument cluster displayMalfunction and indicator
lamps in the
instrument cluster ....................296
On-board diagnostic system .....296
Check engine malfunction
indicator lamp .............................296
Brake warning lamp ..................298
Supplemental restraint
system (SRS)
indicator lamp .............................299
Fuel reserve warning .................299
ABS malfunction
indicator lamp .............................300
Electronic stability
program (ESP) —
warning lamp ..............................301
Distronic (DTR) –
warning lamp ..............................301
Seat belt nonusage
warning lamp ..............................302Malfunction and
indicator lamp in the
center console ........................... 302
AIRBAG OFF indicator lamp .... 302
Malfunction and
warning messages in the
multifunction display .............. 303
DISPLAY DEFECTIVE ................ 304
BATTERY/ALTERNATOR .......... 305
ENTRANCE POSITION .............. 306
BRAKE ASSIST ........................... 306
BRAKE LINING WEAR .............. 307
BRAKE FLUID ............................ 307
PARKING BRAKE ....................... 308
TRUNK OPEN ............................. 308
ELEC. STABIL. PROG.
(Electronic stability
program) ..................................... 309
COOLANT (coolant level) .......... 310
COOLANT
(coolant temperature) ................ 311LIGHTING SYSTEM .................... 312
LIGHT SENSOR ........................... 314
ACTIV E BO DY CO NTROL
(ABC) ............................................ 314
TIRE PRESSURE ......................... 316
ENGINE OIL LEVEL ................... 318
CRUISE CONTROL ..................... 319
KEY ............................................... 319
DOOR ...........................................320
HOOD ...........................................320
TELE AID .....................................321
OIL TEMP.
(engine oil temperature) ...........321
CHIP-CARD (KEYLESS-GO) ......322
SELECTOR LEVER ......................323
TELEPHONE – FUNCTION .......323
WASHER FLUID .........................324
AIR SPRING (AirMatic) .............325
DISTRONIC (DTR) ......................326

23 Instruments and controls
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index 1Parking brake pedal, see page 242
2Hood lock release, see page 331
3Parking brake release, see page 242
4Exterior lamp switch, see page 156
5Easy-entry / exit feature, see page 66
Steering wheel adjustment, see page 105
6Headlamp washer button, see page 159
7Combination switch, see page 160
8Cruise control switch, see page 253, or
Distronic (DTR) switch, see page 2569Multifunction steering wheel, see page 120
Horn (with electronic key in starter switch
position 1 or 2)
Airbag, see page 94
10Instrument cluster, see page 114
11Voice recognition system switch, see separate
operating instructions
12Starter switch, see page 226
13Glove box lock, see page 194
14Glove box lid release, see page 194

115 Instrument cluster
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index 1Knob for instrument cluster illumination,
s e e p a g e 116
2Engine malfunction indicator lamp, see page 296
3Brake f luid low, parking brake engaged,
see page 307
4Supplemental restraint system (SRS) malfunction
indicator lamp, see page 299
5Coolant temperature gauge, see page 117
6Outside temperature indicator, see page 117
7Fuel gauge with reserve warning lamp, see page 299
8Left turn signal indicator lamp, see combination
switch, see page 160
9Speedometer, see page 118
10Electronic stability program (ESP) warning lamp,
system is adjusting to road conditions, see page 301
11Distance warning lamp – vehicles with Distronic
(DTR), distance to the vehicle ahead is insufficient,
see page 267 and 301.12Multifunction display, see page 120
Instrument cluster display, see page 303
13Trip odometer, see page 119 and 124
14Main odometer, see page 124
15Right turn signal indicator lamp, see combination
switch, page 160
16Tachometer, see page 119
17Gear range indicator display, see selector lever
positions, page 236
18Digital clock
To set the time, see COMAND operator’s manual
19Antilock brake system (ABS) malfunction indicator
lamp, see page 300
20High beam headlamp indicator,
see exterior lamp switch on page 156, and
combination switch on page 160
21Fasten seat belts, see page 302
22Reset button J, see pages 116, 119

201 Interior equipment
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Ashtrays
Center console
To o pen :
Briefly touch the mark on the cover, the ashtray opens
automatically.
To remove ashtray insert from center console:
Prior to removing the ashtray insert, move the gear
selector lever to position “N”.Press sliding knob (1) toward the right to eject the
insert.
To r e p l a c e i n s e r t :
Install insert into ashtray frame and push down to
engage into place.
Wa r n i n g !
Remove front ashtray only with vehicle standing
still. With the gear selector lever in position “N”,
turn off the engine and set the parking brake.
Otherwise the vehicle might move as a result of
unintended contact with the gear selector lever.
P68.20-0507-26
1

211 Contents - Driving
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
DrivingControl and operation of
radio transmitters ..................... 212
The first 1 000 miles
(1 500 km) ................................. 213
Maintenance ................................... 213
Tele Aid ........................................... 214
Catalytic converter ........................224
Emission control ............................225
Starter switch .................................226
Starter switch –
KEYLESS-GO ..............................228
Starting and turning off
the engine .................................. 231
Automatic transmission ...............233
Parking brake .................................242Driving instructions ...................... 243
Drive sensibly – Save Fuel ....... 243
Drinking and driving ................ 243
Pedals .......................................... 243
Power assistance ........................ 244
Brakes .......................................... 244
Driving off ................................... 245
Parking ........................................ 246
Tires ............................................. 247
Snow chains ............................... 249
Winter driving instructions ..... 250
Block heater ................................ 251
Deep water .................................. 252
Passenger compartment ........... 252
Traveling abroad ........................ 252
Cruise control ................................ 253
Distronic (DTR) .............................. 256
Brake assist system
(BAS) ...........................................271Antilock brake system
(ABS) ...........................................272
Electronic stability program
(ESP) ........................................... 274
Active body control (ABC) ............278
Level control system
for vehicles
with Airmatic system ...............279
Level control system
for vehicles
with Active Body Control
(ABC) ..........................................280
Ad aptive da mping system
(ADS) ...........................................283
Parking assist (Parktronic) ..........285
What you should know
at the gas station .......................290
Check regularly and
before a long trip ......................293

231 Starting and turning off the enginge
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Starting and turning off the engine
Before Starting
Ensure that parking brake is engaged and that selector
lever is in position “P” or “N”.
Starting
Important!
In areas where temperatures frequently drop below
-4°F(-20°C) we recommend that an engine block heater
be installed. Your authorized Mercedes-Benz Center will
advise you on this subject, see page 251.
Starting the engine with electronic key:
Do not depress accelerator.
Turn electronic key in starter switch to position 2.
Briefly turn electronic key in starter switch clockwise to
the stop and release. The starter will engage until the
engine is running.
If engine will not run, and the starting procedure stops,
turn electronic key completely to the left and repeat
starting the engine.After several unsuccessful attempts, have the system
checked at the nearest authorized Mercedes-Benz
Center.
Important!
Due to the installed starter non-repeat feature, the
electronic key must be turned completely to the left
before attempting to start the engine again.
Starting the engine with KEYLESS-GO:
Note:
For improved recognition of the chip card the doors
should be closed when pressing the start- / stop button.
Depress brake pedal during the starting procedure.
Briefly press start- / stop button on gear selector lever.
The starter will engage until the engine is running.
If engine will not run, and the starting procedure stops,
press start- / stop button on gear selector lever and
repeat starting the engine.
After several unsuccessful attempts, have the system
checked at the nearest authorized Mercedes-Benz
Center.

233 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Automatic transmissionThe automatic transmission selects individual gears
automatically, dependent upon
•Selector lever position
•Program mode selector
•Accelerator position
•Vehicle speed
The gear shifting process is continuously adapted,
dependent on the driving style, the driving situation
and the road characteristics.
Important!
When parking the vehicle or before working on the
vehicle with the engine running, firmly depress the
parking brake pedal and shift the selector lever into “P”.
P27.60-2174-27
