2000 MERCEDES-BENZ CL-CLASS technical data

386 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
3Engine number
4VIN, visible (lower edge of windshield)
5Emission control label
6Information label, California version
Vacuum line routing for emission control system
When ordering spare parts, please specify vehicle
identification and engine numbers.
P61.20-2014-26
ProCarManuals.com

387 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Layout of poly-V-belt drive
CL 500, CL 55 AMG
1Automatic belt tensioner
2Crankshaft
3Air conditioner compressor
4Coolant pumpCL 600
5Generator (alternator)
6Idler pulley
7Power steering pump
8Idler pulley (CL 600 only)
8
5
1
2
3
6
7
4
ProCarManuals.com

388 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Te ch n ica l d a t a
Model CL 500 (215.375
1)CL 55 AMG (215.373
1)CL 600 (215.378
1)
E n g i n e 113 113 13 7
Mode of operation 4-stroke engine,
gasoline injection4-stroke engine,
gasoline injection4-stroke engine,
gasoline injection
No. of cylinders8812
Bore 3.82 in (97.00 mm) 3.82 in (97.00 mm) 3.31 in (84.00 mm)
Stroke 3.31 in (84.00 mm) 3.60 in (92.00 mm) 3.43 in (87.00 mm)
Total piston displacement 303.5 cu.in. (4966 cm
3) 332.0 cu.in. (5439 cm
3) 353.6 cu.in. (5786 cm
3)
Compression ratio 10:1 10.5:1 10:1
Output acc.
to SAE J 1349302 hp/5600 rpm
(225 kW/5600 rpm)355 hp/5500 rpm
(265 kW/5500 rpm)362 hp/5500 rpm
(270 kW/5500 rpm)
Maximum torque acc.
to SAE J 1349339 ft-lb/2700 rpm
(460 Nm/2700 rpm)390 ft.lb/3150 rpm
(530 Nm/3150 rpm)391 ft-lb/4100 rpm
(530 Nm/4100 rpm)
Maximum engine speed 6000 rpm 6000 rpm 6000 rpm
Firing order 1-5-4-2-6-3-7-8 1-5-4-2-6-3-7-8 1-12-5-8-3-10-6-7-2-11-4-9
Poly-V-belt 2390 mm 2390 mm 2345 mm
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the
corresponding data of all special bodies and special equipment.
ProCarManuals.com

389 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Rims – Tires
1 Also permissible 245/45 ZR18
2 Also permissible 275/40 ZR18
3
3 Must not be used with snow chains.
Model CL 500, CL 600
(except Sport Package)
Rims (light alloy)
Wheel offset:7
1/2Jx17H2
1.81 in (46 mm)
All season tires:
Radial-ply tires 225/55 R17 97H
Winter tires:
Radial-ply tires 225/55 R17 97H M+S
Spare wheel
Rim (light alloy)
Wheel offset:7
1/2Jx17H2
2.0 in (51 mm)
All season tire:
Radial-ply tire 225/55 R17 97HModel CL 500, CL 600
(Sport Package)
Rims front axle
AMG light alloy rims
Wheel offset:8
1/2Jx18H2
1.73 in (44 mm)
Rims rear axle
AMG light alloy rims
Wheel offset:9
1/2Jx18H2
1. 81 i n ( 46 m m )
Radial-ply tires
front axle
rear axle245/45 R18 96Y
1
275/40 R18 99Y M0
2, 3
Spare wheel
Rim (light alloy)
Wheel offset:7
1/2Jx17H2
1. 81 i n ( 46 m m )
All season tire:
Radial-ply tire 225/55 R17 97H
ProCarManuals.com

390 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
1 Also permissible 245/45 ZR18
2 Also permissible 275/40 ZR18
3
3 Must not be used with snow chains.
Rims – Winter tires
Model CL 55 AMG
Rims front axle
AMG light alloy rims
Wheel offset:8
1/2Jx18H2
1.73 in (44 mm)
Rims rear axle
AMG light alloy rims
Wheel offset:9
1/2Jx18H2
1.81 in (46 mm)
Radial-ply tires
front axle
rear axle245/45 R18 96Y
1
275/40 R18 99Y M0
2, 3
Spare wheel
Rim (light alloy)
Wheel offset:7
1/2Jx17H2
1.81 in (46 mm)
All season tire:
Radial-ply tire 225/55 R17 97HModel CL 55 AMG
Rim (light alloy)
Wheel offset7
1/2 J x 17 H 2
1. 81 i n ( 46 m m )
Winter tires:
Radial-ply tires 225/55 R17 97H M+S
ProCarManuals.com

391 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Electrical system
Model CL 500 CL 55 AMG CL 600
Generator (alternator) 14 V/150 A 14 V/150 A 14 V/150 A
Starter motor 12V/1.7 kW 12V/1.7 kW 12V/2.2 kW
Battery 12V/100 Ah 12V/100 Ah 12V/100 Ah
Spark plugs
Electrode gap
Tightening torqueBosch F 8 DPER
Beru 14 FGH 8 DPUR X 2
NGK PFR 5 R-11
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Bosch F 8 DPER
0.039 in (1.0 mm)
15 – 22 ft.lb (20 – 30 Nm)Beru 14 F 7-DPUR X 2
0.041 in (1.05 mm)
15 – 22 ft.lb (20 – 30 Nm)
ProCarManuals.com

392 Technical data
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Main Dimensions
We i g h t s Model CL 500 CL 55 AMG CL 600
Overall vehicle length 196.6 in (4993 mm) 196.6 in (4993 mm) 196.6 in (4993 mm)
Overall vehicle width 73.1 in (1857 mm) 73.1 in (1857 mm) 73.1 in (1857 mm)
Overall vehicle height 54.9 in (1394 mm) 54.9 in (1394 mm) 54.9 in (1394 mm)
Wheel base 113.6 in (2885 mm) 113.6 in (2885 mm) 113.6 in (2885 mm)
Track, front 62.1 in (1577 mm) 62.1 in (1577 mm) 62.1 in (1577 mm)
Track, rear 62.1 in (1578 mm) 62.1 in (1578 mm) 62.1 in (1578 mm)
Roof load max. 220 lb (100 kg)
Trunk load max. 220 lb (100 kg)
ProCarManuals.com

412 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
TTachometer ......................................................................119
Technical data ................................................................388
Electrical system ....................................................... 391
Main dimensions ......................................................392
Rims and tires ...........................................................389
Weights .......................................................................392
Tele Aid ........................................................................... 210
Emergency calls ........................................................ 211
Information ................................................................ 215
Initiating an emergency call manually ................. 213
Roadside Assistance ................................................. 214
TELE AID - malfunction
and warning messages ............................................ 317
Telephone ........................................................................ 128
General notes ............................................................. 201
Incoming call ............................................................. 131
Redialing .................................................................... 130
Telephone book ......................................................... 128
TELEPHONE - FUNCTION -
malfunction and warning messages ......................309
Telephones and two-way radios ...................................208
The first 1 000 miles (1 500 km) ................................209
Tire inflation pressure ..................................................345Tire inflation pressure monitor ................................... 150
Inquiry of present tire inflation pressure ............. 150
TIRE PRESSURE -
malfunction and warning messages ...................... 312
Tire traction ................................................................... 244
Tires ................................................................................ 399
Driving instructions ................................................ 243
Rims and tires .......................................................... 389
Rotating wheels ........................................................ 338
Tire inflation pressure ............................................ 345
Tire replacement ...................................................... 337
Winter driving instructions .................................... 247
Tow-away alarm ................................................................64
Towing the vehicle ......................................................... 351
Transmission ................................................................. 229
Traveling abroad ........................................................... 249
Trip computer ................................................................. 134
Trip odometer ................................................................. 119
Trunk .................................................................................53
Opening ........................................................................37
Power closing assist .................................................... 50
Release switch ............................................................. 57
Release/close system ..................................................58
Trunk lid closing feature ...........................................55
Trunk lamp ..................................................................... 371
