2000 Lexus LS400 fuse box

61L005b
INTRODUCTION
398
ENGINE COMPARTMENT OVERVIEW
1 Engine oilfiller cap
2 Engine oilleveldipstick
3 Brake fluid
reservoir
4 Fuse box
5 Battery
6 Washerfluid tank
7 Power
steeringfluidreservoir
8 Engine
coolantreservoir

ELECTRICAL COMPONENTS
450
9 RR FOG7.5No circuit
10 FUEL OPN10Fuel opener system
No.FUSEAMPERECIRCUIT
11 RR CIG15Rear cigarette lighter,
Power outlet
12 FR CIG15Front cigarette lighter, SRS
13 A/C7.5Air conditioning system
14 P RR
DOOR20Rear door lock,
Rear power window
15 STOP LP25Stop lights,
High mounted stop light
16 RADIO NO.215
Audio system,
Outside rear view mirror,
Shift lock system,
Air conditioning system
17 PANEL7.5Instrument panel lights,
Air conditioning system, Glove
box light, Audio system
18 STARTER7.5
Starting system,
Automatic transmission system,
Multiport fuel injection
system/sequential multiport fuel
injection system
19 TAIL7.5Tail lights, Side marker lights,
License plate lights

ELECTRICAL COMPONENTS
460

Engine compartment 1Spare fuses
2Pull±out tool
1. Turn the ignition switch off and open the fuse box
lid.
Determine which f
use may be causing the problem. The
lid of the fuse box shows the name of the circuit for each
fuse.
64L013
2. Make sure the inoperative component is turned
off. Pull the suspected fuse straight out with the
pull±out tool and check it. If it has blown, push a new
fuse into the clips.

ELECTRICAL COMPONENTS
461
64L064

Good
Blown
a. Look carefully at the fuse. If the thin wire is broken,
the fuse has blown. If you are not sure or if it is too dark
to see, try replacing the suspected fuse with one of the
same value that you know is good.
b. Only install a fuse with the amperage rating
designated on the fuse box lid.
If you do not have a spare fuse, in an emergency you can
pull out the ºRADIO NO.1º ºMIR±HTRº or ºOBDº fuse,
which may be dispensable for normal driving, and use it
if its amperage rating is the same.
If you cannot use one of the same amperage, use one
lower than, but as close as possible to, the amperage.
If the amperage is lower than that specified, the fuse
might blow out again but this does not indicate anything
wrong. Be sure to get the correct fuse as soon as
possible and return the substitute to its original clips. It is a good idea to purchase a set of spare fuses and
keep them in your vehicle for emergencies.
If the new fuse immediately blows out, there is a problem
with the electrical system. Have your Lexus dealer
correct it as soon as possible.
