2000 FORD EXPEDITION keyless

2. Turn ignition to OFF and remove the first coded key from the ignition.
3. Within five seconds of turning the ignition to OFF, insert the second
previously programmed coded key into the ignition and turn the ignition
from OFF to ON (maintain ignition in ON for at least one second but no
more than five seconds).
4. Turn the ignition to OFF and remove the second coded key from the
ignition.
5. Within 10 seconds of turning the ignition to OFF, insert the new
unprogrammed key (new key/valet key) into the ignition and turn the
ignition from OFF to ON (maintain ignition in ON for at least one
second). This step will program your new key to a coded key.
6. To program additional new unprogrammed key(s), repeat this
procedure from step 1.
If the programming procedure was successful, the new coded key(s) will
start the vehicle's engine. The theft indicator (located on the instrument
panel) will light for three seconds and then go out.
If the programming procedure was not successful, the new coded key(s)
will not operate the vehicle's engine. The theft indicator will flash on and
off. Wait at least one minute and then repeat the procedure from step 1.
If failure repeats, bring your vehicle to your dealership to have the new
spare key(s) programmed.
REMOTE ENTRY SYSTEM
Your vehicle is equipped with a remote entry system which allows you to:
²unlock the vehicle doors without a key.
²lock all the vehicle doors without a key.
²activate the personal alarm.
The remote entry features only operate with the ignition in the OFF
position.
If there is any potential remote keyless entry problem with your vehicle,
ensureALL key fobs(remote entry transmitters) are brought to the
dealership, to aid in troubleshooting.
Controls and features
84

5. Turn the ignition back to ON. The horn will chirp.
6. Press the unlock control, then press the lock control. The horn will
chirp once if autolock was deactivated or twice (one short and one long
chirp) if autolock was activated.
7. Turn the ignition to OFF. The horn will chirp once to confirm the
procedure is complete.
Keyless entry system
With the keyless entry keypad, you can:
²lock or unlock the vehicle doors without using the key.
Your vehicle has a factory set 5 digit code that operates the keyless entry
system. You can also program your own 5 digit personal entry code. The
factory-set code is located:
²on the owner's wallet card in the glove compartment
²taped to the computer module.
When pressing the controls on the keyless entry keypad, press the
middle of the controls to ensure a good activation.
Programming your own personal entry code
To program your own code:
1. Enter factory set code (keypad will illuminate when pressed).
2. Press 1/2 control within five
seconds of step 1.
3. Enter your personal 5 digit code.
Enter each digit within five seconds
of previous one.
Do not set a code that includes five
of the same number or presents
them in sequential order. Thieves
can easily figure out these types of codes.
Your personal code does not replace the permanent code that the
dealership gave you. You can use either code to unlock your vehicle. If a
second personal code is entered, the module will erase it in favor of the
new code.
If you wish to erase your personal code, use the following instructions:
1. Enter factory set code.
123
45678
90
Controls and features
90

2. Press 1/2 control within five
seconds of step one.
3. Press 7/8 control and 9/0 control
at the same time within five seconds
of step 2.
The system will now only respond
to the factory set code.
Unlocking the doors with the keyless entry system
To unlock the driver door, enter either the factory set code or the
personal code (each digit must be pressed within five seconds of the
prior digit). The interior lamps will also illuminate.
To unlock all doors, enter the factory set code or personal code (driver
door unlocks) and press the 3/4 control within five seconds.
Locking the doors with the keyless entry system
It is not necessary to enter the factory or personal code prior to locking
all doors. To lock the doors:
²Press the 7/8 control and the 9/0 control at the same time.
Activating/deactivating autolock with the keyless entry system
Before following the activation or deactivation procedures, make sure
that the anti-theft system (if equipped) is not armed, ignition is off, and
all vehicle doors and liftgate window are closed.
1. Enter 5 digit entry code
2. Press and hold 7/8 control
3. Press and release 3/4 control while holding 7/8 control
4. Release 7/8 control.
The horn will chirp once if autolock was deactivated or twice (one short
and one long chirp) if autolock was activated.
To re-activate autolock, repeat steps 1±4.
123
45678
90
Controls and features
91

lighting up
panel and interior .....................20
location of components ..............8
Jump-starting your vehicle ......175
Keyless entry system
autolock .....................................89
locking and unlocking doors ....91
programming entry code .........90
Keys
key in ignition chime ...............13
positions of the ignition ...........62
Lamps
autolamp system .......................20
bulb replacement
specifications chart ................219
cargo lamps ...............................20
daytime running light ...............19
fog lamps ...................................20
headlamps .................................19
headlamps, flash to pass ..........19
instrument panel, dimming .....20
interior lamps ...............75,76,220
replacing
bulbs ............215,216,217,218,219
Lane change indicator
(see Turn signal) ........................63
Liftgate ........................................81
Lights, warning and indicator ......8
air bag ..........................................9
air suspension .........................139
anti-lock brakes (ABS) .....10,135
anti-theft ...................................11
brake ..........................................10
charging system ........................11
check coolant ............................11
cruise indicator .........................12
door ajar ....................................12
engine oil pressure ...................11
high beam .................................11
low fuel ........................................8
low washer fluid .......................12
safety belt .................................10service engine soon ....................8
turn signal indicator .................10
Load limits .................................149
GAWR ......................................149
GVWR ......................................149
trailer towing ..........................149
Loading instructions .................151
Locks
autolock .....................................89
childproof ..................................78
doors ..........................................78
Lubricant specifications ....229,232
Lumbar support, seats ...............92
Message center ......................17,71
english/metric button ...............17
menu button .............................17
Mirrors .........................................76
automatic dimming
rearview mirror .........................76
fold away ...................................80
heated ........................................79
programmable memory ............88
side view mirrors (power) .......79
Moon roof ....................................70
Motorcraft parts .................210,226
Octane rating ............................208
Odometer .....................................15
Oil (see Engine oil) ..................183
Overdrive .....................................68
Panic alarm feature, remote
entry system ................................85
Parking brake ............................136
Parts (see Motorcraft parts) ....226
Pedals (see Power
adjustable foot pedals) ...............21
Power adjustable foot pedals .....21
Power distribution box
(see Fuses) ...............................166
Power door locks ...................78,89
Power steering ...................137,138
fluid, checking and adding ....193
fluid, refill capacity ................226
Index
251
