GENERAL
Europe TOTAL TRANSMISSION
Manual gearbox Overseas France (new formula)
Asia Norms S.A.E 75W-80
TOTAL FLUIDE ATX ou
Automatic gearbox MB3TOTAL FLUIDE AT 42.
Special oil distributed by CITROEN
(Part No. : 9730 94).
TOTAL FLUIDE AT 42 ou
Automatic gearbox 4 HP 14 et 4 HP 18 All countries Special oil distributed by CITROEN
(Part No. : 9730 94).
Automatic gearbox 4 HP 20 et AL4Special oil distributed by CITROEN
(Part No. : 9736 22).
Transfer box and differentialTOTAL TRANSMISSION X 4
C MATIC gearboxTOTAL FLUIDE T
Oils for power-assisted steering
Power-assisted steering All countries TOTAL FLUIDE ATX
LUBRICANTS – TOTAL recommended oils
Gearbox oils
Oils for power-assisted steering

Downloaded from www.Manualslib.com manuals search engine GENERAL
31
Liquide de refroidissement moteur
LUBRICANTS – TOTAL recommended oils
PacksCITROEN reference
GLYSANTIN G 33 REVCOGEL 2000
CITROEN Fluid 2 litres9979 70 9979 72
All countries
Protection : - 35°C 5 litres9979 71 9979 73
20 litres9979 76 9979 74
210 litres9979 77 9979 75
Synthetic brake fluid
Packs CITROEN reference
All countriesCITROEN Fluid0.5 litre9979 05
1 litre9979 06
5 litres9979 07
CITROEN hydraulic circuit fluid
Orange-coloured synthetic fluid, for HYDRACTIVE 3 suspension and for steering
TOTAL LDS FLUIDPacks CITROEN reference
All countries 1 litre9979.69
Hydraulic circuit rinsing fluid – green colour
TOTAL HYDRAURINCAGE

Downloaded from www.Manualslib.com manuals search engine 32
GENERAL
CITROEN reference
Concentrated : 250 ml9980 33 ZC 9875 953 U 9980 56
All countries Liquid ready to use: 1 litre9980 06 ZC 9875 784 U
Liquid ready to use: 5 litres9980 05 ZC 9885 077 U ZC 9875 279 U
Grease
Norms NLGI (1)
All countriesTOTAL MULTIS EP2 2
TOTAL MULTIS COMPLEX EP2 2
TOTAL MULTIS N4128 1
TOTAL SMALL MECHANISMS
(1) NLGI = National Lubrificating Grease Institute.
Wash/wipe fluid
LUBRICANTS – TOTAL recommended oils

Downloaded from www.Manualslib.com manuals search engine 33
GENERAL
ENGINE OIL CONSUMPTION
I-Oil consumption depends on :
- the engine type.
- how run-in or worn it is.
- the type of oil used.
- the driving conditions.
II -An engine can be considered RUN-INafter:
- 3,000 miles(5,000 km) for aPETROLengine.
- 6,000 miles (10,000 km) for a DIESELengine.
III - MAXIMUM PERMISSIBLEoil consumption for a RUN-INengine.
- 0.5 litres per600 miles (1,000 km) for a PETROL engine.
- 1 litre per 600 miles(1,000 km) for a DIESEL engine.
DO NOT WORK BELOW THESE VALUES.
IV - OIL LEVEL :The level shouldNEVER be above theMAX. mark on the dipstick after changing or topping up the oil.
- This excess oil will be used up rapidly.
- It will reduce the engine output and adversely affect the operation of the air circuits and gas recycling.

Downloaded from www.Manualslib.com manuals search engine ENGINE
34
ENGINE SPECIFICATIONS
Engine type
Cubic capacity (cc)
Bore / Stroke
Compression ratio
Power ISO or EEC KW - rpm
Power DIN (HP - rpm)
Torque ISO or EEC (m.daN - rpm)
Torque DIN (mkg-rpm)
Max. speed (rpm)
Petrol
Engines : 6FZ - RFN -LZ - XFX
All Types
1.8i 16V2.0i 16V 2.0i Hpi
3.0i V6
6FZ RFN RLZ XFX
1749 1997 1998 2946
82.7/81.4 85/88 85/88 87/82.6
10.8/1 10.8/1 11.4/1 10.9/1
85-5500 99-6000 103-5500 152-6000
117-5500 136-6000 143-5500 21-6000
16-4000 19-4100 19.2-4250 28.5-3750
16.5-4000 19.8-4100 20-4250 29.7-3750

Downloaded from www.Manualslib.com manuals search engine ENGINE
35
ENGINE SPECIFICATIONS
Engine type
Cubic capacity (cc)
Bore / Stroke
Compression ratio
Power ISO or EEC KW - rpm
Power DIN (HP - rpm)
Torque ISO or EEC (m.daN - rpm)
Torque DIN (mkg-rpm)
Max. speed (rpm)
Diesel
Engines : RHY - RHZ - 4HX
All Types
2.0 HDi
2.2 HDi
RHY RHZ 4HX
1997 2179
85/88 85/96
17.6/1 18/1
66-4000 80-4000 100-4000
90-4000 110-4000 13.8-4000
20.5-1900 25-1750 31.5-2000
24.1-1900 26-1750 32.8-2000
5300 5300

Downloaded from www.Manualslib.com manuals search engine ENGINE
36
ENGINE SPECIFICATIONS
Engines : 6FZ-RFN-RLZ
Compulsory engine plate :
"a" Engine legislation type.
"b"Component reference.
"c"Factory serial no.
B1BPWMD

Downloaded from www.Manualslib.com manuals search engine ENGINE
37
CYLINDER HEAD
Engines : 6FZ-RFN-RLZ
Cylinder head gasket identification
Nominal dimension Repair dimension
6FZ RFN-RLZ
Marking zone
"d"4.5 1.4 2-4-5
Marking zone
"e"R1 R2
Gasket thickness 1.1 mm 1.4 mm
Supplier MEILLOR
Multilayer metallic cylinder head gasket.
(d) Marking zone
(e) Marking zone
B1DP183D
