6-59
Micro-Relays
16 Air Conditioning Compressor. . . . . . . . . . . . . . . .
17 Not Used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18 Fuel Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19 Automatic Light Control. . . . . . . . . . . . . . . . . . .
20 Automatic Light Control. . . . . . . . . . . . . . . . . . .
21 Horn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22 Daytime Running Lamps. . . . . . . . . . . . . . . . . . .
Mini
-Fuses
23
- 32 Spare Fuse Holder. . . . . . . . . . . . . . . . . . . . .
33 Rear Defog. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
34 Accessory Power Outlets, Cigar Lighter. . . . . . .
35 Generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
36 Not Used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
37 Air Conditioning Compressor, Body . . . . . . . . . .
Function Control Module
38 Automatic Transaxle. . . . . . . . . . . . . . . . . . . . . . .
39 Powertrain Control Module, Ignition. . . . . . . . . .
40 Anti
-Lock Brakes . . . . . . . . . . . . . . . . . . . . . . . . .
41 Ignition System. . . . . . . . . . . . . . . . . . . . . . . . . . .
42 Back
-Up Lamps, Brake Transaxle . . . . . . . . . . . .
Shift Interlock ControlMini
-Fuses
43 Horn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
44 Powertrain Control Module. . . . . . . . . . . . . . . . .
45 Parking Lamps. . . . . . . . . . . . . . . . . . . . . . . . . . .
46 Climate Control System. . . . . . . . . . . . . . . . . . . .
47 Canister Purge Valve, Powertrain. . . . . . . . . . . . .
Control Module, Exhaust Gas Recirculation,
Heated O
2 Sensor
48 Fuel Pump Injectors. . . . . . . . . . . . . . . . . . . . . . .
49 Not Used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
50 Right Headlamp. . . . . . . . . . . . . . . . . . . . . . . . . .
51 Left Headlamp. . . . . . . . . . . . . . . . . . . . . . . . . . .
52 Cooling Fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
53 HVAC Blower (Climate Control ). . . . . . . . . . . .
54 Not Used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
55 Cooling Fan #2 Ground. . . . . . . . . . . . . . . . . . . .
56 Fuse Puller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
57 Not Used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-60
Replacement Bulbs
Exterior Lamps Bulb
High
-Beam Headlamp 9005. . . . . . . . . . . . . . . . . . . .
Low
-Beam Headlamp 9006. . . . . . . . . . . . . . . . . . . .
Front Park/Turn 3157 NA. . . . . . . . . . . . . . . . . . . . . .
Front Sidemarker 24. . . . . . . . . . . . . . . . . . . . . . . . . .
Back
-Up/Rear Turn 3156. . . . . . . . . . . . . . . . . . . . . .
Center
- Mounted High Level Stoplamp
(Interior Mounted) 912. . . . . . . . . . . . . . . . . . . . . .
Tail/Stoplamp 3057. . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps Bulb
Dome 561 *. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glovebox 194 *. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For service on these bulbs, contact your Chevrolet
dealer service department.
Capacities and Specifications
Engine Specifications
VIN Engine Code J. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 3.1 Liters. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Horsepower 170. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Cooling System13.6 quarts (12.9 L) . . . . . . . . . . . . .
Engine Crankcase4.5 quarts (4.3 L) . . . . . . . . . . . .
Fuel Tank14.3 gallons (54.1 L) . . . . . . . . . . . . . . . . .
Refrigerant, Air ConditioningSee refrigerant . . . . .
charge label under the hood.
Tire Pressures, SizesSee Tire
-Loading . . . . . . . . . . .
Information label on the rear driver's
side passenger door.
All capacities are approximate. When adding, be sure to fill
to the appropriate level or as recommended in this manual.
See ªRecommended Fluids and Lubricantsº in the Index.
7-31
Part C: Periodic Maintenance
Inspections
Listed in this part are inspections and services which
should be performed at least twice a year (for instance,
each spring and fall). You should let your dealer's
service department or other qualified service center do
these jobs. Make sure any necessary repairs are
completed at once.
Proper procedures to perform these services may be
found in a service manual. See ªService and Owner
Publicationsº in the Index.
Steering, Suspension and Front Drive Axle
Boot and Seal Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts, signs of
wear or lack of lubrication. Inspect the power steering
lines and hoses for proper hook
-up, binding, leaks,
cracks, chafing, etc. Clean and then inspect the drive
axle boot seals for damage, tears or leakage. Replace
seals if necessary.
Exhaust System Inspection
Inspect the complete exhaust system. Inspect the body
near the exhaust system. Look for broken, damaged,
missing or out
-of-position parts as well as open seams,
holes, loose connections or other conditions which could
cause a heat build
-up in the floor pan or could let
exhaust fumes into the vehicle. See ªEngine Exhaustº in
the Index.
Engine Cooling System Inspection
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes,
fittings and clamps; replace as needed. Clean the outside
of the radiator and air conditioning condenser. To help
ensure proper operation, a pressure test of the cooling
system and pressure cap is recommended at least once
a year.
