2000 CADILLAC ESCALADE headlamp

2-43 Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high or high
to low, pull the turn signal lever all the way toward you.
Then release it.
When the high beams are
on, this light located on the
instrument panel also will
be on.
Windshield Wipers
You operate the windshield wipers by turning the
control with the wiper symbol on it located on the
multifunction lever.
For a single wiping cycle, turn the control to MIST.
Hold it there until the wipers start, then let go. The
wipers will stop after one cycle. If you want more
cycles, hold the control on MIST longer.You can set the wiper speed for a long or short delay
between wipes. This can be very useful in light rain or
snow. Turn the control to choose the delay time. The
closer to LOW, the shorter the delay.
For steady wiping at low speed, turn the control to the
LOW position. For high
-speed wiping, turn the control
further, to HIGH. To stop the wipers, turn the control
to OFF.
Damaged wiper blades may prevent you from seeing
well enough to drive safely. To avoid damage, be sure to
clear ice and snow from the wiper blades before using
them. If they are frozen to the windshield, carefully
loosen or thaw them. If your blades do become
damaged, get new blades or blade inserts. See
ªWindshield Wipers, Blade Replacementº in the Index.
Heavy snow or ice can overload your wipers. The
windshield wiper motor is protected from overload by a
circuit breaker and a fuse. If the motor overheats due to
heavy snow or ice, the wiper will stop until the motor
cools. Although the circuit is protected from electrical
overload, overload due to heavy snow or ice may cause
wiper linkage damage. Always clear ice and heavy
snow from the windshield before using your
windshield wipers.

2-48
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Exterior Lamps
Your parking/headlamp knob is located on the driver's
side of your instrument panel.Turn the knob clockwise, to the parking lamp symbol, to
turn on the following:

Parking Lamps

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
Turn the knob clockwise again, to the master lighting
symbol, to turn on all the lamps listed as well as
the headlamps.
Turn the knob counterclockwise to OFF, to turn off your
lamps. For additional information on headlamp
operation, see ªHeadlamp Delayº in the Index.
Turn the thumbwheel next to the knob up to adjust
instrument panel lights. Turn the thumbwheel up to the
first notch to return the radio display and gearshift
indicator LED display to full intensity when the
headlamps or parking lamps are on. To turn on the dome
lamps (with the vehicle doors closed) turn the
thumbwheel up to the second notch position.
You can switch your headlamps from high to low beam
by pulling on the turn signal/high
-beam lever.

2-49 Automatic Headlamp System
When it is dark enough outside, your automatic
headlamp system will turn on your headlamps at the
normal brightness along with other lamps such as the
taillamps, sidemarker, parking lamps and the instrument
panel lights.
To idle your vehicle with the automatic headlamp
system off, set the parking brake while the ignition is
off. Then start the vehicle. The automatic headlamp
system will stay off until you release the parking brake.
The headlamp switch can always be used to turn on the
regular lamps. As with any vehicle, you should turn on
the regular headlamp system when you need it.
Headlamps-On Reminder
A chime will sound when your headlamps are turned on
and your ignition is in OFF, LOCK or ACCESSORY.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.The DRL system will make your headlamps come on at
a reduced brightness when:

the ignition is on,

the headlamp switch is off,

the parking brake is released and

it is bright enough outside and the automatic
headlamps are off.
When the DRL are on, only your headlamps will be on.
The taillamps, sidemarker and other lamps won't be on.
Your instrument panel won't be lit up either.
When it begins to get dark, your DRL will turn off. Your
headlamps will come on automatically.
When it begins to get bright, the regular lamps will go
off, and your headlamps will change to the reduced
brightness of DRL.
To idle your vehicle with the DRL off, set the parking
brake. The DRL will stay off until you release the
parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.

2-50 Fog Lamps
Your vehicle has fog lamps. Use them for better vision
in foggy or misty conditions. Your parking lamps and/or
low
-beam headlamps must be on for your fog lamps to
work. Fog lamps are not meant to be used without
headlamps in the dark.
The fog lamp switch is
located to the right of the
instrument panel cluster.
Press the ribbed top part of the switch to turn the fog
lamps on. Press the bottom of the switch to turn them
off. An indicator light will illuminate in the switch when
the fog lamps are on.
Fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beams are off, the
fog lamps will come on again.
Headlamp Delay
Your vehicle is equipped with a headlamp delay feature
that holds the headlamps on for a short period of time
after the ignition is turned off.
The HEADLAMP DELAY button is located on the
lower left side of the inside rearview mirror.

2-51
The length of time that the headlamps stay on after the
ignition is turned off can be adjusted by pressing and
holding the HEADLAMP DELAY button. The delay
can be varied in five steps (0, 15, 30, 60 and 90
seconds). When the HEADLAMP DELAY button is
held in, the Light Emitting Diode (LED) on the mirror
will show five step changes in brightness. When the
LED is at its brightest the headlamp delay will be
90 seconds, and when it is most dim the delay will be
zero seconds.
Interior Lamps
Instrument Panel Intensity Control
The instrument panel intensity control is located next to
the parking/headlamp switch. Turn the thumbwheel up
to adjust the instrument panel lights. Turn the
thumbwheel up to the first notch to return the radio
display and gear shift indicator LED display to full
intensity when the headlamps or parking lamps are on.
To turn on the dome lamps (with the vehicle doors
closed) turn the thumbwheel up to the second
notch position.
Exit Lighting and Delayed Illumination
With this feature, your interior lamps will come on and
stay on for up to 25 seconds when entering the vehicle
and up to five seconds when leaving your vehicle.
When the doors are opened, the dome lamps will only
come on if the DOME OVERRIDE button is in the out
position. When all doors are closed the lamps will stay
on for a short period of time and will then fade out. If
the DOME OVERRIDE button is pressed in, the dome
lamps will not illuminate.
Dome Lamps
The dome lamps will come on when you open the doors.
You can also turn the dome lamps on by turning the
thumbwheel, located next to the parking/headlamps
switch knob, all the way up to the second notch. In this
position, the dome lamps will remain on whether the
doors are opened or closed.

2-52
You can use the DOME OVERRIDE button, located
below the parking/headlamp knob, to set the dome
lamps to come on automatically when the doors are
opened, or remain off. To turn the lamps off, press the
button to the ªinº position. With the button in this
position, the dome lamps will remain off when the doors
are open. To return the lamps to automatic operation,
press the button again and return it to the ªoutº position.
With the button in this position, the dome lamps will
come on when you open the door.
Reading Lamps
Your vehicle has reading
lamps. Press the button
located next to the lamp to
turn the lamp on.
The lamps can be adjusted to point in the direction
you want.
Press the button again to turn the lamp off.
Battery Rundown Protection
This feature shuts off the dome, courtesy, vanity,
reading, glove box and underhood lamps if they are left
on for more than 20 minutes when the ignition is off.
This will keep your battery from running down.

2-53
Mirrors
Electrochromic Inside Rearview Mirror
with Compass, Temperature Display and
Headlamp Delay
Your vehicle has electrochromic inside and outside
rearview mirrors. Your vehicle also has a headlamp
delay feature. See ªHeadlamp Delayº in the Index for
more information.
When on, an electrochromic mirror automatically dims
to the proper level to minimize glare from lights behind
you after dark.
The mirror also includes an eight-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
The display can also be used to indicate outside
air temperature.

2-56 Electric Outside Rearview Mirrors
The electric mirrors can be adjusted to point where you
want from inside the vehicle.
Select the mirror you want
to move by turning the
center of the switch, located
on the driver's door armrest,
to L (left) or R (right).
Then, adjust the mirror angle by pressing the outer
arrows on the switch until the mirror is adjusted where
you want it. The center position turns the electric
mirrors off.
The mirrors can also be folded forward or rearward. To
fold the mirror, push forward or rearward on the
mirror head.
Electrochromic Heated Outside
Rearview Mirrors
The outside rearview mirrors feature auto-dimming and
defrost modes.
To turn on the auto
-dimming feature, press and hold the
TEMP button on the inside rearview mirror for about 15
seconds. See ªElectrochromic Inside Rearview Mirror
with Compass, Temperature Display and Headlamp
Delayº in the Index for further information.
To turn on the defrost feature, press the rear window
defrost button. See ªRear Window Defoggerº in the
Index for further information.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
