2000 CADILLAC DEVILLE clock setting

iii
Section
3
Comfort Controls and Audio Systems
Section
4
Your Driving and the Road
Section
5
Table of Contents (cont'd)
Braking/Anti-lock Brakes
Traction Control System
SteeringDriving Tips for Various Road Conditions
Loading Your Vehicle
Towing a Trailer Heating and Air Conditioning
Setting the Radio Clock
Radio/Cassette Player/CD PlayerRadio Theft-Deterrent Feature
Steering Wheel Controls (If Equipped)
Hazard Warning Flashers
Jump Starting
Towing Your VehicleEngine Overheating
Changing a Flat Tire
If You're Stuck
Problems on the Road

2-47
Parking Lamps
Turn the lamp control knob clockwise to the first stop,
to turn on the parking, taillamps, sidemarker lamps. If it
is night, the instrument panel switch backlighting will
also illuminate. Turn the control knob counterclockwise
all the way back to turn the lamps and lights off.
Headlamps
Turn the control knob clockwise all the way to turn on
the parklamps and headlamps. Turn the control knob
counterclockwise to turn the lamps off.
Wiper
-Activated Headlamps
This feature activates the headlamps and parking lamps
after the windshield wipers have been in use for
approximately six seconds.
In order to operate the wiper
-activated headlamps, the
Twilight Sentinel
must be turned on; the ignition key
in the ON position and the windshield wipers on, or in a
delay setting. If the windshield wipers are active while
the ignition key is in ON, but the Twilight Sentinel
switch is off, a ªHeadlamps Suggestedº message will be
displayed on the Driver Information Center. This
message informs the driver that turning on the exterior
lamps is recommended.This feature lights the way in poor weather and it also
makes your vehicle more visible to other drivers. If the
wiper
-activated headlamps are on and the ignition
switch, Twilight Sentinel, or the wipers are turned off,
the wiper
-activated headlamps will immediately
turn off.
Lamps on Reminder
If the manual headlamp control is left on and a door is
opened, a warning chime will sound. An exception is
when the Twilight Sentinel function is active.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control Panel
3
-6 Electronic Solar Sensor
3
-6 Air Conditioning
3
-6 Heating
3
-7 Defogging and Defrosting
3
-7 Rear Window Defogger
3
-8 Rear Climate Control
3
-9 Ventilation System
3
-10 HVAC Steering Wheel Controls
3
-10 Climate Control Personalization (If Equipped)
3
-11 Audio Systems
3
-11 Setting the Clock
3
-11 AM-FM Stereo with Cassette Tape Player
3
-15 AM-FM Stereo with Cassette Tape and
Compact Disc Player (If Equipped)
3
-19 AM-FM Stereo with Cassette Tape and Compact
Disc Player with Radio Data Systems (RDS) and
Digital Signal Processing (DSP) (If Equipped)3
-28 AM-FM Stereo with Cassette Tape and
MiniDisc Player with Radio Data Systems
(RDS) and Digital Signal Processing (DSP)
(If Equipped)
3
-38 Radio Data Systems (RDS) Program Type
(PTY) Selections
3
-39 Navigation/Radio System (Option)
3
-39 CD Adapter Kits
3
-43 Radio Personalization with Home and Away
Feature (If Equipped)
3
-43 Theft-Deterrent Feature
3
-44 Audio Steering Wheel Controls
3
-45 Understanding Radio Reception
3
-45 Tips About Your Audio System
3
-46 Care of Your Cassette Tape Player
3
-48 Care of Your Compact Discs
3
-48 Care of Your Compact Disc Player
3
-48 Diversity Antenna System

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
With this system, you can control the heating, cooling
and ventilation in your vehicle. Your vehicle also has a
flow
-through ventilation system described later in
this section.
Climate Control Panel
Fan Button
The button with the fan symbol adjusts the fan speed.
Press the up arrow to increase fan speed and the down
arrow to decrease fan speed.Driver's Side Temperature Knob
The knob adjusts the air temperature coming through the
system. Turn the knob clockwise to increase the
temperature and counterclockwise to decrease the
temperature. Press the knob to turn the system off.
Passenger's Side Temperature Button
With this feature, the right front passenger can control
the temperature of air for his/her own zone. The
passenger can select a warmer or cooler temperature
from the driver's setting.
To turn the system on, press the PASS/TEMP button.
Press the up arrow to increase the temperature and
press the down arrow to decrease the climate setting.
Pressing the PASS/OFF button will turn off the
dual
-zone function.
Rear Passenger Climate Control
With this feature, the rear passenger (s) can control the
temperature of the air for the rear compartment.
To adjust the direction of the air flow, press the MODE
button, to adjust the blower speed, press the fan symbol
button and to adjust the temperature, press the TEMP
button. The driver can also override the system and select
a PASS OFF button to turn off the rear climate controls.
See ªRear Climate Controlº later in this section.

3-11
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.
Setting the Clock
Press and hold HR or MN until the time display begins
to change. Release the button as you get close to the
correct time. The time may be set anytime the clock is
displayed. There is a two
-second delay before the clock
goes into time
-set mode.
AM-FM Stereo with Cassette Tape Player
Playing the Radio
PWR/VOL: Press this knob lightly to turn the system
on. Press the knob again to turn the system off. To
increase volume, turn the knob clockwise. Turn it
counterclockwise to decrease volume.
HR or MN: Display the time with the ignition off by
pressing this button.

3-13
Setting the Tone
TONE: Press and release this button until the desired
tone control (BASS or TREBLE) is found. The radio
keeps separate tone settings for each band, each preset
and each source.
LEVEL: After selecting the desired tone control, press
the plus (+) or minus (
-) symbol on this button to select
the desired level.
To save the tone settings for your presets, press and hold
the numbered button for the desired preset for more than
two seconds until you hear a beep.
Adjusting the Speakers
SPEAKER: Press and release this button until the
desired BALANCE or FADE control is found.
LEVEL: After selecting the desired BALANCE or
FADE control, press the plus (+) or minus (
-) symbol on
this button to select the desired level.Playing a Cassette Tape
With the radio on, insert a cassette tape. The tape will
begin playing as soon as it is inserted. When one side of
your cassette tape is done playing, auto reverse plays the
other side of your cassette tape. Cassette tapes may be
loaded with the radio off but they will not start playing
until the radio is on. If you want to insert a cassette tape
when the ignition is off, first press the eject button.
While the tape is playing, use the VOL, TONE, LEVEL, and
SPEAKER controls just as you do for the radio. Other
controls may have different functions when a tape is inserted.
The display will show an underlined tape symbol. TAPE
PLAY will appear on the display when a tape is playing, with
an arrow to indicate which side of the tape is playing.
If an error occurs while trying to play a cassette tape, it
could be that:

The cassette tape is tight and the cassette player
cannot turn the hubs of the tape. Hold the cassette
tape with the open end down and try turning the right
hub counterclockwise with a pencil. Flip the tape
over and repeat. If the hubs do not turn easily, your
cassette tape may be damaged and should not be
used in the player. Try a new tape to be sure your
player is working properly.

The cassette tape is broken. (Check to see if your
tape is broken. Try a new tape.)

3-34
HR or MN: Press the RDS SELECT button, followed
by one of these buttons to display the time for the
current station. STATION TIME IS will be displayed. If
a time has not been sent to the radio, NO STATION
TIME will be displayed. If you have recently tuned to
the station, you may need to wait a minute before the
time is available to the radio. To set the clock to the
current displayed station time, press and hold HR or MN
until TIME UPDATED is displayed. There is a two
second delay before the time is updated. RDS mode
does not have to be on to use this function, but you must
be tuned to an FM RDS station.
ALERT: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. Alert announcements will come on
even if RDS mode is turned off. ALERT appears on the
display when an alert announcement plays. The radio
uses TA volume during these announcements. To
increase volume, turn the PWR/VOL knob clockwise.
Turn it counterclockwise to decrease volume. TA
VOLUME will appear on the display while the volume
is being adjusted. When an alert announcement comeson the tuned radio station or a related network station,
you will hear it, even if the volume is muted or a
cassette tape or MiniDisc is playing. If the radio tunes
to a related network station for an alert announcement,
it will return to the original station when the
announcement is finished. If the cassette tape or
MiniDisc player is playing, play will stop for the
announcement and resume when the announcement is
finished.
Setting the Tone
TONE: Press and release this button until the desired
tone control (BASS, TREBLE or MIDRANGE) is
found. The radio keeps separate tone settings for each
band, preset (except weather band presets) and source.
LEVEL: After selecting the desired tone control, press
the plus (+) or minus (
-) symbol on this button to select
the desired level.
To save the tone settings for your presets, press and hold
the numbered button for the desired preset for more than
two seconds until you hear a beep.

3-43 Radio Personalization with Home and Away
Feature (If Equipped)
If DRIVER 1 (HOME or AWAY) PRESETS or
DRIVER 2 (HOME or AWAY) PRESETS appears in the
display when the radio is first turned on, your vehicle is
equipped with this feature.
With this feature, your vehicle will recall the latest radio
settings as adjusted the last time your vehicle was
operated. This feature allows two different drivers to
store and recall their own radio settings. The settings
recalled by the radio are determined by which RKE
transmitter (ª1º or ª2º) was used to enter the vehicle.
The number on the back of the RKE transmitter
corresponds to driver 1 or to driver 2. The radio settings
will automatically adjust to where they were last set
by the identified driver. The settings can also be recalled
by briefly pressing the MEMORY seat buttons 1 or
2 located on the driver's door.
Your radio can store home and away presets. Home and
away presets allow you to use one set of preset radio
settings in the area where you live, and another set when
you go out of town. That way, you will not need to
reprogram your presets every time you travel. With the
radio off and the clock displayed, use FF and RW to
select home or away presets. To select the away presets,
press and hold FF for five counts until you hear a beep.The next time the radio comes on, the away presets will
be active. To select the home presets, press and hold RW
for five counts until you hear a beep. The next time the
radio comes on, the home presets will be active.
When battery power is removed and later applied, you
will not have to reset your home radio presets because
the radio remembers them. However, you will have to
reset your away radio presets.
Theft-Deterrent Feature
THEFTLOCK
is designed to discourage theft of your
radio. Your vehicle has a ªbuilt
-inº theft-deterrent
feature on each radio that is automatic
-- there is no
programming required. The radio in your vehicle cannot
be used in any other vehicle. When the radio was
originally installed in your vehicle at the factory, it
stored the Vehicle Identification Number (VIN). Each
time the ignition is turned on, the VIN is verified. If the
vehicle's VIN does not match the VIN stored in the
radio, THEFTLOCK will be activated and the audio
system will not play. If the radio is removed from your
vehicle, the original VIN in the radio can be used to
trace the radio back to your vehicle.
