2-9
Instant Alarm
This feature allows you to activate an alarm by pressing
a button on the remote keyless entry transmitter. Your
ignition must be off for the instant alarm to work. When
you press the horn button on the remote keyless entry
transmitter, the headlamps will flash, the horn will honk
repeatedly, and the interior lamps will illuminate,
attracting attention if you need it. The alarm will
continue until:
You press the alarm button on the remote keyless
entry transmitter a second time,
the ignition is in RUN, or
an alarm period of about two minutes has elapsed.
Security Feedback
Security feedback provides audible and/or visible
feedback that a remote keyless entry lock or unlock
command has been received and executed. Your ignition
must be off for this feature to work.You may select one of four operating modes for
reception of a lock command. You may also select one
of four operating modes for reception of an unlock
command. The selection and programming of the lock
and unlock operating modes are independent of each
other. The following modes are available for either lock
or unlock verification:
Mode 1: No Verification
Mode 2: Horn Chirp only
Mode 3: Headlamp Flash only
Mode 4: Horn Chirp and Headlamp Flash
The operating mode of the security feedback
lock feature will be changed when you perform
the following:
Turn the ignition key to RUN.
Close all the doors.
Press and hold the power door lock switch.
While holding the door lock switch, press
and release the remote keyless entry transmitter
lock button.
2-34
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes your:
Turn and Lane Change Signals
Headlamp High/Low
-Beam Changer
Windshield Wipers
Windshield Washer
Cruise Control (If Equipped)
Flash
-to-Pass Feature
Turn Signal and Lane Change Indicator
The turn signal has the following positions: two upward
(for right) and two downward (for left). These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is finished, the lever will
return automatically.
An arrow on the instrument
panel cluster will flash in
the direction of the turn
or lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
If the arrow flashes faster than normal as you signal a
turn or a lane change, a signal bulb may be burned out
and other drivers won't see your turn signal.
2-35
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check for burned
-out bulbs and then check
the fuse (see ªFuses and Circuit Breakersº in the Index).
A chime will sound if you leave your turn signal on for
more than 3/4 mile (1.2 km).
Headlamp High/Low Beam Changer
To change your headlamps from low beams to high
beams, or high to low, pull the multifunction lever all
the way toward you. Then release it.
When the high beams are on this light, located on the
instrument panel, will also be on.
Flash-to-Pass Feature
This feature lets you use your high-beam headlamps
to signal the driver in front of you that you want to pass.
It works even if your headlamps are off.
To use it, pull the turn signal lever toward you a little,
but not so far that you hear a click.
If your headlamps are off or on low beam, your
high
-beam headlamps will turn on. They'll stay on
as long as you hold the lever toward you and the
high
-beam indicator on the dash will come on.
Release the lever to return to normal operation.
2-40
Ending Cruise Control
There are two ways to turn off the cruise control:
Step lightly on the brake pedal, or
move the cruise switch to OFF.
Erasing Cruise Speed Memory
When you turn off the cruise control or the ignition, or
shift into PARK (P) or NEUTRAL (N), your cruise
control set speed memory is erased.
Exterior Lamps
They control these systems:
Headlamps
Taillamps
Parking Lamps
License Lamps
Sidemarker Lamps
Instrument Panel Lights
Courtesy Lamps
The lamp controls
are located on the
instrument panel.
If you pull the knob out halfway, it will turn on your
parking lamps and your other operating lamps. If you
pull the knob all the way out, your headlamps will then
come on.
Push the knob in all the way to turn off the lamps.
A warning chime will sound if you open the driver's
door when you turn the ignition switch to OFF,
LOCK or ACCESSORY with the lamps on.
2-41 Daytime Running Lamps / Automatic
Headlamp Control
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
A light sensor on top of the instrument panel makes the
DRL work, so be sure it isn't covered.
The DRL system will make your front turn signal lamps
come on when:
The ignition is on,
the headlamp switch is off and
the parking brake is released.
When the DRL are on, only your front turn signal lamps
will be on. The headlamps, taillamps, sidemarker and
other lamps won't be on. Your instrument panel won't
be lit up either.
When it's dark enough outside, your front turn signal
lamps will turn off and your vehicle's headlamps and
parking lamps will turn on. The other lamps that come
on with your headlamps will also come on.When it's bright enough outside, your headlamps will go
off and your front turn signal lamps will come on.
To idle your vehicle with the DRL and automatic
headlamp control off, set the parking brake while the
ignition is in OFF or LOCK. Then start your vehicle.
The DRL, headlamps and parking lamps will stay off
until you release the parking brake.
To turn off the automatic headlamp feature when it's
dark outside, move the exterior lamp control to the
parking lamp position. Your parking lamps will remain
illuminated and your headlamps will turn off.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Delayed Headlamp Illumination
Delayed headlamp illumination provides a period of
exterior lighting as you leave your vehicle's area. The
feature is activated when your vehicle's headlamps are
on due to the automatic headlamp control feature
described previously in this section, and when your
vehicle's ignition is turned off. Your headlamps will
then remain on until the headlamp switch is moved from
OFF to the parking lamp position or until a 90 second
lighting period has ended.
2-42
If you turn off the ignition with the headlamp switch in
the parking lamp or headlamp position, the delayed
headlamp illumination cycle will not occur.
You can customize the vehicle to activate delayed
headlamp illumination when your vehicle's ignition is
turned off under the conditions described above, or you
may choose not to activate this feature under any
conditions. You can turn the feature on and off when
you perform the following sequence:
1. Turn the ignition key to RUN.
2. Close all the doors.
3. Press and hold the power door lock switch. While
holding the door lock switch, cycle the headlamp
switch on and then off two times.
4. Release the power door lock switch. These steps
must be carried out in a time period of less than
10 seconds, followed by a delay period of no more
than 10 seconds.
5. Then, press and hold the power door unlock switch.
While holding the door unlock switch, turn the
headlamp switch on and then off two times. Release
the courtesy door unlock switch. These operations
must be carried out in a time period of less than
10 seconds.After releasing the door unlock switch, a single chime
will be heard if the delayed headlamp illumination
function has been disabled; two chimes will be heard
if the feature has been enabled. Disconnecting the
vehicle's battery for up to a year will not change the
programmed operation of this feature.
Interior Lamps
Instrument Panel Brightness Control
You can brighten or dim the instrument panel lights by
moving the LIGHTS knob. If you turn the knob past
MAX, your courtesy or interior lamps will come on.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easier to see as
you enter and exit your vehicle. You can also turn these
lamps on by twisting or turning the interior lights knob
all the way to the right.
2-45 Inside Day/Night Rearview Mirror
To reduce glare from headlamps behind you, pull the
lever at the bottom of the mirror toward you (to the
night position). To return the mirror back to the day
position, push the lever away from you.
Electrochromic Automatic Dimming
Rearview Mirror (If Equipped)
Your vehicle may have an electrochromic day/night
rearview mirror. Push the button in the center of the
mirror to turn this feature on. The mirror will darken
gradually to reduce glare from headlamps behind you.
This may take a few moments.
The mirror's two outer buttons operate the lights on the
bottom sides of the mirror.One photocell on the front of the mirror senses when it
is becoming dark outside. Another photocell, facing
rearward, senses headlamps behind you. To turn the
electrochromic feature off, press the button in the center
of the mirror again.
To keep the photocells operating well, occasionally
clean them with a cotton swab and glass cleaner.
Power Outside Foldaway Mirrors
The power mirror control
switches are located near
the driver's side window,
on the armrest.
To choose either the left or right outside mirror, move
the top switch from left through neutral to right. Press
any of the four buttons located below the top switch to
move the mirrors in the desired direction.
2-46
Adjust each mirror so you can see the side of your
vehicle and the area behind your vehicle.
These mirrors can also be folded rearward manually.
This feature is particularly useful in automatic car
washes and when maneuvering your vehicle in
narrow spaces.
Automatic Dimming/Heated Outside
Rearview Mirror (If Equipped)
If you have this feature, the driver's side outside mirror
will adjust for the glare of headlamps behind you. This
feature is controlled by the on and off settings on the
electrochromic automatic dimming rearview mirror.
(See ªElectrochromic Automatic Dimming Rearview
Mirrorº) earlier in this section.
The left and right outside mirrors are also heated when
you activate the rear window defogger. (See ªRear
Window Defoggerº in the Index.)
Both outside mirrors can be folded forward or
rearward. This feature is particularly useful in
automatic car washes.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
