Page 72 of 189
70n
Wiper/washer system1 Intermittent wipe or rain
sensor
*
Intermittent wipe:
You can use rotary dial 6 to select from
four wipe intervals. In addition, the wipe
interval automatically adapts to varia-
tions in road speed.
Rain sensor:
When the rain sensor is activated, the
windshield wiper is controlled automati-
cally, depending on the degree of wet-
ness of the windshield (in both snow
and rain). You do not have to be con-
cerned with switching the windshield
wiper on or off or adjusting the wipe
interval between intermittent and full
wipe. Instead, you can concentrate fully
on the traffic conditions. This is espe-
cially important under adverse weather
conditions.462de213
To activate the rain sensor:
In ignition key positions 1 or 2, move
the lever to position 1. The wipers travel
once across the windshield under all
circumstances.
You can leave the lever permanently in
position 1, and then activate the rain
sensor in ignition key positions 1 or 2.
To do this,
>turn rotary dial 6 briefly or
>use the automatic windshield
washer 5.
To modify the sensitivity of the rain
sensor:
Turn rotary dial 6.
Switch the rain sensor off when
the vehicle passes through the car
wash. Failure to do so could result in
damage caused by undesired wiper
activation.<
2 Normal wiper speedWhen the vehicle is stationary, the wip-
ers switch automatically to intermittent
wipe (not on vehicles with rain sensor).3 Fast wiper speedWhen the vehicle is stationary, the wip-
ers operate at normal speed (not on
vehicles with rain sensor).5 Automatic windshield washer The system sprays washer fluid against
the windshield and activates the wipers
for a brief period.
If you only pull the lever briefly, the sys-
tem sprays washer fluid onto the wind-
shield without activating the wipers.
Page 73 of 189
71n
RepairsIndexOverview Controls Car care Technology Data
Wiper/washer system Rear window defroster Headlamp washers
*
When the vehicle's lighting system is
switched on, the headlamps will also be
cleaned every fifth time the automatic
windshield washer is activated.
Do not use the washers if there is
any danger that the fluid will freeze
on the windshield, otherwise vision
could be obscured. Use an antifreeze
agent. Refer to page 122.
Do not use the washers when the reser-
voir is empty, otherwise damage to the
washer pump could result.
automatically when the ignition key is in
position 2
*.
To activatePress the button: As long as the indica-
tor lamp remains on, the rear window
defroster continues at high-output
(rapid thaw).
After the indicator lamp goes out, the
defroster continues operating at re-
duced power for a limited period before
deactivating automatically. 460de026
To deactivatePress the button if the indicator lamp is
on.
Page 187 of 189
Owner service procedures from A to Z
185n
RepairsIndexOverview Controls Car care Technology Data
PParking lamps
bulb replacement 142
Pressure, tires 27RRadio remote control
new transmitter 147
Release the hood 119
Remove condensation from
windshields 91
Replace bulbs 140
Replace windshield wiper
blades 140
Replenish washer
reservoir 122
Replenish windshield
washer 122
Return used batteries 153SSliding/tilt sunroof
closing after electrical
fault 155
Space-saver tire 148
Spare tire 148
Starting problems 63, 105
Switching off the interior
motion sensor 43
Switching off the tilt sensor
alarm system 43
TTail lamps
bulb replacement 143
Tire damage 113
Tools 140
Tow fittings 157
Tow starting 157
Towing 157
Turn signal
bulb replacement 142UUse anti-freeze 126
radiator 126VVanity mirror
bulb replacement 146WWarning lamps 20
Warning messages 77
Washer fluid
replenish 122
Wheel lug wrench 148
Working in the engine
compartment 119
